Summary of Contents for XtendLan DPG-IP-G21
- Page 1 English DPG-IP-G21 USER MANUAL ＳＯＳ...
-
Page 2: Parts And Functions
1.Parts and Functions LCD Screen Microphone Alarm Button Handset ＳＯＳ Speaker Unlock Button Call Button Handset Line LED Indicator Dimension:220(H) x 358(W) x 35(D)mm Key functions: Microphone Receives sound from the user. LCD Screen Display the icon menu and images .Touch operation. Alarm Button Flash when the guard unit receives alarm record. -
Page 3: Specification
2.Specification Power supply: DC 14~30V Power consumption: Standby 6W; Working status 13W Working temperature: C~55 Alarm record: 1000 pieces Calls record: 600 pieces Screen: 10 inch digital TFT LCD Video signal: 1Vp-p, 75Ω, CCIR standard Wiring: CAT5 cable Dimension: 220(H) x 358(W) x 35(D)mm 3.About Main Menu The Main menu is your starting point for using all the applications on the guard unit. -
Page 4: Calling Users
Answer calls from common door station • The operation is the same as calling from door station. Answer calls from users • Select "Direct call guard unit" on monitor to call Guard Unit.(please refer to monitor user manual for more detail information) •... -
Page 5: Entrance Monitoring
User alarms to Guard Unit • Select "Call Guard Unit" on monitor to alarm guard unit.(please refer to monitor user manual for more detail information) • The Guard Unit will send out a soud of buzzer and the alarm button will flash in red when receives alarm signal. -
Page 6: System Tools
current monitor. • If the user answers the call,the guard person can talk with the user immediately. • The system will cut off automatically if exceeds the maximum calling waiting time in calling state or exceeds maximum talking time in talking state. Checking all calls record •... -
Page 7: Ring Tone Setting
6.Settings Ring tone setting • User call tone, door station call tone,GL call tone can be set different ring tone to distinguish different calling • Touch " icon on main menu page, then touch " ", total 6 User Setup" Call Tone Setup pieces ring tones will be displayed •... -
Page 8: Built-In Memory And Sd Card
7.Built-in Memory and SD Card The Guard Unit has been equipped with a built-in memory (about 120 MB) together with a SD card reader. Maximum 16 GB SD card can be supported. ＳＯＳ SD card Picture recording Both auto recording and manual recording are available.and auto recording is default. If receive a call , after a moment, the guard unit will record automatically. -
Page 9: Screen And Volume Adjustment
• Avoid to plug in/out the SD card when the guard unit is under operation. • Playing will be interrupted by the calling. 8.Screen and Volume Adjustment During monitoring or talking, touch icon, then touch and select the adjustment item you ADJUST want;...
