Assembly and Operating Instructions for Outback®
Drawings are not to scale.
Specifications subject to change
without prior notice.
•
For outdoor use only. Not for commercial use.
•
Read instructions before using the appliance. Failure to follow instructions could
result in death, serious bodily injury, and/or property loss.
•
Warning: accessible parts may be very hot. Keep young children and pets away.
•
Do not move the appliance during use.
•
Turn off the gas supply at the gas bottle after use.
•
Any modification of the appliance, misuse, or failure to follow the instructions may
be dangerous and will invalidate your warranty. This does not affect your statutory
WARNING
rights.
•
Retain these instructions for future reference.
•
Leak test annually, and whenever the gas bottle is removed or replaced. Check that
the hose connections are tight and leak test each time you reconnect the gas bottle.
•
For Flare-up control please refer to the 'OPERATION' section of this manual.
FOR YOUR SAFETY
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open barbecue lid or hood.
4.
If odour continues, discontinue use and
contact your local dealer.
Outdoor Kitchen BBQ
I100
1.
Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2.
A gas bottle not connected for use must not be
stored in the vicinity of this or any other
appliance.
FOR YOUR SAFETY
0359

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the I100 and is the answer not in the manual?

Questions and answers

Related Manuals for Outback I100

Summary of Contents for Outback I100

  • Page 1 Assembly and Operating Instructions for Outback® Outdoor Kitchen BBQ Drawings are not to scale. I100 Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use. • Read instructions before using the appliance. Failure to follow instructions could result in death, serious bodily injury, and/or property loss.
  • Page 2 I100B Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. Outback® CODE PART Outdoor Kitchen BBQ Warming Rack Cooking Grill Flame Tamer Trim Kit (left) Trim Kit (right) Trim Kit (back) Drip Tray M6x10 Bolt...
  • Page 3 I100B Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice.
  • Page 4 I100B Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 7 A Main burner control knobs B Back burner control knob...
  • Page 9 I100 Parts List Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’. Outback® CODE PART Outdoor Kitchen BBQ Barbecue Countertop Front Panel Double Drawers...
  • Page 10 I100 Parts Diagram Quantity varies according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
  • Page 11 I100 Hardware Reference Diagram Specifications subject to change without prior notice. M8x25 Wing Bolt 3PCS M8x45 Wing Bolt 8PCS M8x60 Wing Bolt 2PCS...
  • Page 12 I100 Assembly IMPORTANT! TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Phillips/Crosspoint screwdriver, • adjustable spanner or metric spanner set. Always wear protective gloves when assembly unit. Remove any internal component or packaging from the barbecue body. • Whilst every care is taken in the manufacture of this product, care must be taken during assembly in •...
  • Page 13 Top view Assemble the front panel by aligning the holes in the Front and Side panels and securing together using the Wing Bolts (B2x2pcs) to lock the top of front panel. Loosen the retaining bolts (do not to completely release/remove), then place the Cylinder Bracket (A10) in position by aligning the retaining bolts with the underside slots of cylinder bracket, and secure into place.
  • Page 14 Top view Carefully fit the bottom panel assembly into the base of module. Then secure using the two Wing Bolts (B2x2pcs) of both left/right Side Panels.
  • Page 15 Remove the retaining bolts from Door Handle (A6), then secure the Door Handle onto the door using the retaining bolts as shown. Remove the retaining bolts (8pcs) and L-shape plate (4pcs) from Double Drawers (A4), then fix the double drawers into the island module by screwing the retaining bolts through the L-shape plate.
  • Page 16 Put the Countertop (A2) onto the assembled island unit. Place the Bar Cabinet (A8) onto the Right Side Panel and fix using Wing Bolts (B3x2pcs).
  • Page 17 Place the Bar Countertop (A7) onto the Bar Cabinet (A8) and fix using Wing Bolts (B1x3pcs). Position the Barbecue (A1) onto the assembled island unit. WARNING: Be careful not to damage hose and regulator.
  • Page 18 Connect the hose and regulator assembly to the cylinder. WARNING: Check that connections are tight. Attention: the bar may also be assembled on the left side of the unit using the procedure when assembling the bar to the right side of the unit.

  • Page 19: Leak Testing

    1. Maximum diameter or breadth is 320mm. 2. Maximum height (regulator included) is 600mm. ASSEMBLY IS NOW COMPLETE. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE ALL JOINTS AND CONNECTIONS MUST NOW BE LEAK TESTED BEFORE USING THE BARBECUE.

  • Page 20: Important Information

    Important Information leak test. This is the only safe and sure way to detect any gas leaking from joints and connections of the barbecue after assembly. Please read these instructions carefully before assembly and use of your barbecue. Leak test annually, and whenever the gas bottle is removed or replaced.
  • Page 21 WARRANTY. In the case of replacing your Preparation Before Cooking original hose and regulator, please consult your To prevent foods from sticking to the cooking local gas dealer for the most suitable regulators surface, please use a long handled brush to and gas bottles.

  • Page 22: Warming Rack

    lighting hole on the right side of the is opened during cooking please allow extra barbecue body and place near rightmost time for the barbecue to regain its temperature and complete the cooking. Use the temperature burner porthole. gauge to monitor the heat of the barbecue. •...

  • Page 23: Flame Tamer

    out. The time between cleaning may need to be recommend that the unit be covered when left reduced if very fatty foods or cheap meat outside for any length of time, especially during products are being cooked. Failure to do this the winter months.

  • Page 24: Drip Tray

    Drip Tray Always rinse and allow to dry after cleaning. After every use, empty and clean the drip tray (and foil liner, if applicable) of any fat or food Fixings particles, using a plastic or wooden scraper if All screws and bolts, etc. should be checked necessary.

  • Page 25: Technical Specifications

    Technical Specifications NOTES: Heat Injector Burners Gas /Pressure Approval Input Size Main 14.8 Butane: 28-30mbar 0.95mm Burner Propane: 37mbar 0359 359BR665 Back Butane: 28-30mbar 0.97mm Burner Propane: 37mbar Gas Consumption: Main Burner: 1076g/hr Back Burner: 291g/hr Countries of Use: BE, CH, CY, CZ, ES, FR, GB, GR, IE, IT, LT, LU, LV, PT, 3+ (28-30/37) SK, SI Specifications subject to change without prior notice.

  • Page 26: Troubleshooting

    Troubleshooting Problem Possible Cause Solution Burner will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replaced Obstructions in burner Clean burner Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose is connected on Reconnect wire...
  • Page 27 OUTBACK® WARRANTY OUTBACK® barbecues are warranted for a period of one (1) year from the date of purchase to the original purchaser against defects in materials and workmanship, OUTBACK® will supply replacements for defective parts free of charge provided that: The product has not been used for trade, professional or hire purposes.
