S M O O T H - Q
. Getting Started
Download ZY Cami App
. Getting to Know SMOOTH-Q4
1. Fill Light Magnet
2. Phone Clamp
3. Gimbal Mode/Battery Level
Indicator Lights
4. Control Wheel
5. Handle
6. Gimbal Shaft
7. MODE Button
8. Joystick
9. Photo/Video Button
10. Tripod
11. Tilt Axis Motor
EN - Quick start guide
12. Tilt Axis Lock Clip
13. Pan Axis Motor
14. Type-C Charging /Firmware
15. Power Button
16. Roll Axis Motor
17. Phone Clamp Lock Clip
18. Extension Rod
19. Trigger Button
20. Wrist Strap Hole
21. Magnetic Fill Light
zhiyun-tech.com
Read Detailed
User Guide
Upgrade Port
(in SMOOTH-Q4 COMBO package)
Quick start guide
Watch Video
Tutorials
