Installer and user manual
Meteo Green HE R.S.I.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the METEO GREEN HE R.S.I. and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beretta METEO GREEN HE R.S.I.

Summary of Contents for Beretta METEO GREEN HE R.S.I.

  • Page 1 Installer and user manual Meteo Green HE R.S.I.

  • Page 2: Table Of Contents

    METEO GREEN HE R.S.I. METEO GREEN HE R.S.I. boiler complies with basic requirements of the following Directives: - Gas directive 2009/142/EC; - Yield directive 92/42/EEC; - Electromagnetic compatibility directive 2004/108/EC; - Low-voltage directive 2006/95/EC; - Directive 2009/125/EC Ecodesign for energy-using appliances; - Directive 2010/30/EU Indication by labelling of the consumption of energy by energy-related products;...

  • Page 3: Installer Manual - Contents

    METEO GREEN HE R.S.I. INSTALLER MANUAL 1 - GENERAL SAFETY DEVICES The boilers produced in our factory are built with care down to the last Safety measures: component to protect both the user and installer from eventual accidents. The boiler should not be used by children or unassisted disabled people We therefore recommend qualified personnel that after working on the product they should pay particular attention to the wiring, especially the Electrical devices or equipment, such as switches, appliances, etc.,...

  • Page 4: Boiler Operating Elements

    METEO GREEN HE R.S.I. 2 - BOILER OPERATING ELEMENTS Electrical connections box Safety valve Three-way solenoid valve Circulation pump Lower air vent valve Siphon Return NTC sensor Expansion vessel Fume probe 10. Fume analysis sample cap 11. Fumes outlet 12. Ignition transformer 13.

  • Page 5: Technical Data

    METEO GREEN HE R.S.I. 4 - TECHNICAL DATA R.S.I. 25 kW R.S.I. 35 kW Nominal thermal load 25.00 34.60 kcal/h 21 500 29 756 Nominal thermal power (80-60°C) 24.38 33.74 kcal/h 20 963 29 012 Nominal thermal power (50-30°C) 26.20 36.50 kcal/h 22 532...

  • Page 6: Multigas Table

    METEO GREEN HE R.S.I. R.S.I. 25 kW R.S.I. 35 kW Fume exhaustion and air suction separated pipe Diameter Max lenght 32 + 32 40 + 40 Loss for a 90°/45° bend 1.5 / 1 1.5 / 1 Forced open installation (B23P-B53P) Diameter Max lenght Loss for a 90°/45°...

  • Page 7: Hydraulic Circuit

    METEO GREEN HE R.S.I. Parameter Symbol R.S.I. 25 kW R.S.I. 35 kW Unit Seasonal space heating energy efficiency class Water heating energy efficiency class Rated heat output Pnominal Seasonal space heating energy efficiency Useful heat output At rated heat output and high-temperature regime (*) 24,4 33,7 At 30% of rated heat output and low-temperature regime (**)

  • Page 8: Multi-Wire Diagram

    METEO GREEN HE R.S.I. 7 - MULTI-WIRE DIAGRAM...

  • Page 9: Electrical Connections

    METEO GREEN HE R.S.I. 8 - ELECTRICAL CONNECTIONS HIGH VOLTAGE CONNECTIONS HIGH VOLTAGE CONNECTIONS Any external connection of a second circulator will be connected to The programmable heating thermostat and ambient thermostat to the terminal black M2 as shown below. be connected as shown in the diagram.

  • Page 10: Boiler Installation

    METEO GREEN HE R.S.I. 9 - BOILER INSTALLATION - 1.1 - Boiler must only be installed by qualified personnel. Boiler is available in the following models: Model Type Category Power R.S.I. CH only 25-35 kW pressure relief Meteo Green HE R.S.I. is a C-type condensation wall-mounted boiler and is able to operate: - CASE A: only heating.

  • Page 11: Hydraulic Connections

    METEO GREEN HE R.S.I. When working with a constant delivery temperature and attainment of sta- The “anti-blocking” function is only active when the electrical power bilising the ambient conditions, the average temperature of the radiators supply to the boiler is on. WHQGV WR LQFUHDVH %\ NHHSLQJ ¨7 FRQVWDQW WKH UHGXFWLRQ LQ WKH IORZ UDWH LV Operating the circulation system without any water is strictly forbidden.

  • Page 12: Installing The External Probe

    METEO GREEN HE R.S.I. 11 - INSTALLING THE EXTERNAL PROBE - 1.4 - The sensor (Fig. 1.4) must be installed on an external wall of the building you want to heat, while taking care to comply with the instructions below: - It must be fitted on the facade most often exposed to wind, on a wall facing SOUTH or SOUTH-EAST, and taking care to avoid direct sunlight.

  • Page 13: Filling And Emptying The System

    METEO GREEN HE R.S.I. - 1.7 - - 1.8 - HIGH VOLTAGE CONNECTIONS (230V) LOW VOLTAGE CONNECTIONS 15 - FILLING AND EMPTYING THE SYSTEM The central heating system can be filled up once the water mains have been connected up. This must be done while the installation is cold by: - turn the caps of the lower (A) and upper (E) automatic bleed valves two - 1.9 - or three times;...

  • Page 14: Fumes Exhaustion And Burning Air Suction

    METEO GREEN HE R.S.I. 16 - FUMES EXHAUSTION AND BURNING AIR - 1.10 - SUCTION EXHAUSTION CONFIGURATIONS (Fig. 1.10-1.11) Boiler is homologated for the following exhaustion configurations: B23P-B53P - Suction in room and discharge outside C13 - Concentric wall exhaustion. Pipes can separately start from boiler, but outlets must be concentric or close enough to be subject to similar wind conditions (within 50 cm) C23 - Concentric exhaustion in common chimney (suction and exhaustion...
  • Page 15 METEO GREEN HE R.S.I. Rectilinear length means without bends, outlet ends and connections. - 1.13 - The fumes outlet duct must slope by 1% towards the condensate col- sealing lector. rubber Uninsulated fumes outlets are potential hazards. The boiler automatically adapts ventilation according to the type of installation and the length of the duct.

  • Page 16: Start-Up And Operation

    METEO GREEN HE R.S.I. 17 - START-UP AND OPERATION NB: all the adjustments (boiler calibration, thermoregulation setting, pa- fault symbol (e.g. 10 - no flame) rameter setting) must be made directly on the boiler control panel only. function selector (turned to the chosen operating mode: winter or Ignition, switch-off, function selection and heat requests must ALWAYS summer (DO NOT USE)
  • Page 17 METEO GREEN HE R.S.I. SUMMER function (only with external water tank connected, ADJUSTING HEATING WATER TEMPERATURE DO NOT USE Fig. F) Turning the selector A (Fig. G), after having positioned the selector mode on winter , it is possible to regulate the heating water temperature. With the selector in this position, the boiler provides water to the water tank Turn clockwise to increase the temperature and anticlockwise to decrease.
  • Page 18 METEO GREEN HE R.S.I. WORKING THE BOILER - J - Adjust the ambient thermostat to the required temperature (approx. 20°C). If there is a demand for heating water, the boiler starts and the symbol is shown on the display (Fig. K). The boiler will remain working until the set temperatures are reached, after which it will go on stand-by.
  • Page 19 METEO GREEN HE R.S.I. 17.4 - INF2 - Q - It is possible to display information, which may be useful for the Technical Assistance Centre, by pressing the button for 10 seconds: the code “INF2” appears on the display. INF2 list Display Display Step...

  • Page 20: Troubleshooting

    METEO GREEN HE R.S.I. 18 - TROUBLESHOOTING DIAGNOSTIC CODES FAULT CODES In this generation of PCB it’s possible to have more detailed fault signals Fault codes take priority over all display functions in the event of a system compared to the past. This is made to give to the service the chance to know fault occurring.
  • Page 21 METEO GREEN HE R.S.I. Fault codes: SAFETY CODE TYPE MEANING Final Flow NTC temperature too high: this alarm is generated because the boiler sensed that the value of flow NTC exceeded the value of 105°C continuously for more than 120”. It’s necessary to reset the boiler.
  • Page 22 METEO GREEN HE R.S.I. Fault codes: WATER CODE TYPE MEANING Temporary Too little water pressure in the appliance: this alarm is generated because the CH system pressure level drops below 0,3 bar. The burner is switched off during this 60 seconds. If the pressure goes over 0,4 bar within 60 seconds the boiler will work normally, otherwise will become fault code 40.
  • Page 23 METEO GREEN HE R.S.I. Fault codes: TEMPERATURE PROTECTIONS CODE TYPE MEANING Temporary Over heat under floor heating thermostat: it is generated when the contact of the under floor safety thermostat that protects an eventual under floor system opens. The burner is switched off and blocked. Temporary Maximum delta between flow temperature and return temperature reached: it’s generated when the burner is on during the modulation phase and the difference...

  • Page 24: Resetting Faults

    METEO GREEN HE R.S.I. 19 - Resetting faults - CC - Wait for about 10 seconds before resetting operating conditions. Then proceed as follows: 1) VIEWING JUST THE SYMBOL disappears, it means that an operating fault has been discovered which the boiler is attempting to solve on its own (temporary stoppage).

  • Page 25: Programming Parameters

    METEO GREEN HE R.S.I. Case C - DD - Alarm 91 - Contact the Technical Assistance The boiler has a self-diagnosis system which, on the basis of the hours to- talised in particular operating conditions, signals the need for maintenance or cleaning of the primary exchanger (alarm code 91).
  • Page 26 METEO GREEN HE R.S.I. PROGRAMMABLE PARAMETERS DEFAULT PARAMETERS N° UNIT OF DESCRIPTION PARAMETERS (setted in (setted by techn. PAR. MEASURE factory) assist. centre) THIS PARAMETER IS NOT USED ON THIS MODEL. DO NOT MODIFY THIS PARAMETER IS NOT influential 10-16-20-26-30-34-50-70 INSULATION LEVEL OF BUILDING DHW MODE 0 (OFF)

  • Page 27: Serial Number Plate

    METEO GREEN HE R.S.I. 21 - SERIAL NUMBER PLATE During parameter modification operations, the “select functions” button acts as an ENTER (confirm) button, the button acts as an ESCAPE nominal capacity button. If no confirmation is given within 10 seconds, the value is dis- nominal power carded and returns to the previously set one.
  • Page 28 METEO GREEN HE R.S.I. Parameter with password 18 PAR. MEANING UNIT STEP DEFAULT CH2 OTC (climatic curve) ONLY IF THE PAR. 20 SET UP IS 6 (2 HEATING CIRCUIT) Max. speed fan Look istr. The value visualized is rpm/100 (e.g.: 3700/100 = 37) boiler Min.
  • Page 29 METEO GREEN HE R.S.I. Parameter with password 53 PAR. MEANING UNIT STEP DEFAULT Gas type - don’t change 1 = G20 - LPG Boiler power - not used - don’t change 26-30-34 Kind of building Domestic hot water type 0= OFF 1= Instantaneous (COMBO) (COMBO)
  • Page 30 METEO GREEN HE R.S.I. Parameter with password 53 PAR. MEANING UNIT STEP DEFAULT CH timers: ON /OFF selection 0 = OFF 1 = ON Maximum flow temperature CH2 °C Minimum flow temperature CH2 °C DHW thermostat function 0 = OFF 1 = AUTO 2 = ON Pre-heating function...
  • Page 31 METEO GREEN HE R.S.I. The parameters 10 - HP - SP - LP - MM - 23 - 24 must be modified, - 1.15 - by professionally qualified personnel, only if absolutely necessary. The manufacturer refuses any responsibility in the case of incorrect setting of the parameters.

  • Page 32: Setting The Thermoregulation

    METEO GREEN HE R.S.I. 23 - SETTING THE THERMOREGULATION PARAMETER 44. Enable thermoregulation function The connected external temperature probe combined with PARAMETER 44 provides the following operating modes: CHECKING THE CONNECTION WITH THE EXTERNAL PROBE - EXTERNAL PROBE CONNECTED and PARAMETER 44 = 0 (OFF) in this After connecting the external probe to the boiler, use the INFO function to case the TEMPERATURE CONTROL function is disabled even though the check that the probe has been automatically recognised by the temperature...

  • Page 33: Gas Conversion

    METEO GREEN HE R.S.I. The ambient thermostat makes a heat request when its contact closes, while 24 - GAS CONVERSION it stops it when its contact opens. Though delivery temperature is automati- It is easy to transform gas from one family to gas belonging to another family cally calculated by the boiler, the user may manually override it.

  • Page 34: Checking Combustion Parameters

    METEO GREEN HE R.S.I. - Reassemble the mixer with the flap in a horizontal position and the spacer - 1.18 - springs placed at 120° as shown in the (Fig. 1.18) - Reassemble gas ramp and silencer, working vice versa. METEO GREEN 25 HE - Check the number of times the fan turns - Switch on the power to the boiler and turn on gas cock again...
  • Page 35 METEO GREEN HE R.S.I. The boiler is supplied with the settings shown in the table. But said values may be adjusted by following the graphs given here below, depending on instal- lation requirements or regional rules and regulations combusted gas emission limits. Heat capacity curve –...
  • Page 36 METEO GREEN HE R.S.I. Heat capacity curve – emissions (Qnrisc) – 35 HE Heating heat capacity (kW) Heat capacity curve – fan rpm (Qnrisc) – 35 HE 6500 6000 5500 5000 4500 4000 3500 3000 2500 2000 1500 1000 Heating heat capacity (kW)

  • Page 37: General Safety Information

    REMOTE CONTROL USER MANUAL Dear Client, Beretta has always been committing itself to comply with the demands of its Please read carefully because, following our information and advice, you own Clients and uses all its experience and competence for the realization would be able to use properly your new appliance and provide for its proper of all its appliances.
  • Page 38 METEO GREEN HE R.S.I. DESCRIPTION OF DISPLAY Text messages and time display field Daily current heating schedule Communication with the boiler symbol, indicates that there is an exchange of data between the boiler and the remote control panel Holiday function symbo Symbol for burner operating in the heating or sanitary function Anti-freeze protection symbol Modification symbol: indicates that the values set may vary...

  • Page 39: Switching On

    METEO GREEN HE R.S.I. 2 - SWITCHING ON code will appear on the display. To reset the boiler: With the dashboard cover closed, push the button until you see press the PAUSE and AUTO- PAUSE AUTO I MAN MAN buttons simultaneously on on the display the desired operating mode, summer or winter the remote control panel.
  • Page 40 METEO GREEN HE R.S.I. 3.1.1 Selecting the operating mode 3.1.2 Selector for adjusting the room temperature SUMMER MODE (boiler in STAND-BY) In the manual and automatic ope- rating modes, the heating function WINTER MODE depends on the room temperature heating values set.
  • Page 41 METEO GREEN HE R.S.I. HOLIDAY 3.1.4 Unblocking function To enable the function, you have to set the system in winter mode and Pressing simultaneously the buttons overtake the 24 hours PAUSE in the You can reset the boiler after a safety PAUSE AUTO I MAN following way:...
  • Page 42 METEO GREEN HE R.S.I. 3.2 Advanced functions (dashboard cover open) ITALIANO PORTUGUES POLSKI CROATIAN 6HDUFKHV RU PRGL¿HV YDOXH CESKY LIETUVISKAI LATVIESU SLOVENSKY MAGYAR DEUTSCH ENGLISH FRANCAIS NEDERLANDS ESPANOL  FRQ¿UP WKH VHOHFWLRQ E\ SUHVVLQJ (17(5 3.2.2 Selecting the menus available Access the adjusting menus Fills up the installation (press both With the +/- buttons, you can run...
  • Page 43 METEO GREEN HE R.S.I. of manual operating mode (see paragraph “operating mode”) menu, displaying the new memorized settings. Desired temperature for the ¿UVW WLPH EDQG in case of heating HTG-PROG schedule (HTG-PROG), see paragraph “HTG-PROG” (heating schedule) - T-ROOM DES 2 (5°C-40°C °C): Desired temperature for the Permits programming three 24 hours operating time bands.
  • Page 44 METEO GREEN HE R.S.I. In USER MENU set the desired temperature: T-ROOM DES1 20°C T-ROOM DES2 18°C T-ROOM DES3 24°C The progress of temperature/time bands will be as shown in the diagram. ENTER ENTER °C fascia 3 time band 3 T-AMB3 T-ROOM DES 3 fascia 1...
  • Page 45 METEO GREEN HE R.S.I. The time bands programming phase always begins with a starting WLPHWDEOH 21  LGHQWL¿HG ZLWK WKH V\PERO DQG ¿QLVKHV ZLWK DQ HQGLQJ WLPHWDEOH 2))  LGHQWL¿HG ZLWK WKH V\PERO  . The 3 time bands are expressed on the display by the following symbols: ENTER ENTER...

  • Page 46: Switching Off

    METEO GREEN HE R.S.I. 4 - SWITCHING OFF FAULT E41 Should the wording FILL REQ appe- Switching off for short periods ar on the display for lack of water, the In the event of short periods of absen- ¿OOLQJ SURFHGXUH FDQ EH DFWLYDWHG DV ce, press the “...

  • Page 47: Guide To Main Configurations

    METEO GREEN HE R.S.I. GUIDE TO MAIN CONFIGURATIONS SOLUTION A System Temperature External Probe Heating Call Direct High or Low Not installed Rec07 TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HEATING SYSTEM With Parameter nr.20=1, and then with Par. nr. 21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP). When the Rec07 makes an heating call, the system can work in 2 different ways: - The Rec07 defines the value of the water flow temperature thanks to the thermoregulation ( ambient temperature probe installed).
  • Page 48 METEO GREEN HE R.S.I. SOLUTION B System Temperature External Probe Heating call Direct High or Low Installed Rec07 TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HETING SYSTEM With Parameter nr.20=1, and then with Par. nr. 21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP). With the external probe and the Rec07 request, the system can work in 2 ways, according to Parameter nr.44: - If the Par.44=0, the thermoregulation is managed by the Rec07 which uses both its ambient probe and the boiler external one.
  • Page 49 METEO GREEN HE R.S.I. SOLUTION C System Temperature External Probe Heating call Direct High or Low Not installed Ambient Thermostat TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HEATING SYSTEM With Parameter nr.20=11, Par. nr. 21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP) When the Ambient Thermostat (TA) makes a heating call, the boiler starts working with a heating SP defined with the heating encoder (20÷80°C = Par.22÷Par.21).
  • Page 50 METEO GREEN HE R.S.I. SOLUTION D System Temperature External Probe Heating call Direct High or Low Installed Ambient Thermostat TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HEATING SYSTEM With Parameter nr.20=11, Parameter nr.44=1, Par.21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP) With the external probe and the request from the Ambient Thermostat, the system works according to the thermoregulation of the electronic PCB embedded in the boiler (AE02), thanks to Parameter nr.44=1 and with the climatic curve defined with Parameter nr.45: 20 (default) for systems with high temperature, 10 for systems with low temperature, but the value can be modified according to the system characteristics.
  • Page 51 METEO GREEN HE R.S.I. SOLUTION E System Temperature External Probe Heating Call 2 zones at leat High or Low Not installed Rec07 and / or TA TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HEATING SYSTEM With Parameter nr.20=11, Par. nr. 21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP) The Rec07 has not the dry contact, typical of the Ambient Thermostat, which is necessary to energize the zone valve - VDZ (230 vac).
  • Page 52 METEO GREEN HE R.S.I. SOLUTION F System Tempoerature External Probe Heating Call 2 zones at least High or Low Installed Rec07 and / or TA TRADITIONAL SYSTEM – RADIATORS HIGH TEMP. UNDERFLOOR HEATING SYSTEM With Parameter nr.20=11, Parameter nr.44=1, Par.21 and Par.22 we define the maximum and minimum limit of the Heating Set Point (SP) The Rec07 has not the dry contact, typical of the Ambient Thermostat, which is necessary to energize the zone valve –...
  • Page 53 METEO GREEN HE R.S.I. SOLUTION G System Temperature External Probe Richiesta Calore 1 High temp. e 1 Low Temp. High and Low unconcerned Rec07 and / or TA Connect BASE Circuit The electronic PCB embedded in the boiler (AE02) considers the “Connect BASE” as the only Ambient Thermostat of a direct system (High Temp.). The Connect is equipped with a relay to which the 2 Ambient Thermostats of the 2 zones are connected;...
  • Page 54 METEO GREEN HE R.S.I.
  • Page 55 METEO GREEN HE R.S.I.
  • Page 56 Tel. +39 0341 277111 Fax +39 0341 277263 info@berettaboilers.com www.berettaboilers.com In order to improve its products, Beretta reserves the right to modify the characteristics and information contained in this manual at any time and without prior notice. Consumers statutory rights are not aected.
