Battery Safety Guidelines
Batter y Maintenance
1.Never use the batter y when the temperature is too high or too low.
2.Do not store the batter y in any environment with a temperature of over 60°C.
Transportation Notice
1.Discharge the batter y power to 5% or lower before carr ying the batter y on an airline
flight. Only discharge the batter y in a fireproof location, ideally in a dr y and open area.
2.Do not store or transport batteries together with metal objects such as eyeglasses,
watch, and jewelries, etc.
3.Do not transport damaged batteries. When transporting, be sure to discharge the
batter y to less than 50%.
Batter y Disposal
Dispose of the batter y in specific recycling boxes only after a complete discharge. Do not
put away the batter y in regular trash containers. Strictly follow your local regulations
regarding the disposal and recycling of batteries.
Batter y Use
Make sure the batteries are fully charged before each time of use.
Batter y Charging
The batter y will stop charging automatically when it is full. Disconnect the batteries from
the charger when fully charged.
Batter y Storage
1.Discharge the batter y to 40%-65% if it will NOT be used for over 10 days. This can greatly
extend the batter y life.
2.The batter y enters hibernation mode when voltage gets too low. Charge the batter y will
bring it out of hibernation.
3.Remove batteries from the stabilizer when not in use and store them in a specialized
container.
Batter y Maintenance
Never over-discharge, as this may lead to batter y cell damage.
Batter y performance may be affected if not used for a long time.
Charge and discharge the batter y once ever y 3 months to keep it active.
Batter y Disposal
If the batter y cannot be fully discharged, do not leave it in the recycling box, but contact a
professional batter y disposal/recycling agent for further assistance.
7 zhiyun-tech.com
Get to Know SMOOTH-Q
Check the product package before use, make sure that all items below have arrived with
the product. In case that any item is found missing, please contact ZHIYUN or your local
selling agent.
Mobile Clamp
Roll Axis
Thumb Screw
Bluetooth Indicator
Joystick
MODE
ON/OFF
1/4 Threaded Hole "
Payload：75g-200g
Horizontal Arm Adjusment Range：15mm(0.6 inch)
Mounting Clamp Supporting Range：58-85mm(2.3-3.3 inch)

Quick Start Guide

Mobile Clamp
Thumb Screw
Micro USB Port
Batter y Level
Indicator
Shifter Lever
Power Output Port
(for charging of
smartphone)
