Restrictions and Notes
Positioning the GPIB Connector for the GPIB-F-LPE,
GPIB-FL-LPE
Although the GPIB connector on the GPIB-F-LPE, GPIB-FL-LPE exceed the specified bracket opening
size for Low Profile size by approximately 1.5mm, this rarely causes a problem in practice.
CN-GP/C
GPIB Connector
Figure 6.1. Position for Installing the GPIB Connector
GPIB-F-LPE, GPIB-FL-LPE
1.5mm
Size of opening stipulated in
Low Profile size specifications
6. About Hardware
55
