:: Hardware - 1:1 Scale View
Button Head (bhcs)
2x4mm (31510)
Aluminum (8545)
2.5x8mm (31521)
3x6mm (31531)
Aluminum (8550)
Titanium (91580)
3x8mm (31532)
Aluminum (8552)
Titanium (91581)
3x10mm (25211)
Aluminum (8554)
Titanium (91582)
3x12mm (89202)
Titanium (91583)
3x14mm (25187)
Titanium (91584)
3x16mm (89203)
Titanium (91585)
3x20mm (25188)
Titanium (91587)
3x24mm (89204)
Titanium (91589)
Cap Head (shcs)
1.6 x 5mm (91611)
2x5mm (31511)
Notes:
Flat Head (fhcs)
2.5x8mm (31448)
3x6mm (31541)
Aluminum (8551)
Titanium (91591)
3x8mm (25201)
Aluminum (8553)
Titanium (91592)
3x10mm (25202)
Aluminum (8555)
Titanium (91593)
3x16mm (25204)
Titanium (91596)
Set Screws
3x3mm (25225)
3x20mm (91737)
Shims and Washers
Servo Mount Washer (7337)
(.250 x .125 x .815)
FT Ballstud Washer, Aluminum
(0.5mm) (31381)
FT Ballstud Washer, Aluminum
(1mm) (31382)
FT Ballstud Washer, Aluminum
(2mm) (31383)
Ball Bearings
3x7x3mm (91475)
5x8x2.5mm (31400)
5x10x4mm (91560)
6x13x5 (91562)
10x15x4 (91563)
Ballstuds
Silver HD 4mm (91451)
FT Ti HD 4mm (91750)
Ti Nitride HD 4mm (91452)
HD 6mm (91047)
FT HD Ti 6mm (91751)
Ti Nitride HD 6mm (91118)
Silver HD 8mm (91048)
FT Ti HD 8mm (91752)
Ti Nitride HD 8mm (91119)
HD 10mm (91049)
FT Ti HD 10mm (91753)
Ti Nitride HD 10mm (91120)
Nuts (lock/plain)
M3 Nut (91477)
M3 Alum. Locknut, Blue (31550)
M3 Locknut, Black (25215
M3 Locknut w/Flange (25612)
FT 3mm Locknuts, Blue(25392)
M4 Locknut w/Flange (91148)
FT M4 Locknut, Blue (31551)
M4 Locknut, Serrated (91738)
