(2-1) Detaching and refitting the laser scanner unit
Procedure
1. Remove the image scanner unit.
2. Remove two screws.
3. (50/60 ppm model only)
Slide the right inner spacer and the left
inner spacer forward and then remove it
upward.
4. Remove two screws.
5. Remove the center stay cover.
Screw
Left inner
spacer
Figure 1-5-40
Screw
Figure 1-5-41
1-5-25
2NM/2NX/2NY/2NZ/2P0/2P6
Right inner
spacer
Screw
Eject unit cover
Screw
