9.7

Custom Stream Formatting

A serial port on the 880 main board can be configured to stream scale data out. The format of the streamed data
can be configured for the COM and USBCOM ports indiviually through the front panel using the tokens in
Table 9-5. Configuration will be available for stream output tokens through EDP commands only; no front panel
access will be provided.
Format Identifier
<P[G | N | T]>
<U[P | S | T]>
<M[G | N | T]>
<S>
<B [–]n,...>
B0
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
84 880 Installation Manual
Defined By
STR.POS Polarity. Outputs the positive or negative polarity label for the current or
STR.NEG specified (Gross/Net/Tare) weight on the source scale. Possible values are
SPACE, NONE, + (for STR.POS), or – (for STR.NEG)
STR.PRI Units. Outputs the primary, secondary, or tertiary* units label for the current or
STR.SEC specified (Primary/Secondary/Tertiary*) weight on the source scale.
STR.TER
STR.GROSS Mode. Outputs the gross, net, or tare label for the current or specified weight
STR.NET (Gross/Net/Tare) on the source scale.
STR.TARE
STR.MOTION Outputs the status for the source scale. Default values and meanings for each
STR.RANGE status:
STR.OK STR.MOTION
STR.INVALID STR.RANGE
STR.ZERO STR.OK
STR.INVALID
STR.ZERO
See Bit fields. Comma-separated sequence of bit field specifiers. Must be exactly 8
descriptions bits. Minus sign ([–]) inverts the bit.
below
- Always 0
- Always 1
Configuration =1 if even parity
Dynamic =1 if MODE=NET
Dynamic =1 if COZ (center of zero)
Dynamic =1 if motion
Dynamic =1 if displayed gross or net weight is negative
Dynamic =1 if out of range
Dynamic =1 if secondary/tertiary*
Dynamic =1 if tare in system
Dynamic =1 if tare is keyed
Dynamic =00 if MODE=GROSS
=01 if MODE=NET
=10 if UNITS=TERTIARY*
=11 (not used)
Dynamic =00 if UNITS=PRIMARY
=01 if UNITS=PRIMARY
=10 if UNITS=PRIMARY
=11 (note used)
Configuration =00 (not used)
=01 if current DSPDIV=1
=10 if current DSPDIV=2
=11 if current DSPDIV=5
Configuration =00 (not used)
=01 if primary DSPDIV=1
=10 if primary DSPDIV=2
=11 if primary DSPDIV=5
Table 9-5. Custom Stream Format Identifiers
Description
M In motion
O Out of range
<space> OK
I Invalid
Z COZ
