NARDA EHP-50F User Manual
  1. Manuals
  2. Brands
  3. NARDA Manuals
  4. Measuring Instruments
  5. EHP-50F
  6. User manual

NARDA EHP-50F User Manual

Electric and magnetic field probe - analyzer from 1 hz up to 400 khz
Hide thumbs
Table of Contents

Advertisement

Quick Links

NARDA
Safety
Test
Solutions
S.r.l. Socio Unico
http://www.narda-sts.it
User's Manual
ELECTRIC AND MAGNETIC
FIELD PROBE - ANALYZER
SERIAL NUMBER OF THE INSTRUMENT
You can find the Serial Number on the bottom cover of the instrument.
The Serial Number is in the form: 000XY00000.
The first three digits and the two letters are the Serial Number prefix, the last five
digits are the Serial Number suffix. The prefix is the same for identical instruments,
it changes only when a configuration change is made to the instrument.
The suffix is different for each instrument
Document EHP50FEN-50501-1.63 – Copyright © NARDA 2015
Sales & Support:
Via Leonardo da Vinci, 21/23
20090 Segrate (MI) - ITALY
Tel.: +39 02 2699871
Fax: +39 02 26998700
EHP-50F
From 1 Hz up to 400 kHz
Manufacturing Plant:
Via Benessea, 29/B
17035
Cisano sul Neva (SV)
Tel.: +39 0182 58641
Fax: +39 0182 586400
