Networking Commands

LINK

The LINK command is responsible for configuring radio's operation mode.
It has parameters listed below.
Note: In parentheses is shown firmware version, which supports this parameter. If the
firmware version is not specified, it means that this parameter is supported in both ver-
sions.
LINK [Parameter Name] [Parameters List] [/?]
Parameter Name Parameter List
1 - Simplex Transceiver
2 - Simplex Transceiver
7 - Trimtalk 450S transceiver
8 - Trimtalk 450S transceiver
9 - Transparent w/EOT Repeater
10 - Repeater (ArWest Proprietary protocol
11 - Transparent - Trmb Repeater
12 - Transparent w/EOT timeout Transceiver
13 - Transparent w/EOT timeout Transceiver
PROT 14 - STL Transceiver
15 - STL Transceiver
19 - Transparent w/EOT character Transceiver
20 - Transparent w/EOT character Transceiver
23 - TT450S(HW) Transceiver
24 - TT450S(HW) Transceiver
25 - Trimmark3 Transceiver
26 - Trimmark3 Transceiver
27 - Trimmark ||/||e Transceiver
28 - Trimmark ||/||e Transceiver
1- DBPSK
2 - DQPSK, a default settings
3 - D8PSK
MOD
4 - D16QAM
5 - GMSK
6 - 4FSK
0 - 25 kHz (12.5 kHz for Trimmark3 protocol) = 9600 symbols/s
1 - 12.5 kHz = 4800 symbols/s
SPACE 2 - 6.25 kHz = 2400 symbols/s
3 - 20 kHz = 7500 symbols/s
4 - 25 kHz = 19200 symbols/s (available for Trimmark3 protocol only)
www.javad.com
PWRB / PWRW (25 - 46) / (320 - 35000) - RF output Power in dBm / mW
FHOP (only for (0 - 32) - Frequency Hoping Pattern number
firmware ver. 1.8) LINK FHOP command can be processed only if the Channel Map (up to 32 channels)
0 - No Scrambling (a default setting)
SCRAM
(1 - 255) - Seed for Pseudo-Random Sequence Generator
0 - Disable Forward Error Correction (FEC), a default setting
FEC
1 - Enable Reed-Solomon encoding
Base Unit
0 - No Retransmission in the wireless cluster
1- There is Repeater Remote Unit
RTR Rover Unit
0 - Auto Detect (Base or Repeater)
1 - Receive from Repeater
2 - Receive from Base
1 - Enable 4FSK clock correction
CLKCORR
0 - Disable 4FSK clock correction
0 - active AGC signal finding algorithm
1 - HIGH sensitivity level, -70...-117 dBm
SNST 2 - MIDDLE sensitivity level, -40...-90 dBm
3 - LOW sensitivity level -10...-60 dBm
4 - Keep last successfully received packet state
0 - default value = 4 sec.
SYNRT 1 - do not reset the LNA and ADC gain
N - Set Demodulator reset in sec.
sets/gets string type value representing the call sign of transceiver. The length of
CSIGN entered call sign can be less or equal to 10 characters. A-Z letters and 0-9 digits are
accepted.
sets/gets the compatibility with:
0 - Satel 3AS
CMPT
1 - Satel Easy
2 - ADL
sets/gets the Transceiver mode:
0 - Transceiver
RXTX
1 - Receive Only
2 - Transmit Only
sets/gets the SNRM packet send option:
SNRM 0 - Off (default)
1 – On
Note: The frequency defined by CHAN parameter is not valid if Frequency Hoping mode
is selected. In the Frequency Hoping mode, the Frequency Pattern generator must gen-
erate the random numbers smaller than the number of frequencies listed in the unit's
