TANDBERG Quick Set C20/C20 Plus and Profiles using C20
Contents
Contents
Introduction
Introduction
TANDBERG Profile 42"/52",
continued...
OTHER INTERFACES
USB host for future usage
PRECISIONHD 1080P 12X CAMERA
1/3" CMOS
12 x zoom
+15°/-25° tilt, +/- 90° pan
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3m–infinity
1920 x 1080 pixels progressive @ 60fps
Other formats supported (configurable through Dip-
switch):
1920 x 1080@60 Hz (HDMI only)
1920 x 1080@50 Hz (HDMI only)
1920 x 1080@30 Hz
1920 x 1080@25 Hz
1280 x 720@60 Hz
1280 x 720@50 Hz
1280 x 720@30 Hz
1280 x 720@25 Hz
Automatic or manual focus/brightness/white balance
Far-end camera control
Dual HDMI and HD-SDI output
SYSTEM MANAGEMENT
Support for the TANDBERG Management Suite
Total management via embedded SNMP, Telnet, SSH,
XML, SOAP
Remote software upload: via web server, SCP, HTTP,
HTTPS
Remote control and on-screen menu system
DIRECTORY SERVICES
Support for Local directories (My Contacts)
Corporate Directory
Unlimited entries using Server directory supporting LDAP
and H.350
Unlimited number for Corporate directory (through TMS)
200 number local directory
Received Calls with Date and Time
Placed Calls with Date and Time
Missed Calls with Date and Time
D14637.01—MARCH 2010
Advanced configuration
Advanced configuration
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 4.5 A max
Maximum power consumption: 390 W
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STORAGE AND TRANSPORT TEMPERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90% (non-
condensing)
APPROVALS
Directive 2006/95/EC (Low Voltage Directive)–Standard
EN 60950-1, 2ed
Directive 2004/108/EC (EMC Directive)–Standard EN
55022, Class A– Standard EN 55024– Standard EN
61000-3-2/-3-3
Approved according to UL 60950-1 and CSA 60950-1-07
Complies with FCC15B Class A
DIMENSIONS
Height: 63.78" / 162 cm
Width: 38.58" / 98 cm
Depth: 6.7" / 17 cm
WEIGHT
Weight: 202.8 lbs / 92 kg
Password protection
Password protection
About monitors
About monitors
All specifications are subject to change without notice,
system specifics may vary.
All images in these materials are for representational
purposes only, actual products may differ.
TANDBERG and Expressway are registered trademarks or
trademarks of TANDBERG in the U.S. and other countries.
All other trademarks are property of their respective
owners.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
March 2010
48
Administrator guide
Appendices
Appendices
Appendices
Contact us
Contact us
* requires option
www.tandberg.com
