frequency list.

Serial Interfacing Commands

DPORT

The DPORT is an object that responsible for data port interface configura-
tions like Bit Rate, Flow Control, etc.
DPORT [Parameter Name] [Parameters List] [/?]
Parameter Name Parameter List
0 – Maintenance Port baud rate, a default setting 1 – 1200 baud
2 – 2400 baud
3 – 4800 baud
4 – 9600 baud
RATE 5 – 14400 baud
6 – 19200 baud
7 – 38400 baud
8 – 57600 baud
9 – 115200 baud, a default setting
BITS Set number of bits in one byte (8 or 7) 8 is a default setting
0 – None, a default setting 1 – Odd
PARITY
2 – Even
0 – None, a default setting 1 – Not used
FLOW
2 – HW (RTS/CTS)
0 - RS232, a default setting 1 - RS485
RS
2 - RS422; use save, boot commands to activate modification
0 - UART, a default setting
DATATX 1 - USB
2 - BT
0 - UART, a default setting
DATARX 1 - USB
2 - BT
0 - 1 stop bit, a default setting
STOPBIT 1 - 2 stop bits for non-5-bit word length or
1 1/2 stop bits for 5-bit word length
0 - Disable DTR line interrupt
DTR
1 - Enabled DTR line interrupt
20
0 - Buffering is disabled
BUF
1 - Buffering is enabled
The response of command without Parameter Name indicates all values:
RATE =9
BITS =8
PARITY =NONE
FLOW =HARDWARE
STOPBIT =0
DTR =0
RS =RS232
DATATX =UART
DATARX =UART
BUF =0

IMPORT

The MPORT is an object that responsible for maintenance serial port inter-
face configurations such as data rate and number of bits in a byte.
MPORT [Parameter Name] [Parameters List] [/?]
Parameter Name Parameter List
0 – Auto
1 – 1200 baud
2 – 2400 baud
3 – 4800 baud
4 – 9600 baud
RATE
5 – 14400 baud
6 – 19200 baud
7 – 38400 baud
8 – 57600 baud
9 – 115200 baud, a default setting
Note: JAVAD GNSS radio modem's does not support data flow and parity on the main-
tenance serial port.The radio modem with none-dedicated maintenance serial port must
keep CTS line always active in MPORT mode (DP/MP is low).
