HV Belt Drive Fan
Installation and Maintenance Instructions.
THESE INSTRUCTIONS MUST BE READ FULLY BEFORE COMMENCING INSTALLATION.
Owner / installer: The life of this apparatus and its efficiency will be increased if
its use and maintenance is carried out in accordance with these instructions and
current statutory requirements. The installation and initial adjustments should be
carried out by a qualified and competent technician. Hydor Limited should be
consulted before substituting or fitting parts from another manufacturer. It is the
responsibility of the installer to verify that the installation is in accordance with
the following standards and the owner is given the current User's Manual.
Any modifications to the fan or its installation, even the smallest
modification, change or elimination of security components or pieces that
influence the efficiency or loss of ventilation, will result in the CE Certification
and Hydor's warranty being cancelled.
Single Phase
Speed
Model
r/min
HV800
530
HV1000
600
HV1250
410
HV1250A
425
HV1250
425
HV1500
360
HV2000
375
Supply
Power
V-Ph-Hz
kw
230-1-50
0750
230-1-50
0750
230-1-50 1,100
230-1-50 1,100
230-1-50 1,500
230-1-50 1,500
230-1-50 1,500
FLC
Start
Blade
Amps
Amps
Mattl.
4.5
14.3
5.4
14.9
7.2
25.7
7.5
25.7
8.4
29.5
9.4
33.0
10.0
35.0
Weight
kg
st.st
31
st.st
40
st.st
50
ali.
50
st.st
52
st.st
55
st.st
75
HV Inst Issue 2: 18.06.15
incorrect
correct, m
Weight
kg incl.
Louvre
44
50
70
70
72
85
100
