Code Contents
1930 Paper feeder 4 EEPROM
error
When writing the data, read
and write data does not match
4 times in succession.
2000 Main motor startup error
Main motor is not stabilized
within 2 s since the motor is
activated.
2010 Main motor steady-state
error
After main motor is stabilized,
the ready signal is not ready
for 2 s continuously.
Related parts
PF main PWB
(EEPROM)
Main motor
Connect right PWB Replace the cconnect right PWB (see page
2-2-12).
Control PWB
Main motor
Connect right PWB Replace the connect right PWB (see page 2-
2-12).
Control PWB
1-4-27
2NM/2NX/2NY/2NZ/2P0/2P6
Check procedures/
corrective measures

1. Confirm that the wiring connector is

firmly connected and, if necessary,
connect the connector all the way in.
2. Replace the PF main PWB.
1. Confirm that the wiring connector is
firmly connected and, if necessary, con-
nect the connector all the way in.
Main motor and connect right PWB
(YC10)
Connect right PWB and control PWB
(YC29)
2. If the wiring is disconnected, shorted or
grounded, replace the wiring.
3. Replace the main motor (see page 1-5-
94).
1. Check the control software and upgrade
to the latest, if necessary.
2. Replace the control PWB and check for
correct operation (see page 2-2-12).
1. Check the drive gear can rotate or they
are not unusually loaded and, if neces-
sary, replace.
2. Confirm that the wiring connector is
firmly connected and, if necessary,
connect the connector all the way in.
Main motor and connect rightl PWB
(YC10)
Connect right PWB and control PWB
(YC29)
3. If the wiring is disconnected, shorted or
grounded, replace the wiring.
4. Replace the main motor (see page 1-5-
94).
1. Check the control software and upgrade
to the latest, if necessary.
2. Replace the control PWB and check for
correct operation (see page 2-2-12).
