Inspire NS1003 Installation Manual

CAUTION: High Voltage Wires
WARNING Electricity is dangerous. Before commencing work, ensure that you read and understand these instructions and isolate
the relevant circuit. This product should only be installed by a qualified electrician or heating engineer and should be installed
in accordance to BS 7671 (IEE Wiring Regulations), or to another equivalent standard.
Whats in the box
2(or 3) x Assembled Room Thermostat consisting of
1 x Room Thermostat
1 x Wall Mount
1 x Assembled Relay Module consisting of
1 x Control Board
1 x Wall Mount
1 X Front Cover
1 x Gateway
1 x Network Cable
1 x Power Supply
2(or 3) x Thermostat screw pack
1 x Relay Module Screw Pack
4(or 6) x Batteries
Introduction
The NS1003 series is designed to control a typical domestic central heating system. The Relay module
can switch three independent channels. This would usually be the 2 Central Heating Zones and the Hot
Water or 3 Central Heating Zones.
The central heating channel is switched on and off in response to commands from the supplied Wireless
Thermostat.
The Hot Water channel is switched on and off at the programmed time intervals that the user sets.
NS1003 Installation Guide
Power Supply
Inspire Home Automation
www.inspirehomeautomation.co.uk
contact@inspirehomeautomation.co.uk
01202 798390
Rev 1.1
Gateway
Room Thermostat
Relay Module Thermostat
Screw Pack Screw Pack
Relay Module
Batteries Network Cable
1
