9. Orient the Seat Post (10) as shown. Loosen the
Post Knob (18) a few turns, pull it outward, and
insert the Seat Post into the Frame (1).
Then, slide the Seat Post (10) upward or down-
ward to the desired position, and release the
Post Knob (18) into one of the adjustment holes
in the Seat Post. Move the Seat Post upward
or downward slightly to make sure that the
Post Knob is engaged in one of the adjust-
ment holes in the Seat Post. Then, tighten the
Post Knob.
10. See the inset drawing. Remove the Carriage
Knob (15) from the Seat Carriage (11).
Next, set the Seat Carriage (11) on the Seat Post
(10) and hold it in place.
Insert the Carriage Knob (15) upward into the
Seat Post (10), and tighten the Carriage Knob
into the Carriage Bracket (14) inside the Seat
Carriage (11). Make sure that the Carriage
Knob is tightened into the Carriage Bracket.
9
Adjustment
Holes
10
1
10
11
10
15
10
18
10
14
15
11
