Multicast IP Addressing for Multiple SMP 111 Installations
When multiple SMP 111 devices are installed in a system (when the multicast address
is used for push or pull streaming) the streams are managed by the SMP 111 to avoid
conflicts.
Pull streaming (RTSP)
The SMP 111 can use one of two multicast streaming IP address assignment methods.
If multicast IP addresses for a network are limited, the SMP 111 devices can use
unassigned port numbers within the available range (1024 to 65436).
NOTE: To prevent conflicts, always check to see if other devices using the same IP
address have already used a port number before using it in the SMP 111.
The following table shows a typical port assignment for multiple SMP 111 devices using a
single multicast IP address (RTSP pull streams require four sequential ports).
Device
SMP1
SMP2
SMP3
When there are different multicast IP addresses available, there is no need for multiple port
numbers and the port number can remain at the default (
Device
SMP1
SMP2
SMP3
NOTE: The SMP 111 automatically inserts the ending port number when the initial port
number is entered.
Push streaming (TS/UDP, TS/RTP, ES/RTP)
Push streams to a multicast address generally require only two ports, except for ES/RTP
which requires four. When push streaming from multiple SMP 111 devices to multicast
addresses, the same IP address rules apply as with pull streaming.
For push streaming, the destination IP and port number are adjusted using the encoder
presets page.
SMP IP Multicast IP
192.168.254.10 239.199.188.138
192.168.254.11 239.199.188.138
192.168.254.12 239.199.188.138
SMP IP Multicast IP
192.168.254.10 239.199.188.138
192.168.254.11 239.199.188.139
192.168.254.12 239.199.188.140
SMP 111 • Reference Information
Multicast Port
7000 to 7003
7004 to 7007
7008 to 7011
) as shown in the next table.
63000
Multicast Port
7000
7000
7000
