User's Manual
SERIAL NUMBER OF THE INSTRUMENT
You can find the Serial Number in a side of the box.
Serial Number is in the form : 0000X00000.
The first four digits and the letter are the Serial Number prefix, the last five digits are
the Serial Number suffix. The prefix is the same for identical instruments, it changes
only when a configuration change is made to the instrument.
The suffix is different for each instrument.
Document PL01EN-00708 – Copyright © NARDA 2020
Sales & Support:
NARDA
Via Rimini, 22
Safety
20142 - Milano (MI)
Test
Tel.: +39 02 581881
Solutions
Fax: +39 02 58188273
S.r.l. Socio Unico
PMM PL-01
PULSE LIMITER
Manufacturing Plant:
Via Benessea, 29/B
17035 - Cisano sul Neva (SV)
Tel.: +39 0182 58641
Fax: +39 0182 586400

Advertisement

loading
Need help?

Need help?

Do you have a question about the PMM PL-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NARDA PMM PL-01

  • Page 1 The first four digits and the letter are the Serial Number prefix, the last five digits are the Serial Number suffix. The prefix is the same for identical instruments, it changes only when a configuration change is made to the instrument. The suffix is different for each instrument. Document PL01EN-00708 – Copyright © NARDA 2020...
  • Page 2 Union (2002/96/EC) and belongs to Category 9 (Monitoring and Control Instruments). You can return the instrument to us free of charge for proper environment friendly disposal. You can obtain further information from your local NARDA Sales Partner or by visiting our website at www.narda-sts.it .
  • Page 3 Contents Page Safety recommendations and instructions.………..EC Declaration of Conformity …………………………… 1 General Information Page 1.1 Documentation…….…………………………………… 1.2 Introduction to PL01 Pulse Limiter……………... 1.3 Insertion loss………………......……... 1.4 Environment………….........….... 1.5 Return for service………….......…...…..2 Main Specification Page 2.1 Main Specification ………………………………………. 2-1 3 Preparation for use Page 3.1 Introduction….……………………………………………...
  • Page 4 Figures Figure Page PMM PL01 Typical frequency response………………. Tables Table Page Main Specification…………………….….……………… Contents...
  • Page 5 • To prevent the possible danger of electrocution, do not remove any covers, panels or guards installed on the device, and refer only to NARDA Service Centers if maintenance should be necessary; • To maintain adequate protection from fire hazards, replace fuses only with others of the same type and rating;...
  • Page 6 EMC: EN 61326-1 (undated reference, applies to all editions) declares, under its sole responsibility, that the product: PMM PL-01 Pulse Limiter conforms with the essential requirements of the Low Voltage Directive 2014/35/EU, of the EMC Directive EMC 2014/30/EU and of the RoHS directive 2011/65/EU.
  • Page 7 1 - General Information Enclosed with this manual are a service questionnaire to send back to 1.1 Documentation NARDA in case that equipment service is needed. 1.2 Introduction to The Pulse Limiter PL01 is an accessory designed to protect the input circuit PL01 Pulse Limiter of a Receiver against high energy interfering voltage pulses.
  • Page 8 -25° to + 70° C • Humidity < 95% relative If the instrument should be returned to NARDA for service, please complete 1.5 Return for service the service questionnaire enclosed with the Operating Manual and attach it to the instrument.
  • Page 9 Frequency response: 0,5 W Max permissible input power: RF input: BNC female connector RF output: BNC male connector Rated temperature: 0 to + 45 C - 25 to + 70 C Storage temperature: Document PL01EN-00708 - © NARDA 2020 Main specifications...
  • Page 10 This page has been intentionally left blank Main specifications...
  • Page 11 Verify the accessories availability in the shipping container referring to the accessories check list enclosed with the Operating Manual. Notify any damage to the carrier as well as the NARDA Representative. Inspect the Pulse Limiter for damage before use. 3.3 Initial inspection...
  • Page 12 The male BNC plug of the Pulse Limiter must be connected to the RF input 3.4 Preparation for use socket of the EMI test receiver. Pulse Limiter usage under some condition may affect measurement result in respect to test signal characteristics. When test signal has very high pulses the Pulse Limiter may reach saturation and affect measurement accuracy.
  • Page 13 Moreover, we are continuously improving our quality, but we know this is a never ending process. We would be glad if our present efforts are pleasing you. Should one of your pieces of NARDA equipment need servicing you can help us serve you more effectively filling out this card and enclosing it with the product.
  • Page 14 Suggerimenti / Commenti / Note: Suggestions / Comments / Note:...
