Setup of a toner container
1. Push the release button down and open
the front cover.
2. Rotate the toner container lock lever to
the lock position and then the unlock
position.
Front cover
Lock position
Toner container
lock lever
1-2-5
2NM/2NX/2NY/2NZ/2P0/2P6
Release button
Figure 1-2-5
Unlock position
Figure 1-2-6
