NARDA PMM 6600 User Manual

Rf power meter 10 khz - 1 ghz

Advertisement

Quick Links

http://www.narda-sts.it
User's Manual
SERIAL NUMBER OF THE INSTRUMENT
You can find the Series Number on the rear panel of the instrument.
Series Number is in the form: 0000X00000.
The first four digits and the letter are the Series Number prefix, the last five digits are
the Series Number suffix. The prefix is the same for identical instruments, it changes
only when a configuration change is made to the instrument.
The suffix is different for each instrument.
Document 6600EN-00705-1.10 – Copyright © NARDA 2007
Sales & Support:
NARDA
Via Leonardo da Vinci, 21/23
Safety
20090 Segrate (MI) -
Test
Tel.: +39 02 2699871
Solutions
Fax: +39 02 26998700
S.r.l. Socio Unico
PMM 6600
RF POWER METER
10 kHz - 1 GHz
Manufacturing Plant:
Via Benessea, 29/B
17035 Cisano sul Neva (SV)
ITALY
Tel.: +39 0182 58641
Fax: +39 0182 586400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMM 6600 and is the answer not in the manual?

Questions and answers

Summary of Contents for NARDA PMM 6600

  • Page 1 The first four digits and the letter are the Series Number prefix, the last five digits are the Series Number suffix. The prefix is the same for identical instruments, it changes only when a configuration change is made to the instrument. The suffix is different for each instrument. Document 6600EN-00705-1.10 – Copyright © NARDA 2007...
  • Page 2 Union (2002/96/EC) and belongs to Category 9 (Monitoring and Control Instruments). You can return the instrument to us free of charge for proper environment friendly disposal. You can obtain further information from your local NARDA Sales Partner or by visiting our website at www.narda-sts.it .
  • Page 3: Table Of Contents

    3 Operating Page 3.1 Introduction..............3.2 Serial port connection..…........3.2.1 Typical PMM 6600 display……………....3.3 To connect PMM 6600 input to source………………. 3.3.1 PMM 6600 off or disconnected……………………... 4 Maintenance and Servicing Page 4.1 Return for service............4.2 Equipment cleaning.......…....
  • Page 4 Figures Figure Page Front panel........…...……..Rear panel.........…………..Interconnection block diagram......Tables Table Page Technical Specification…………………...…… Contents...
  • Page 5 • Ground connections must not be interrupted intentionally; • To prevent the possible danger of electrocution, do not remove any covers, panels or guards installed on the device, and refer only to NARDA Service Centers if maintenance should be necessary;...
  • Page 6 E C C o n f o r m i t y C e r t i f i c a t e (in accordance with the directives: EMC 89/336/EEC and low voltage 73/23/EEC) This is to certify that the product: PMM 6600 RF Power Meter 10 kHz - 1 GHz Produced by: NARDA S.r.l.
  • Page 7: Documentation

    Serial Number prefix may be different from those documented in this manual. The PMM 6600 is a simple and easy to use RF power measurement 1.3 Introduction solution. It has been mainly designed for EMC application in order to calibrate CDNs and CLAMPs for conducted and induced immunity tests, or to measure input power forwarded to antennas or GTEMs cells.
  • Page 8: Main Specifications

    Table 1-1 lists the PMM 6600 performance specifications. The following conditions apply to all specifications: • The PMM 6600 needs at least a 15 minutes warm-up before operation. • The room temperature shall be 10° to 40° C. TABLE 1-1 Technical specifications...
  • Page 9: Front And Rear Panel

    1.6 Front and rear panel Fig. 1-1 Front Panel Fig. 1-2 Rear Panel General information...
  • Page 10: Functional Description

    1.7 Functional PMM 6600 philosophy is based on high technology approach to offer high performance into small instrument. description The block diagram give you an idea on how it works. Fig. 1-3 Interconnection block diagram The instrument should be stored in a clean and dry environment.
  • Page 11: Initial Inspection

    • Altitude < 4’000 meters 2.6 Hardware Installation PMM 6600 is delivered ready to use. Remove the Power Meter from his cardboard box and connect RS 485 cable to rear panel plug. Plug the opposite side of RS 485 cable in PMM 6485 interface module and connect RS 232 cable between PMM 6485 and PC serial port.
  • Page 12: Software Installation

    2.7 Software Installation PMM 6600 is provided with a simple Windows™ driver. This driver have to be installed before to use it. The procedure is: - insert the diskette into drive A; - invoke the program manager; - run the command File Run A:\Setup.
  • Page 13: Installation Completed Message

    When installation is complete you get the following window: 2.7.2 Installation completed message 2.7.3 PMM 6600 icon Click OK to confirm the installation. Then the driver will show the PMM 6600 icon. Click PMM 6600 icon to run the software. Installation...
  • Page 14 This page has been left blank intentionally Installation...
  • Page 15: Serial Port Connection

    By default software driver recognizes automatically PMM 6600 if connection connected at COM 2 serial port. If this serial port is already busy, click once on PMM 6600 icon and open Property window from Program Manager in Windows 3.11, or select the...
  • Page 16: Pmm 6600 Off Or Disconnected

    3.3.1 PMM 6600 off or disconnected If the power meter is off or disconnected from the PC you get the following message: Check all connections and DC power supply; then try again. Operating...
  • Page 17: Equipment Cleaning

    4 - Maintenance and Servicing If the instrument should be returned to NARDA for service, please 4.1 Return for service complete the service questionnaire enclosed with the User Manual and attach it to the instrument. To minimize the repair time, be as much specific as possible when describing the failure.
  • Page 18 This page has been left blank intentionally Maintenance and Servicing...
  • Page 19: Calculation Of Power

    At the enquiry “ #Pmp “ the 6600 answers “ 03H ” and “ 3FH” (3 and 63 in decimal), then the CW power (or the power without modulation correction) ∗ − 3 256 63 1000 = − 16 9 Document 6600EN-00705-1.10 - © NARDA 2007 Serial Communication Protocol...
  • Page 20 This page has been left blank intentionally Serial Communication Protocol...
