What's in the box
1 x Ignite Signal Booster
1 x Power Supply
Introduction
An Ignite Signal Booster is used when the Ignite components have to be positioned
in such a way that they are not within radio range of each other, or the radio signal
strength is poor. This may happen if the Ignite system is installed in a large house or
a house with thick walls or a building where components are located over several
floors.
Power Light
Ignite Signal Booster User Guide Rev 1.3
Power
Socket
Connected to
Inspire System
Pairing
Button
A device is connected
to this signal booster
1
Advertisement
Related Manuals for Inspire Ignite
Summary of Contents for Inspire Ignite
- Page 1 This may happen if the Ignite system is installed in a large house or a house with thick walls or a building where components are located over several floors.
- Page 2 Positioning The best place for the repeater would be halfway between the unit(s) which are struggling to communicate and the powered device (Receiver or Wired Thermostat) Please note that messages cannot “Hop” between Battery operated devices (Wireless Thermostats and Smart Sensors) See the diagram below.
- Page 3 Pairing Before the Ignite Signal Booster can be used, it must be paired to the Ignite System. Ensure that the Ignite Signal booster is showing a green power light. Ignite Touch / LITE / Wireless Long press BOTH buttons on the Receiver until `1 and WiFi’ lights flash.
- Page 4 Or take the batteries out of a device, wait for 30 seconds to allow any residual power to fully dissipate, and then put the batteries back in again. To reset the Ignite Touch To reset the Ignite Smart Sensor, Thermostat, press and hold the up press and hold the two buttons for 5 and down arrows for 30 seconds.
