Summary of Contents for Advantech ARK-1380
- Page 1 User Manual ARK-1380 Ultra Compact, Intel® ULV Celeron® M 1 GHz with PC Card Slot, 4 x USB, CRT & LVDS, 1 x LAN, 2 x COM, Fanless Embedded Computer...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
-
Page 3: Declaration Of Conformity
Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 4: Ordering Information
Intel ULV Celeron M 1GHz, 2 x Serial ports, PCMCIA,1 x LAN, 4 x USB 2.0, 2 x COM, 1 x VGA, 1 x LVDS,Ultra Compact, Fanless Embedded Box Computer ARK-1380-2S0A1E ARK-1380-1S0A1E with 512 MB DDR SDRAM, 1 GB Compact Flash Disk, pre-installed Windows CENET 5.0 Professional Plus and License ARK-1380-1M0A1E Intel Celeron M 600MHz, 2 x Serial ports, PCMCAI, 1 x LAN, 4 x USB 2.0, 2 x COM, 1 x VGA, 1 x LVDS, Ultra Compact, Fanless... -
Page 5: Table Of Contents
2.2.2 Jumper List and Settings ............11 Connectors....................12 Figure 2.1 ARK-1380 Front I/O Panel........12 Figure 2.2 ARK-1380 Rear I/O Panel ........12 ARK-1380 Front Side External I/O Connectors........13 2.4.1 COM Connector ................13 Figure 2.3 COM connector ............13 Table 2.1: COM Standard Serial Port Pin Assignments .... - Page 6 Figure 4.7 Remove the CF card anti-shock holder....37 Figure 4.8 Remove the CF card ..........38 Figure 4.9 Turn over the carrier board and remove the DRAM module..............38 Appendix A Intel Boot Agent Setup Menu... 41 Intel Boot Agent Setup Menu ..............42 ARK-1380 User Manual...
-
Page 7: Chapter 1 General Introduction
Chapter General Introduction This chapter gives background information on the ARK-1380. Sections include: Introduction Specifications... -
Page 8: Introduction
The ARK-1380 answers this demand by offering 4 x USB 2.0 ports, 1 x LVDS inter- face, 1 x LAN port and 2 x COM ports; packed into a small rugged unit and powered by an Intel Celeron M processor. -
Page 9: Product Features
UXGA panel resolution with frequency range from 25 MHz to 112 MHz LCD Interface: 1 Channel, 1 x 18/36-bit LVDS LVDS: one Hirose connector supports up to 2 channels LVDS LCD Panel Dual Independent Display: CRT + LVDS ARK-1380 User Manual... -
Page 10: Specifications
Specifications 1.3.1 Functional Specifications 1.3.1.1 Processor Table 1.1: Processor For ARK-1380-1S0A1E and ARK-1380-2S0A1E Processor CPU support Supports 400 MHz Source-Synchronous Processor Sys- tem Bus Supports Celeron M-1.0GHZ (373) CPU 35 mm *35 mm Micro-FCBGA Package For ARK-1380-1M0A1E and ARK-1380-2M0A1E Processor... - Page 11 Supports both ACPI (Advanced Configuration and Power Interface) 2.0 and legacy APM V1.2 power management BIOS Intel 82855GME/ICH4 chip supports Phoenix 4M bit Flash BIOS, supports Plug & Play, APM 1.2/ACPI 1.1 FWH Type Socket: 32 pin PLCC socket ARK-1380 User Manual...
-
Page 12: Table 1.3: Others (Chipset)
(PCMCIA2.1/JEIDA4.2) Card Bridge function between PCI bus and Card Bus Supports 1 PC Card Socket PCMCIA Socket on board: PCMCIA 68P 90D (F) SMD x Battery Backup Battery support: CR2032 BATTERY 3V/210 mAh with WIRE x 1 ARK-1380 User Manual... -
Page 13: Mechanical Specifications
9 V-3.8 A ~ 35 V-1 A Adaptor 1.3.3.2 Supply Current Supply Current (Maximum) CPU: Celeron M-1.0G (373), RAM: 333 MHz 512GB DDR SDRAM Adaptor 19 V BIOS 1.98 A WINXP Idle 2.18 A WINXP HCT11.0 WINXP 3DMARK2001SE WINXP BURN IN TEST 2.2 A ARK-1380 User Manual... -
Page 14: Environmental Specifications
Standard products (0 ~ 60° C) Relative humidity: 95% @ 60° C Phoenix products (-20 ~ 80° C) Relative humidity: 95% @ 60° C Platinum Phoenix products (-40 ~ 85° C) Relative humidity: 95% @ 60° C ARK-1380 User Manual... -
Page 15: Chapter 2 H/W Installation
Chapter H/W Installation... -
Page 16: Introduction
2.2.1 Jumper Description You can configure your ARK-1380 to match the needs of your application by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. -
Page 17: Jumper List And Settings
2.2.2.1 LVDS Power The ARK-1380 embedded box computer provides a jumper - CN14 located on the internal carrier board for selecting an LCD signal power of 5 V or 3.3 V. When you connect your LVDS LCD panel display, you need to set up the CN14 jumper for the LCD power setting selection for your LVDS panel display. -
Page 18: Connectors
Connectors Figure 2.1 ARK-1380 Front I/O Panel USB1 USB3 USB2 USB4 PS/2 COM1 COM2 Figure 2.2 ARK-1380 Rear I/O Panel External COM1 COM2 VGA Connector USB1 & USB2 USB3 & USB4 CN10 LAN (RJ45) CN12 Keyboard & Mouse CN16 Power Connector... -
Page 19: Ark-1380 Front Side External I/O Connectors
ARK-1380 Front Side External I/O Connectors 2.4.1 COM Connector The ARK-1380 provides two D-sub 9-pin connectors, which offer RS-232/422/485 serial communication interface ports. Please see the BIOS settings. Figure 2.3 COM connector Table 2.1: COM Standard Serial Port Pin Assignments... -
Page 20: Usb Connectors
2.4.2 USB Connectors The ARK-1380 provides four USB interface connectors, which give complete Plug & Play and hot swapping for up to 127 external devices. The USB interface is compliant with USB UHCI, Rev. 2.0. The USB interface can be disabled in the system BIOS setup. -
Page 21: Ps2 Keyboard/Mouse Connector
PS2 Keyboard/Mouse Connector The ARK-1380 provides a PS/2 keyboard/mouse connector. A 6-pin mini-DIN con- nector is located on the front metal face plate of the ARK-1380. The ARK-1380 comes with an adapter to convert from the 6-pin mini-DIN connector to two 6-pin mini-DIN connectors for PS/2 keyboards and PS/2 mouse connections. -
Page 22: Ethernet Connector (Lan)
2.4.4 Ethernet Connector (LAN) The ARK-1380 is equipped with an Intel 82551QM Ethernet controller that is fully compliant with IEEE 802.3u, 10/100Base-T CSMA/CD standards. The Ethernet port provides a standard RJ-45 jack connector with LED indicators on the front side to show its Active/Link status (Green LED) and Speed status (Yellow LED). -
Page 23: Ark-1380 Rear Side External I/O Connectors
2.5.2 LED Indicators There are two LEDs on the ARK-1380 front metal face plate for indicating system sta- tus: the PWR LED for power status which flashes in green; and the HDD LED for hard disk and compact flash disk status which flashes in red. -
Page 24: Audio Connector
2.5.5 AUDIO Connector The ARK-1380 provides a D-sub 9-pin connector, which offers an AC97 stereo audio output port. There are connections for Speaker_Out, Mic_In and Line_In (The con- nector can be attached to 3 phone jacks by an audio cable, P/N:1700006011, which is an accessory). -
Page 25: Vga Connector
Green Blue H-SYNC V-SYNC 2.5.7 Power Input Connector The ARK-1380 comes with a two pin header that carries and external power input of 9~35 VDC. Figure 2.10 Power Input Connector Table 2.8: Power Connector Pin Assignments Signal Name +9~35VDC ARK-1380 User Manual... -
Page 26: Dimension
Dimension Ø4,6 Detail A 165,0 COM1 COM2 PS/2 USB1 USB3 USB2 USB4 189,0 Figure 2.11 Dimension ARK-1380 User Manual... -
Page 27: Bios Operation
Chapter BIOS Operation... -
Page 28: Bios Introduction
CPUs ranging from 386 through Pentium, AMD Geode, K7 and K8 (including multiple processor platforms), and VIA Eden C3 and C7 CPUs. You can use Advantech’s utilities to select and install features to suit your designs for customer needs. -
Page 29: Main Menu
This setup page includes load system optimized value, and system best perfor- mance configuration. Set Password Establish, change or disable password. Save & Exit Setup Save CMOS value settings to CMOS and exit BIOS setup. Exit Without Saving Abandon all CMOS value changes and exit BIOS setup. ARK-1380 User Manual... -
Page 30: Standard Cmos Features
Extended Memory [Show Only] The BIOS POST determines the amount of extended memory (above 1MB in CPU’s memory address map) installed in the system. Total Memory [Show Only] Displays the total system memory size. ARK-1380 User Manual... -
Page 31: Advanced Bios Features
When you select “Setup”, the system prompts for the super- visor password at boot up only when the setup utility is invoked System When you select “System”, the system prompts for the user password every time you boot up. APIC Mode [Enabled] ARK-1380 User Manual... -
Page 32: Advanced Chipset Features
Allows the system BIOS to be cached to allow faster execution and better per- formance. Video BIOS Cacheable [Disabled] Allows the video BIOS to be cached to allow faster execution and better perfor- mance. AGP Aperture Size (MB) [64] ARK-1380 User Manual... -
Page 33: Integrated Peripherals
(Extended Capabilities Port) and EPP (Enhanced Parallel Port). BIOS default value: Normal. – EPP Mode Select [EPP1.7] Allows users to change the EPP Mode for the parallel port. BIOS default value: EPP1.7. – ECP Mode Use DMA [3] ARK-1380 User Manual... -
Page 34: Power Management Setup
– DPMS Initial display power management signaling. Video Off In Suspend [Yes] Allows users to turn off video when system enters suspend mode. Suspend Type [Stop Grant] Allows users to determine the suspend type. Modem use IRQ ARK-1380 User Manual... -
Page 35: Pnp/Pci Configurations
The “PC Health Status” option controls the thermal, fan and voltage sta- tus of the board. It is chipset independent. Shutdown Temperature [Disabled] Enables users to set CPU temperature limits, ranging from 60° C to 75° C. ARK-1380 User Manual... -
Page 36: Frequency/Voltage Control
Load optimized defaults. loads the default system values directly from ROM if the stored record created by the setup program should ever become corrupted (and therefore unusable). These defaults will load automatically when you turn the ARK-1380 system on. 3.2.11 Set Password Note! To enable this feature, you should first go to the ‘Advanced BIOS Fea-... -
Page 37: Save & Exit Setup
CMOS. Typing “N” will return to the BIOS Setup Utility. 3.2.13 Quit Without Saving Note! Typing ”Y” will quit the BIOS Setup Utility without saving to CMOS. Typing “N” will return to the BIOS Setup Utility. ARK-1380 User Manual... - Page 38 ARK-1380 User Manual...
-
Page 39: Full Disassembly Procedure
Chapter Full Disassembly Procedure... -
Page 40: Introduction
Users should be aware that Advantech Co., Ltd. takes no responsibility whatsoever for any problems or damage caused by user disassembly of the ARK- 1380. Make sure the power cord of the ARK-1380 is unplugged before you start dis- assembly. -
Page 41: Figure 4.2 Unscrew The 6 Screws On The Front Side Frame
Figure 4.2 Unscrew the 6 screws on the front side frame Unscrew the 4 Hex-bolts on the front face plate. Figure 4.3 Unscrew the 4 Hex-bolt on the front face plate Unscrew the 6 screws on the rear side frame. ARK-1380 User Manual... -
Page 42: Figure 4.4 Unscrew The 6 Screws On The Rear Side Frame
Figure 4.4 Unscrew the 6 screws on the rear side frame Unscrew the 6 Hex-bolts on the rear face plate. Figure 4.5 Unscrew the 6 Hex-bolt on the rear face plate ARK-1380 User Manual... -
Page 43: Figure 4.6 Pull Out The Carrier Board From The Aluminum Case
Pull out the carrier board from the Aluminum case. Figure 4.6 Pull out the carrier board from the aluminum case Remove the CF card anti-shock holder. Figure 4.7 Remove the CF card anti-shock holder ARK-1380 User Manual... -
Page 44: Figure 4.8 Remove The Cf Card
Remove the CF card. Figure 4.8 Remove the CF card Turn over the carrier board, remove the DRAM module. Figure 4.9 Turn over the carrier board and remove the DRAM module ARK-1380 User Manual... - Page 45 Note! Before installing the system, please make sure the thermal pad is not broken and be careful of the thermal pad when you insert the board into the system. ARK-1380 User Manual...
- Page 46 ARK-1380 User Manual...
-
Page 47: Appendix A Intel Boot Agent Setup Menu
Appendix Intel Boot Agent Setup Menu... -
Page 48: Intel Boot Agent Setup Menu
RPL) that a user can select from the ‘Network Boot Protocol’ item. To show the prompt message, hold down the ‘Ctrl + S’ keys during system ini- tialization to enter the ‘Boot Agent Setup’ menu and select ‘Show Setup Prompt’ item. ARK-1380 User Manual... - Page 49 ARK-1380 User Manual...
- Page 50 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2007...
