  • Page 1 INSTALLATION & MANUALS NS1001 Plus NS1001 LV Plus NS1001 HL NS1001 Plus Zones NS1001 LV Plus Zones NS1001 HL Zones...
  • Page 2: Table Of Contents

    Test the connection Activation Activation code Unit Codes Installing your Thermostat Before you start Preferred place for your Inspire Thermostat. Removal of your old Thermostat Install the wall mount Prepare you new Inspire Thermostat Wiring your Inspire Thermostat Install the Thermostat...
  • Page 3: What's In The Box

    1 x Room Thermostat 1 x Wall Mount 1 x Wiring Cover 1 x Internet Gateway 1 x Network Cable 1 x Power Supply 2 x AA Batteries 2 x Screws 2 x Wall Plugs Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 4: Your Thermostat

    Enter the programming menu or activate program advance. (PLUS unit only) Select / Boost Multipurpose, changes function and cycles menu options. Activates the Boost function. (PLUS unit only) Adjustment Keys Multipurpose, these are used to adjust the desired temperature and program times. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 5: Your Gateway

    If you do not wish to wait this long, reset the Room Thermostat by pressing and holding all four buttons for 5 seconds. Upon reset, the connection should be made within a few seconds. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 6: Status Lights

    Flashing amber Amber Green Power light No power Initialising Ready Establishing Connection Internet light No connection Unregistered Connection Established Thermostat not Connection RF Light No device paired Pairing connected Established Power Internet Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 7: Test Your Inspire Thermostat

    6. Remove the batteries. Test the connection Before you install your new Inspire Thermostat on the wall we recommend you test the connection between the Thermostat and the Gateway box. 1. Unpack the power supply and plug in the Gateway.
  • Page 8: Activation

    Gateway and wait for the left hand power light to become solid green. Insert the batteries into the Thermostat, leave for 5 minutes and try accessing your activation Inspire Home Automation code again. www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 9: Installing Your Thermostat

    Before you start Do I need to install my Inspire Thermostat somewhere new? We find that most Thermostats are located in rooms that have limited use. The position of these Thermostats mean the temperature could be warmer or colder than the homeowners feel.
  • Page 10: Preferred Place For Your Inspire Thermostat

    The homes construction and arrangement may affect the communication so consideration is needed. ° Place your Inspire Thermostat so you can easily access and read the on screen display. ° Install on an interior wall. ° Make sure your Thermostat is away from any drafts.
  • Page 11: Removal Of Your Old Thermostat

    3. Tape the wires together to stop them from falling back into the wall and continue to remove your old Thermostat. Prepare you new Inspire Thermostat 1. Remove the two securing screws from the bottom edge of the Thermostat and lift the Thermostat off the wall mount.
  • Page 12: Wiring Your Inspire Thermostat

    / or a damaged room thermostat. Inspire Home Automation will not accept any liability whatsoever for damage caused to your central heating system and/or electrical system as a result of the incorrect wiring of the thermostat. Also damage to the thermostat due to incorrect wiring is not covered by your guarantee.
  • Page 13: Install The Thermostat

    Using your new Thermostat If you have previously followed the instructions to activate your account then you have finished installation and your Inspire Thermostat will be ready to use. 1. Make sure your Gateway box is connected and switched on.
  • Page 14: Basic Functions

    The Menu button is used to set the clock. However, if you have an Internet connection this will be done automatically. If you are outside of the United Kingdom then you can specify your time zone on the ‘Setup’ page within your online account. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 15: Setting The Clock

    Thermostat is in profile mode (P1 or P2). Pressing the key a 2nd time will cancel the program advance and the unit will revert back to the set temperature. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 16: Installing Additional Thermostats

    Radio Frequency 2.4 GHz Dimensions 119 x 88 x 22 mm Gateway Power input 5V 1A Internet Connection Wired Ethernet Cable Radio Frequency 2.4 GHz Dimensions 94 x 79 x 24 mm Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 17: Troubleshooting

    (WiFi) Therefore ensure that your Gateway and internet router are separated. Move the Gateway closer to your Room Thermostat. This can normally be achieved by using Home Plugs or a longer network cable. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 18 Room Thermostat is powered up, the low battery indicator is not flashing, and that the RF Link on the Thermostat is displayed. Check the “My Thermostat will not pair or repeatedly loses connection” above for information on how to improve this. Inspire Home Automation www.insiprehomeautomation.co.uk Installation & User manual...
  • Page 19: Ec Declaration Of Conformity

    EC Declaration of Conformity EC Declaration of Conformity in accordance with EN ISO 17050-1:2004 Inspire Home Automation Limited 13 Barrow Way, Bournemouth, Dorset, BH8 0HZ In accordance with the following Directives: 2006/95/EC The Low Voltage Directive 2004/108/EC The Electromagnetic Compatibility Directive...
