c o n n e c t i n g
LANCOM L-322agn
Dual Radio Access Point with MIMO technology
Two integrated 11n radio modules for simultaneous 2.4- and 5 GHz wireless network
operations
Power supply via IEEE 802.3af PoE
Separation of user groups by Multi- SSID and VLAN
Four RSMA connectors for special applications requiring external antennas
y o u r
b u s i n e s s

Advertisement

loading

Related Manuals for Lancom L-322agn

Summary of Contents for Lancom L-322agn

  • Page 1 LANCOM L-322agn Dual Radio Access Point with MIMO technology Two integrated 11n radio modules for simultaneous 2.4- and 5 GHz wireless network operations Power supply via IEEE 802.3af PoE...
  • Page 2 More Performance The 802.11n standard includes several mechanisms such as MIMO, 40 MHz channels, packet aggregation, and block acknowledgement which significantly increase the amount of bandwidth available for user applications. With throughput rates up to 300 Mbps, this represents a greater than five- fold increase over the performance of 802.11a/g networks Better and Reliable Coverage.

  • Page 3: Bandwidth Limitation

    LANCOM L-322agn Scope of features: as of LCOS version 8.5x WLAN Frequency band 2.4 GHz and 5 GHz 2400 - 2483.5 MHz (ISM) and 5150- 5825 MHz (depending on country- specific restrictions) Data rates 802.11a/ h 54 Mbps (fallback to 48, 36 , 24, 18, 12, 9, 6 Mbps, Automatic Rate Selection), fully compatible with TPC (adjustable power output) and DFS (automatic channel selection, radar detection) according to ETSI EN 301 893 V.1.5.1., EN 302 502...
  • Page 4 LANCOM L-322agn Scope of features: as of LCOS version 8.5x WLAN Background scanning Detection of rogue AP's and the channel information for all WLAN channels during normal AP operation. The Background Scan Time Interval defines the time slots in which an AP or Router searches for a foreign WLAN network in its vicinity.
  • Page 5 LANCOM L-322agn Scope of features: as of LCOS version 8.5x Security Intrusion Prevention Monitoring and blocking of login attempts and port scans IP spoofing Source IP address check on all interfaces: only IP addresses belonging to the defined IP networks are allowed...
  • Page 6 LANCOM L-322agn Scope of features: as of LCOS version 8.5x Interfaces 10/100/1000 Base- TX, autosensing, auto node hub, PoE compliant with IEEE 802.3af 1st LAN port 10/100Base- TX, autosensing, auto node hub, PoE compliant with IEEE 802.3af DSL over LAN (DSLoL) The LAN port can (even parallel to LAN mode) be used as a WAN port for connecting external DSL modems (PPPoE) or external routers.
  • Page 7 LANCOM L-322agn Scope of features: as of LCOS version 8.5x Management SSH & Telnet client SSH- client function compatible to Open SSH under Linux and Unix operating systems for accessing third- party components from a LANCOM router. Also usable when working with SSH to login to the LANCOM device. Support for certificate- and password- based authentication.

  • Page 8: Item Numbers

    LANCOM L- 322agn dual Wireless 61533 LANCOM L- 322agn dual Wireless UK 61534 LANCOM L- 322agn dual Wireless 10- 61537 piece bulk www.lancom.eu LANCOM Systems GmbH I Adenauerstr. 20/B2 I 52146 Wuerselen I Deutschland I E-Mail info@lancom.eu I Internet www.lancom.eu...
