Connecting HPT435BT and TRIUMPH-1
Connect the external HPT435BT UHF radio to receiver's port B with ca-
ble Accessory Data-Ser cable, ODU-7/D15 (1.8 m) p/n 14-578108-01.
Once you have established a connection between the modem and the
TRIUMPH-1, you will be able to:
• Configure the modem and its components through receiver;
• Send commands to the modem trough receiver;
• Use ModemVU to load new firmware to the modem
• Transmit/receive GNSS data.
www.javad.com
Configuring HPT435BT
• Connect the computer and HPT435BT, as described in "Connecting
HPT435BT and Computer".
• Turn on the modem.
• Start ModemVU.
• Select the HPT435/HPT435BT (Figure 5) in the Options window, and
click OK:
Figure 10. Options window
• Select the COM port the HPT435BT modem is connected to. Click
Connect.
