Introducing Gimbal Control Modes

Double Press MODE
Mode Switch Schematic Figure
Roll
Tilt
Pan
Pan
Pan Following Mode:The Locking Mode: This mode
smartphone pans left/right locks movement of all three
following the movement of axes to keep the camera still
the stabilizer while the tilt and stable. Push the
and roll axes are locked. joystick up/down and
Push the joystick up/down left/right allows manual
allows manual control of the control of the tilt axis and
tilt axis. pan axis.
15 zhiyun-tech.com
Mode switch:
The stabilizer enters Pan Following Mode by
default each time when powered on. Switch into
Locking Mode by single pressing on the MODE
button. Double press the MODE button to enter
the Following mode. Single press the MODE
button under the Following Mode will return to
the previous mode.
See ZHIYUN's product training videos on
www.ZHIYUN-TECH.com for more operation tips.
Roll
Roll
Tilt
Pan
Following Mode: The
camera pans and tilts
following the movement of
the stabilizer. Push the
joystick left/right allows
manual control of the roll
axis.
1.Connect the stabilizer to your computer using the Micro USB cable for firmware upgrade
and on-line calibration.
2.Connect the stabilizer to a power source for direct charging. The stabilizer can operate
while charging.
Connect the stabilizer to your computer
using the Micro USB cable for firmware
upgrade and on-line calibration.
Calibration can also be operated through
mobile APP.
Visit ZHIYUN's official website:
www.ZHIYUN-TECH.com.
Click to open the "Downloads" page, and
find the Firmware Upgrade Tutorial
package.
Download the driver, calibration tool and
latest firmware corresponding to your
stabilizer.
Upgrade firmware following the
Tilt
instructions indicated in the Firmware
Upgrade Tutorial.
1.Visit ZHIYUN's official website: www.ZHIYUN-TECH.com.
2.Click to open the "Downloads" page, and find ZHIYUN's Gimbal Tools as well as online
calibration tutorial; OR
3.Operate calibration on mobile APP by connecting to the smartphone.

Introducing Connection Ports and Various Operations

Micro USB Port
Firmware Upgrade
Calibration Method
