EN
3.8
Signalling devices
FRIAMAT fusion units confirm certain sequences of operations by emitting an
acoustic signal (1, 2, 3, or 5 beeps). These signals mean the following:
1 beep means: Read barcode confirmed.
2 beeps mean: Fusion procedure ended.
3 beeps mean: Supply voltage too low / too high.
5 beeps mean: Error! See display!
INFORMATION
Adjust the volume!
The volume of these signals can be set to "high" or "low" in the "Basic Settings"
menu. See also Sections 5.3 and 6.2.6.
3.9
Technical details
Technical details*
Input voltage range
Frequency range
Input current
Output
Generator rated
output for fittings
d20–d160
d180–d900
Unit fuse
Housing
Connecting cable
Fusion cable
Barcode type
14
FRIAMAT Prime
AC 190 V – 250 V
44 Hz...66 Hz
AC 16 A max.
16 A slow blow
international protection IP 54 DIN EN 60529
protection class I DIN EN 60335-1
5 mm with contoured plug
4 m with fittings plug, ø 4 mm
code 2/5
interleaved according to
ANSI HM 10.8 M-1983
and ISO CD 13950/08.94
code 128 according to
ISO 12176-4
FRIAMAT Basic
3.5 kW
~ AC 5.0 kW
code 2/5
interleaved according to
ANSI HM 10.8 M-1983
and ISO CD 13950/08.94
