HOW TO ADJUST THE DRIVE BELT
If the pedals slip while you are pedaling, even while
the resistance is adjusted to the highest level, the drive
belt may need to be adjusted.
To adjust the drive belt, you must remove the seat
post, the post knob, the post cover, the right pedal, the
right lock ring, and the right shield as described below.
To remove the Seat Post (10), loosen the Post Knob
(18) a few turns, pull the Post Knob outward, and
remove the Seat Post. Then, using an adjustable
wrench, remove the Post Knob.
10
16
Using a standard (flat) screwdriver, release the tabs
along the bottom edge of the Post Cover (16) and
remove it. Then, using an adjustable wrench, turn the
Right Pedal (29) counterclockwise and remove it.
Using a standard (flat) screwdriver, release the tabs
around the edge of the right Lock Ring (23), and then
remove it from the Right Shield (22).
18
22
29
23
See the EXPLODED DRAWING on page 23.
Remove all of the screws from the Left and Right
Shields (21, 22); there are two sizes of screws in
the shields—note which size of screw you remove
from each hole. Then, gently remove the Right Shield.
Loosen the Adjustment Screw (47). Then, tighten the
Idler Screw (45) until the Drive Belt (59) is tight.
When the Drive Belt (59) is tight, tighten the
Adjustment Screw (47).
Then, reattach the left and right shields, the right lock
ring, the right pedal, the post cover, the post knob, and
the seat post.
20
59
47
45
