4. Attach the wall plate using the provided screws. See figure 3.
J-box
Back plate
Back plate
Screw
Screws
Screws
Figure 3. Mount wall plate
5. Reattach the cover to the wallplate. See figure 4.
Figure 4. Reattach cover to wall plate
