Special Commands

BOOT

The factory software image and default configuration is set for the new
unit. The BOOT command is intended to reboot the unit using specified
software image and selected configuration.
BOOT IMAGE BOOT CFG
The BOOT command with no parameters selects the user settings defined
by the prior "parameterized" BOOT commands.

HELP

The HELP command types the list of all available commands:
HELP- Display this usage
BOOT- Reboot the unit
LINK- Set RF Link Operation Mode
DPORT- Set Data Port Configuration
MPORT- Set Maintenance Port Configuration
ALARM- Alarm Indication and Alarm Control Configuration
SLEEP- Set Sleep Mode Configuration
STATE- Display Status and Statistics
SAVE- Save Current Configuration into Configuration
File
INFO- Display Product ID along with Hardware/Software
Versions
ATI- Display Product ID along with Hardware/Software
Versions
MAP- Operates with Channel Map
DATAMODE- Exit Command Mode
[COMMAND] /?- Display Command Usage

SAVE

www.javad.com
The SAVE command is intended to store the unit's currently used configu-
ration into the User Configuration file. The configuration stored in the User
Configuration file is activated by automatically after unit's reboot.

SLEEP

The SLEEP command determines the sleep mode parameters. The sleep-
ing AW435BT can be activated by real-time CLK, DTR/RTS lines, and
command received through TTL inputs. The user can select one, two, or
all three conditions.
SLEEP [Parameter Name] [Parameters List] [/?]
Parameter Name Parameter List
0 – Do not activate by internal real-time clock
CLK
(1 – 255) – Activate by internal real-time clock after 100 to 25500 msec of sleeping
HW 0 – Do not activate through DTR/RTS lines 1 – Activate through DTR/RTS lines
TTL 0 – Do not activate by external sense lines 1 – Activate by external sense lines
0 – Disable Sleep mode (default)
GTS
(1 – 255) – Go to sleep mode if there is no activity in 10 to 2550 msec

Diagnostics and Identification Commands

INFO

The INFO command is used to retrieve the Radio ID along with its
Hardware version, the loaded real- time software version/revision and
BootLoader's version/revision.
INFO [Parameter Name] [Parameters List] [/?]
Parameter Name Parameter List
Product ID: 35 - HPT435BT;
ID
43 - AW435BT;
SN Six bytes Serial Number (SN)
HW 1.0 - hardware version in numeric "Major.Minor" format
Ver. 1.0 Rev. A - displays software's version in numeric "Major.Minor" format and
SW revision in numeric format (range from 01 to 99) for engineering releases and alpha-
betic format (A to Z) for manufacturing releases
