- Page 1 2014-2017 Pike Service Manual GEN.0000000004461 Rev E © 2016 SRAM, LLC...
- Page 2 SRAM LLC WARRANTY EXTENT OF LIMITED WARRANTY Except as otherwise set forth herein, SRAM warrants its products to be free from defects in materials or workmanship for a period of two years after original purchase. This warranty only applies to the original owner and is not transferable. Claims under this warranty must be made through the retailer where the bicycle or the SRAM component was purchased.
-
Page 3: Table Of Contents
TABLE OF CONTENTS EXPLODED VIEW - RCT3/DUAL POSITION AIR™ ..............................5 EXPLODED VIEW - RC/SOLO AIR™ ...................................6 ROCKSHOX® SUSPENSION SERVICE ..................................7 Parts and Tools Needed for Service............................................7 Recommended Service Intervals ............................................8 Record Your Settings ................................................8 Torque Values .....................................................8 Fluid Volume ....................................................8 LOWER LEG ASSEMBLY ......................................9 50/200 Hour Service Lower Leg Removal.................................................. - Page 4 SAFETY FIRST! We care about YOU. Please, always wear your safety glasses and protective gloves when servicing RockShox® products. Protect yourself! Wear your safety gear!
-
Page 5: Exploded View - Rct3/Dual Position Air
E x p l o d e d V i e w - R C T 3 / D u a l P o s i t i o n A i r ™ Air Shaft Assembly Air Valve Cap Knob Retaining Nut Compression Damper DPA Adjuster Knob... -
Page 6: Exploded View - Rc/Solo Air
E x p l o d e d V i e w - R C / S o l o A i r ™ Air Shaft Assembly Compression Damper Air Valve Cap Assembly SA Top Cap Rebound Damper Assembly Knob Retaining Nut Bottomless Token™... -
Page 7: Rockshox® Suspension Service
R o c k S h o x ® S u s p e n s i o n S e r v i c e We recommend that you have your RockShox suspension serviced by a qualified bicycle mechanic. Servicing RockShox suspension requires knowledge of suspension components, as well as the use of specialized tools and lubricants. -
Page 8: Recommended Service Intervals
R e c o m m e n d e d S e r v i c e I n t e r v a l s Regular service is required to keep your RockShox® product working at peak performance. Follow this maintenance schedule and install the service parts included in each service kit that corresponds with the Service Hours Interval recommendation below. -
Page 9: Lower Leg Assembly
L o w e r L e g A s s e m b l y 5 0 / 2 0 0 H o u r S e r v i c e L o w e r L e g R e m o v a l Remove the air valve cap from the top cap located on the non-drive side fork leg. - Page 10 Place an oil pan beneath the fork to catch any draining oil. 5 mm Use a rubber or plastic mallet to firmly strike each bottom bolt to dislodge the air and damper shafts from the lower leg. Use a 5 mm hex wrench to remove the bottom bolts from the lower leg. Firmly pull the lower leg downward until oil begins to drain.
-
Page 11: 50 Hour Service
5 0 H o u r S e r v i c e L o w e r L e g S e r v i c e Remove the foam rings and clean them with isopropyl alcohol and a rag. Soak the foam rings in RockShox 0w-30 suspension oil. -
Page 12: 200 Hour Service
2 0 0 H o u r S e r v i c e L o w e r L e g S e a l S e r v i c e Place the tip of a downhill tire lever underneath the lower lip of the dust wiper seal. - Page 13 Soak the new foam rings in RockShox 0w-30 suspension oil. Install new foam rings on the top bushings in the lower leg. Remove the wire spring from the new dust wiper seal and set it aside. Insert the narrow end of a new dust wiper seal into the recessed end of the seal installation tool.
- Page 14 Hold the lower leg steady and use the seal installation tool to press the dust wiper seal evenly into the lower leg until the seal surface is flush with the top of the lower leg surface. Reinstall the wire spring onto the dust wiper seal. Repeat steps 7, 8, and 9 for the other side of the lower leg.
-
Page 15: Air Spring Travel Change And Bottomless Tokens
A i r S p r i n g T r a v e l C h a n g e a n d B o t t o m l e s s T o k e n s ™ To increase or decrease the travel in your RockShox®... -
Page 16: Air Spring Service
A i r S p r i n g S e r v i c e 2 0 0 H o u r S e r v i c e A i r S p r i n g R e m o v a l N OTI CE Inspect each part for scratches. - Page 17 Use your fingers or a pick to remove the top cap o-ring. Use your fingers to install a new o-ring. Do not apply any grease to the top cap threads. Dual Position Air™: Push the air shaft into the upper tube to prevent it from getting scratched while removing the retaining ring.
- Page 18 Solo Air™: Use a flat blade screwdriver to push the SA seal head tab under the retaining ring. Place your finger over the end of the air spring shaft to prevent it from getting scratched while removing the retaining ring. NOTI C E Scratches on the air shaft will allow air to bypass the seal head into the lower leg, resulting in reduced spring performance.
- Page 19 Remove the seal head assembly, backup ring, and wave spring from the air shaft. Discard the seal head assembly and wave spring. NOTI C E Do not install a new seal head at this time. The seal head will be replaced in the Installation section.
-
Page 20: Solo Air™ Bottomless Token™ Installation
S o l o A i r ™ B o t t o m l e s s T o k e n ™ I n s t a l l a t i o n Bottomless Tokens reduce the air volume in your fork to create greater ramp at the end of the fork travel. Add tokens to maintain your fork's bottomless feel. -
Page 21: Air Spring Installation
2 0 0 H o u r S e r v i c e A i r S p r i n g I n s t a l l a t i o n Apply a liberal amount of SRAM® Butter to the air piston and seal head seals. - Page 22 Use your fingers to slide the retaining ring onto the shaft. Do not scratch the air shaft. NOTI C E Scratches on the air shaft will allow air to bypass the seal head into the lower leg, resulting in reduced spring performance. Place the tips of large internal retaining ring pliers into the eyelets of the retaining ring, then use the pliers to push the seal head into the upper tube while installing the retaining ring into the groove.
- Page 23 Dual Position Air™: Place the DPA adjuster knob and the knob retaining nut onto the top cap with the long tab near the front of the crown. Turn the DPA adjuster knob counter-clockwise until it engages the first detent space. Use a torque wrench with a 10 mm socket to tighten the knob retaining nut to 1.7-2.2 N•m (15-20 in-lb).
-
Page 24: Damper Service
D a m p e r S e r v i c e 2 0 0 H o u r S e r v i c e C h a r g e r D a m p e r ™ R e m o v a l N OTI CE Inspect each part for scratches. - Page 25 RCT3: Use a 2 mm hex wrench to remove the low speed adjuster knob 6 mm RCT3 screw. Remove the low speed compression adjuster knob. Use a 6 mm socket wrench to remove the knob retaining nut. Remove the compression mode adjuster knob. 2 mm RCT3 RC: Use a 4 mm hex wrench to remove the knob retaining nut.
- Page 26 Lightly clamp the cartridge tube into a bicycle stand with the rebound damper shaft oriented upward. NOTI C E Clamp the cartridge tube into the bicycle just tighten enough so that it does not slip or spin. The tube can deform if clamped too tightly. Place a 21 mm open end wrench on the wrench flats of the cartridge tube.
- Page 27 Remove the seal head assembly from the rebound damper shaft. Discard the damper seal head. Apply SRAM® Butter grease to the new rebound damper seal head seals. Install the new seal head assembly onto the rebound damper shaft with the threads oriented toward the piston.
-
Page 28: Optional Rebound Re-Tune
O p t i o n a l R e b o u n d R e - t u n e The Charger Damper™ in Pike® comes with additional shims installed on the piston to allow the rider to modify the rebound tune. If your rebound setting is one or two clicks from open, we recommend changing to a soft tune on the rebound. - Page 29 Use the chart below to layout the shim stack for your desired tune on your Shim thickness rebound damper piston. Use a metric caliper to verify the shim outer diameter and shim thickness or print the page at 100% scale to arrange the shim stack using the outlines on the page.
- Page 30 Install the shims on a small wrench or pick in the order of your desired tune. Off center hoop shim Slide the shim stack onto the piston face. Use your fingers to squeeze the stack and center the shims. NOTI C E Ensure the hoop shim is centered on the shim stack.
-
Page 31: Charger Damper™ Assembly
2 0 0 H o u r S e r v i c e C h a r g e r D a m p e r ™ A s s e m b l y Spray isopropyl alcohol inside the cartridge tube and compression damper. Pour the alcohol and remaining oil into an oil pan. - Page 32 Wrap a rag around the cartridge tube. Pour RockShox 3wt suspension oil into the cartridge tube until it is full. Insert a 2.5 mm hex wrench into the rebound damper shaft until it contacts the rebound adjuster screw. Turn the hex wrench counter-clockwise until it stops.
- Page 33 Lightly clamp the cartridge tube assembly into the bicycle stand with the compression damper oriented upward. Charger Damper™ Assembly...
-
Page 34: Charger Damper™ Bleed
2 0 0 H o u r S e r v i c e C h a r g e r D a m p e r ™ B l e e d RCT3: Use small retaining ring pliers to remove the retaining ring from the low speed compression adjuster. - Page 35 Use your fingers to install the bottom bolt into the rebound damper shaft, then pull down on the bottom bolt. Cover the top cap with a rag and cycle the rebound damper shaft a few times to pre-bleed air from the damper. Pull the rebound damper shaft down until it stops.
- Page 36 Create a vacuum in the damper assembly by pulling up on the syringe handle and simultaneously pushing up on the rebound damper shaft. This will force bubbles out of the damper assembly. Pressurize the damper assembly by pushing down on the syringe handle and simultaneously pulling down on the rebound damper shaft.
- Page 37 RCT3: Insert the low speed compression adjuster into the compression cam assembly. Push down and turn the low speed compression adjuster clockwise until it clicks into place. RCT3 RC: Use needle-nose pliers to insert the bleed plug into the compression adjuster until it clicks into place.
- Page 38 Push the rebound damper shaft into the cartridge tube. The shaft should not move more than 2 mm if the bleed was successful. If the shaft moves while in the locked position, repeat the bleed procedure. ≤ 2 mm RCT3: Rotate the compression mode adjuster cam counter-clockwise until it stops.
-
Page 39: Charger Damper™ Installation
2 0 0 H o u r S e r v i c e C h a r g e r D a m p e r ™ I n s t a l l a t i o n Remove the rebound bolt from the rebound damper shaft. - Page 40 RCT3: Place the compression mode adjuster knob onto the compression RCT3 top cap with the long tab near the front of the crown. Turn the knob clockwise until it engages the first detent space. RCT3 RC: Place the low speed compression adjuster knob onto the compression top cap with the long tab near the back of the crown.
- Page 41 RCT3: Install the low speed adjuster knob and knob retaining screw. Use a torque wrench with a 2 mm hex bit socket to tighten the nut to 1.0-1.5 N•m (8-13 in-lb). 2 mm 1.0-1.5 N•m (8-13 in-lb) Charger Damper™ Installation...
-
Page 42: Lower Leg Assembly
L o w e r L e g A s s e m b l y 5 0 / 2 0 0 H o u r S e r v i c e L o w e r L e g I n s t a l l a t i o n Spray isopropyl alcohol on the upper tubes and clean them with a rag. - Page 43 Slide the lower leg assembly along the upper tubes until it stops and the spring and damper shafts are visible through the lower leg bolt holes. Use a rag to clean all excess oil from the outer surface of the lower leg. Install a new crush washer on the non-drive side and drive side bottom Damper side bolts.
- Page 44 Refer to the air chart on the fork lower leg and pressurize the air spring to the appropriate pressure for your rider weight. You may see a drop in the indicated air pressure on the pump gauge while filling the air spring; this is normal. Continue to fill the air spring to the recommended air pressure.
