º
LANCOM L-315agn
dual Wireless
³
·
»
¿
´
²
º
The reset switch has two different functions depending on the length of time
that it is pressed:
Reset button functions
The reset button offers two basic functions—boot (restart) and reset (to the
factory settings)—which are called by pressing the button for different
lengths of time.
It is not always possible to install a device under lock and key. There is conse-
quently a risk that the configuration will be deleted by mistake if a co-worker
presses the reset button too long. You can define the behavior of the reset but-
ton with a setting in WEBconfig (LCOS menu tree
Reset switch
I
DC 12 V
ETH 4
ETH 3
»
Voltage switch
Connection for the included power adapter
Switch with four 10/100Base-Tx connections
WAN port
USB connection
ISDN/S
port
0
Serial configuration port
Reset switch
Restarting the device (soft reset) – push the button for less than five
seconds. The device will restart.
Resetting the configuration (hard reset) – push the button for more
than five seconds. All the device's LEDs will light up green and stay
on. As soon as the reset switch is released, the device will restart with
factory default settings.
LANCOM L-300 Access Point series
WAN
USB
ETH 2
ETH 1
¿
´
Chapter 2: Installation
ISDN-S0
Config (COM)
Reset
²
º
Setup
Config):
29
