10.09 Zero speed
RO
ô 0 or 1 ð
0 = speed not zero
1 = zero speed
Set if speed feedback 03.02 < zero speed threshold 03.23. Refer to
10.01 and 10.02
10.10 Armature voltage clamp active
RO
ô 0 or 1 ð
0 = clamp not active
1 = clamp active
Set when the armature voltage clamp is activated. Prevents the voltage
from increasing further. Refer to 03.15.
10.11 Phase rotation
RO
ô 0 or 1 ð
0 = L1 L3 L2
1 = L1 L2 L3
Rotation is detected from L1, L2, L3.
NOTE that connection to E1 and E3 must also be correct - refer to
Figure 6-2 and Figure 6-3.
10.12 Drive healthy (normal)
RO
ô 0 or 1 ð
1 = Drive is powered-up and has not tripped.
10.13 Alarm (I x t)
RO
ô 0 or 1 ð
0 = no alarm condition present
1 = alarm condition present, impending sustained-overload trip
Indicates that the Drive is in an overload condition and will eventually trip
on sustained overload 10.18 if the overload condition is not removed.
The time taken to trip is dependent on the settings of 05.06 and 05.07
and on the magnitude of overload.
Visual indication that the alarm has been actuated is given by the Alarm
LED (flashing). External signal also provided through status logic output
ST3 to terminal TB2-17 provided that source parameter 09.19 is at its
default value.
