  • Page 1 Ignite - Wireless rev 2.0 www.inspirehomeautomation.co.uk...

  • Page 2: What's In The Box

    BS 7671 (IEE Wiring Regulations) and should be installed in accordance to , or to another equivalent standard. WHAT'S IN THE BOX 1 x Ignite Wireless 1 x Ignite Wireless 1 x Screw Pack 2 x AA Thermostat Receiver &...

  • Page 3: Specification

    INTRODUCTION The Ignite Wireless series is designed to control a typical domestic central heating system. The system can switch two independent channels. This would usually be the Central Heating and the Hot Water (if applicable). If you do not have a typical gas / oil fired central heating system, please see www.inspirehomeautomation.co.uk/other_heating...
  • Page 4 If you have a large number of WiFi devices in the property or you cannot get a good WiFi signal at your Receiver location (you can use your phone to get a good indication of WiFi signal strength), then we would strongly recommend that you www.inspirehomeautomation.co.uk/wifi upgrade your WiFi Network.
  • Page 5 Fig 2 Fig 2 shows another two possible positions. The Thermostat located at B will have the signal travelling entirely through a solid wall. This will create a very poor signal, or no signal at all. When moved to position A the signal will be considerably stronger. Fig 3 Fig 3 As shown in...
  • Page 6 The room where the Thermostat is located must have a working radiator and the Thermostatic must be Radiator Valve (TRV) removed if present. Most TRV's can be removed by turning it up to the maximum setting, gently pushing down from the top and undoing the metal collar.

  • Page 7: Installation

    Please consult your boiler installation manual for guidance on how to wire in external controls. Usually, there will be a wire link to remove on the boiler terminal block, then these two terminals are wired to terminals 3 & 4 on the Inspire Fig 6 Terminal board as shown in Connect the Receiver Live(L) and Neutral(N) to the same fused spur as the boiler.
  • Page 8 The majority of combi boilers can be wired using the 4 wire installation method. If Fig 7 your boiler manual suggests a 3 wire install, then refer to , remembering to remove the link wire in the boiler (if required) and add a link wire between terminals 4 &...
  • Page 9 SYSTEM BOILER WITH EXISTING CONTROLS System Boiler with existing 2 channel programmer and optional Thermostat **Before commencing, take clear photos of the existing programmer wiring** S Plan (2 x 2 port zone valves, usually near hot water cylinder) Usually 4 Wires to existing programmer, Live, Neutral, CH ON, HW ON. (CH OFF and HW OFF not used) Y plan (1 x 3 port zone valve, usually near the hot water cylinder) Usually 5 wires to existing programmer, Live, Neutral, CH ON, HW ON, HW OFF.
  • Page 10 Once each wire is identified, remove the existing wires from the old programmer Installation - Wall Mount and install the Inspire Ignite Receiver as described in page 11. Fig 9 Install the previously identified wires into the appropriate terminals (see ).

  • Page 11: Installation - Wall Mount

    INSTALLATION - THERMOSTAT Preparing your new Thermostat Pull the thermostat away from the wall mount. There is a back panel that can be used to fully cover single gang back boxes. If this is not required, it can be Fig 10 removed from the wall mount by twisting it anti-clockwise.

  • Page 12: Testing The System

    If this is an additional Thermostat, then select User -> Add Device from within the app. Windows / Mac Follow our simple, 3 step, online setup www.inspirehomeautomation.co.uk/start To start, please browse to: Important You will need to be in the same location as the inspire system to complete the initial setup.
  • Page 13 IGNITE THERMOSTAT IGNITE RECEIVER Fig 12...
  • Page 14 BASIC FUNCTIONS (HEATING) Your heating will be switched off. Auto Your Thermostat will follow its Heating Schedule The default is: (This can be adjusted via your online account) 15 Degrees between 00:00 and 06:00 20 Degrees between 06:00 and 08.30 17 Degrees between 08:30 and 17:00 22 Degrees between 17:00 and 22:30 15 Degrees between 22:30 and 00:00...

  • Page 15: Setting The Clock

    BASIC FUNCTIONS (HOT WATER) Your hot water will be switched off. Auto Your Thermostat will follow its Hot Water Schedule The default is: (This can be adjusted via your online account) On between 06:00 and 08.30 On between 12:00 and 13:00 On between 18:00 and 20:00 Your hot water will be switched on and will keep your hot water cylinder at the temperature set by your cylinder thermostat.

  • Page 16: Video Tutorials

    Inspire system. PHONE APP Please go to this weblink to download the app www.inspirehomeautomation.co.uk/apps or search for Inspire Home Automation in the app store. TROUBLESHOOTING Please visit our website for further help and assistance: www.inspirehomeautomation.co.uk/help...
