Bag 3.1, - Associated Electrics RC10B64D Manual

:: Center Gear Differential Build - Bag 2.1, 2.2, 2.3 - Step 3
:: Center Gear Differential Build - Bag 2.1, 2.2, 2.3 - Step 4
!
Tighten the
screws evenly in a
crossing order!
:: Steering Rack Build - Bag 3.1, 3.2 - Step 1
92004
B64
Steering
Rack
x2
91048
HD 8mm
Ball Stud
x3
92079
Shim
5x8.5x0.17
92083
Aluminum
Center Diff
Cap
92078
Diff Outdrive
O-Ring
92082
Gear Diff
Outdrives
4
2
1
31448
3
2.5x8mm
FHCS
92078
Diff
Gasket
x3
31521
2.5x8mm
BHCS
92005
Bellcrank
Input Arm,
18mm
92004
B64
Bellcrank
92077
Sun Gear,
Metal
x4
!
Tighten the
screws evenly in a
crossing order!
91048
HD 8mm
Ball Stud
31382
1mm
Shim
25215
M3
Locknut
Bellcrank
92077
Sun Gear
Pin
4
1
2
3
25187
3x14mm
BHCS
92004
B64
7
x4
31531
3x6mm
BHCS
92085
B64 Spur
Gear, 81T
x2
x4
91475
3x7x3mm
Bearing
x2
31382
1mm
Shim
