Introducing Gimbal Control Modes - Zhiyun SMOOTH-Q User Manual

Pan
Following
Mode
Double Press MODE
Locking
Mode
Single Press MODE
Mode Switch Schematic Figure
Roll Axis
Tilt Axis
Pan Axis
Pan Following Mode:The
smartphone pans left/right
following the movement of the
stabilizer while the tilt and roll axes
are locked. Push the joystick up/
down allows manual control of the
tilt axis.

Introducing Gimbal Control Modes

Mode switch:
The stabilizer enters Pan Following Mode by default each
time when powered on. Switch into Locking Mode by single
pressing on the MODE button. Double press the MODE
button to enter the Following mode. Single press the MODE
button under the Following Mode will return to the previous
mode.Quick press MODE three times and the camera will
turn 180° along the pan axis while the active control mode
remains unchanged.
Following
See ZHIYUN's product training videos on
Mode
www.zhiyun-tech.com for more operation tips.
Roll Axis
Tilt Axis
Pan Axis
Locking Mode: This mode locks
movement of all three axes to keep
the camera still and stable. Push
the joystick up/down and left/right
allows manual control of the tilt
axis and pan axis.
Roll Axis
Tilt Axis
Pan Axis
Following Mode: The camera
p a n s a n d t i l t s f o l l o w i n g t h e
movement of the stabilizer. Push
the joystick left/right allows manual
control of the roll axis.
English
14
