INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS
KESSEL rainwater pumping system
Aqabull
®
with switch unit Aqatronic S/K
€
Aqabull
with switch unit Aqatronic S
€
Aqabull
with switch unit Aqatronic K
Art.#. 85101
The installation and service of this unit should be carried
out by a licensed professional servicer
company - telephone number
Edition 2010/10
Date
town
Art.#. 85 101
Art.#. 85 201
Product advantages
Plug-in compact unit
Installation below the
backwater level possible
Fully automatic operation
With integrated on-demand
drinking water feeding
unit tested according to
DIN 1989
Smooth pump operation
High operational safety
Nationwide service network
stamp
ID-Number 010-200EN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kessel 85 101
Summary of Contents for Kessel 85 101
- Page 1 INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS KESSEL rainwater pumping system Aqabull ® with switch unit Aqatronic S/K € Aqabull with switch unit Aqatronic S Art.#. 85 101 € Aqabull with switch unit Aqatronic K Art.#. 85 201 Product advantages Plug-in compact unit...
- Page 2 Dear customer, we are pleased that you have decided to buy a KESSEL product. The entire system was subjected to a stringent quality control before it left our factory. Nevertheless, please check im- mediately whether the system has been delivered to you complete and undamaged. In case of any transport damage, please refer to the instructions in the chapter "Warranty"...
-
Page 3: Table Of Contents
Table of contents ....................Page 1. Safety instructions Application ..............Page Plant description............Page 2. General Functional description ..........Page Dimensions and weight ..........Page Control unit..............Page 3. Technical Data Floating switch ............Page 3-way-switch-over-valve ..........Page Automatic pressure switch ..........Page Pump................Page Wall mounting .............Page 10 Connection to emergency overflow......Page 10 4. -
Page 4: Safety Instructions
1. Safety Insructions The personnel for assembly, operation, maintenance and repair must possess the appropriate qualifi- cation for this type of work. The area of responsibility, the authority and the supervision of personnel must be exactly regulated by the operator. The operational safety of the system supplied is only guaranteed when it is used in accordance with the regulations. -
Page 5: Application
2.1 Area of application: ® almost no servicing. It is used for supplying service water to toilets, washing clothes and cleaning. The KESSEL rainwa- single family and multi-family homes. The automatic feeding ter pumping system Aqabull® has been designed for free-... -
Page 6: Plant Description
2. General The KESSEL rainwater pumping system Aqabull with switch unit Aqatronic S or Aqatronic K is made up of the following assem- 2.2 Plant description: ® blies: Basic unit Pump unit 1.1 Drinking water feeding tank 3.1 Multi-stage rotary pump 1.2 Cover... -
Page 7: Functional Description
The maintenance- automatic drinking water feeding. free automatic pressure switch has an automatic switch The KESSEL-Switch unit Aqatronic S controls the on/off function geared towards demand which absorbs any drinking water feeding through a floating switch installed in ®... -
Page 8: Dimensions And Weight
3. Technical Data 3.1 Dimensions and weight: 76 80 Drinking water connection Trinkwasser- anschluss Suction connection Sauganschluss Pressure connection Druckanschluss Emergency overflow Notüberlauf Pipe routing Weight empty approx. 28 kg Operation weight (full with water) approx. 45 kg Protective rating IP 55 The technical data can be found in the enclosed original ope- Mains connection cable... -
Page 9: Pump
3. Technical Data Voltage / Frequency 230 V AC / 50 Hz Permanent operation possible 3.6 Pump Power consumption 800 W Suction connection 1ʼʼ inner thread Protective rating IP 55 Pressure connection 1ʼʼ inner thread Insulation class Materials rust-free Speed 2900 min Operating temperature max. -
Page 10: Wall Mounting
Take the KESSEL rainwater pumping system Aqabull® out of the packaging and remove the transportation safety devi- ces. The accessories are in the same box. The KESSEL rain- water pumping system Aqabull® has been designed in such a way that the inlet and pressure connection for the service water can be installed on the left and/or right as required. -
Page 11: Drinking Water Connection
We recommend the KESSEL suction fine/coarse filter, 4.4 Connecting the pump Connect the pump to the service water network. The user floating, art. -
Page 12: Electrical Connection
® A double socket with earthed contacts is required for instal- S ). ® lation of the KESSEL rainwater pumping system Aqabull ® Fuse 16 A slow-blow with residual current breaker 30 mA. 6. Initial operation This way, the system is reliably ventilated and is ready for im- mediate operation. -
Page 13: Initial Operation
To reduce foreign matter entering the feeding tank, the Evacuation plug area around the system must be cleaned at regular intervals. If the KESSEL rainwater pump system Aqabull i s to be We recommend that you conclude a servicing contract with ®... -
Page 14: Maintenance
The chapter "Safety instructions" must be heeded! Repairs and maintenance work on the electrical system and the pump unit may only be carried out by a qualified electrician or by the KESSEL Customer Services department. Possible faults Motor does not start up... -
Page 15: Spare Parts
9. Spare parts and accessories 9.1 Spare parts 210-075 Assembly switch unit t Aqatronic S 210-264 Bearing buffer 017-041 Washer 210-069 + Floating switch Assembly switch unit Aqatronic K 210-315 017-184 Countersunk screw 134-025 PT screw 017-046 234-003 Basic tank 182-565 Pipe duct seal 234-002... - Page 16 DN 150 made of plastic With two seals each DN 32/DN 40, one seal DN 50 and one blind plug each DN 40 and DN 50. Suitable for KESSEL rainwater pumping sy- stems Aqabull®/Aqadive® and rainwater fil- ters with/without back-flushing unit...
- Page 17 Pack palette KESSEL leak probe 80 085 Optical probe with 5 m cable for monito- ring the level of the water in the feeding tank of the KESSEL rainwater pumping system Aqabull / Aqadive with switch ® ® unit Aqatronic K.
- Page 18 10 m control pipe and pneumatic universal tank contents gauge for all tank sizes and heights. Art.# 85 020 KESSEL Staufix ® flood slide, 72 100 ø 110 Flap closes automatically...
-
Page 19: 10. Warranty
Note: Only the manufacturer may open sealed components or warranted for a period of 24 month. This warranty period be- gins on the day the product is shipped form KESSEL to its cu- screw connections. Otherwise, the warranty may become null stomer. - Page 21 __________________________________________________________ Planner __________________________________________________________ Address __________________________________________________________ Telephone / Fax __________________________________________________________ Contracted plumbing company __________________________________________________________ Address __________________________________________________________ Telephone / Fax __________________________________________________________ KESSEL-Commissions no.: System operator /owner __________________________________________________________ Address __________________________________________________________ Telephone / Fax __________________________________________________________ User __________________________________________________________ Address __________________________________________________________ Telephone / Fax __________________________________________________________ Person of delivery...
- Page 22 Notice...
- Page 23 Notice...
- Page 24 Everything for drainage Backwater valves and cleanouts Grease separators Oil/fuel and coalescence Polymer and Ecocast drains separators Volatile liquid traps Inspection chambers Lifting stations, pumps, warning Custom projects for and control units industrial applications Rainwater management systems...
