ISDT Q6 PLUS Operating Instructions Manual page 14

Tztufn!Efgbvmu
Long press the shuttle key in standby interface to make the system default menu pop up, and
the items are as follows:
Max Input Power
Min Input Voltage
Backlight
Volume
About
Save
Cancel
Max input power limitation: if the input power fails to reach the max working power (160W), set
this parameter based on the actual output capacity of input power in order to protect it and
enable the charger to work stably. For example, as the power connected is 12V/10A, the value of
this item should be 120W.
Min input power: this item can protect the battery from excessive discharge since it's used as
input power. If the charger tests that the input voltage is lower than the default value, all tasked
in operation would be terminated and there would be a warning of low voltage. For example, if
a 6S Lipo battery is used as the input power source, the value of the item should be 21V to
protect the battery from excessive discharge.
Buzzer volume: the default is OFF, the operation sound would be blocked, but not the sound of
error warning.
25
Limited between 50 - 330 W
Limited between 7 - 32 V
Three gears: high, medium, low
Three gears: high, medium, low; and o
See system software information
Save altered system default items
Cancel all alteration and exit system default menu
