Installing the Wall Mount
For reliable operation, the Thermostat must mount correctly
on the wall mount.
If you have a single gang back box, secure the wall
mount to this using the two M3 screws provided.
If you do not have an existing back box then, using the wall
mount as a template, mark the location of the two holes on
the wall. For reference, the two holes are 60.3 mm apart.
Fig 4
Drill suitable holes (6mm diameter for the supplied wall
plugs) and fix the wall mount to the wall using appropriate wall plugs and screws.
WARNING be aware of any buried cables before drilling.
We would recommend using our supplied screws where possible. If not, ensure the screw
heads do not protrude above the surrounding wall mount plastic.
This unit is designed for fixed wiring only. Wire the unit up following the appropriate circuit
schematic for your heating system type, ensuring that all wires are securely held and that
no bare copper is visible outside the connector block. For ease of wiring, we recommend
1mm2 cable. All wiring should conform to the current IEEE wiring regulations. When
replacing an existing Thermostat, the wiring conversion table, on page 7, may be of
assistance.
All diagrams are in schematic form and earths have been omitted on the drawings for
clarity. This is a class 2 device and does not require an earth. Ensure that you do not break
earth continuity to the rest of the circuit. You may need to join the existing earth leads
together using a terminal strip. Ensure that the circuit is protected by a 3 amp fuse.
