BUILDING
WLAN Router
When using Access Points and appropriately polarized antennas in accor-
dance with IEEE 802.11n two wireless links can be established simultaneously
between the end points of a point-to-point connection. This allows higher
data throughput to be achieved or greater distances to be covered than when
using other standards.
BUILDING
MIMO AP 802.11n
Depending on the WLAN standard and WLAN antenna being used, the follo-
wing data-throughput rates can be achieved::
Access Point
802.11n indoor AP
802.11n indoor AP
802.11n outdoor AP
802.11n outdoor AP
ANTENNA
POLARIZATION
DIVERSITY
Antenna
Directional antenna with 9° beam
spread, surge protection, 10m cable
Directional antenna with 9° beam
spread, surge protection, 10m cable
Directional antenna with 9° beam
spread, surge protection, 2m cable
Directional antenna with 9° beam
spread, surge protection, 2m cable
LANCOM L-300 Access Point series
Chapter 5: Advanced wireless LAN configuration
Data throughput
brutto 240Mbps
brutto 15Mbps
brutto 240Mbps
brutto 15Mbps
BUILDING
ANTENNA ACCESS POINT
BUILDING
ANTENNA ACCESS POINT
BUILDING
POLARISATION
MIMO AP 802.11n
DIVERSITY
Range
1km
8,9km
2,1km
18km
