iES28TG/iES28GF User Manual
H
ardware Installation
3.1 Rack-mount Installation for iES28GF
The switch c a n b e rack-mounted using the hardware provided.
To mount the switch:
Step 1: Install left and right front mounting brackets to the switch using 4 M3 screws on each side
(screws provided with the switch).
Step 2: Place the switch in the rack and mount to the rack using the rack screws.
Note: You can install the brackets either in the front or at the rear depending on your management
requirements. Remember when installing the brackets at the front; use the four screw holes at the top
and bottom. When installing the brackets on the back sides, use the four screw holes at the top and
middle.
iS5 Communications Inc.
16
