CAUTION: High Voltage Wires
WARNING Electricity is dangerous. Before commencing work, ensure that you read and understand these instructions and isolate
the relevant circuit. This product should only be installed by a qualified electrician or heating engineer and should be installed
in accordance to BS 7671 (IEE Wiring Regulations), or to another equivalent standard.

Whats in the box

1 x Assembled Room Thermostat consisting of
1 x Room Thermostat
1 x Wall Mount
1 x Assembled Relay Module consisting of
1 x Control Board
1 x Wall Mount
1 X Front Cover
1 x Gateway
1 x Network Cable
1 x Power Supply
1 x Thermostat screw pack
1 x Relay Module Screw Pack
2 x Batteries
Introduction
The NS1002 series is designed to control a typical domestic central heating system. The Relay module
can switch two independent channels. This would usually be the Central Heating and the Hot Water.
The central heating channel is switched on and off in response to commands from the supplied Wireless
Thermostat.
The Hot Water channel is switched on and off at the programmed time intervals that the user sets.
NS1002 Installation Guide
Gateway
Power Supply
Inspire Home Automation
www.inspirehomeautomation.co.uk
contact@inspirehomeautomation.co.uk
01202 798390
Rev 1.4
Room Thermostat
Relay Module
Thermostat
Screw Pack
Screw Pack
Relay Module
Batteries
Network Cable
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS1002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inspire NS1002

  • Page 1: Whats In The Box

    2 x Batteries Introduction The NS1002 series is designed to control a typical domestic central heating system. The Relay module can switch two independent channels. This would usually be the Central Heating and the Hot Water. The central heating channel is switched on and off in response to commands from the supplied Wireless Thermostat.
  • Page 2: Specifications

    Also, the radio can be adversely affected by large metal objects such as your boiler, radiators and mirrors. For best performance, ensure that your units are placed at least 1 metre away from such objects. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk...
  • Page 3  The Relay Module is positioned away from metal objects.  The Gateway is positioned centrally between the Thermostat and Relay Module.  The Room Thermostat has been positioned to avoid the staircase. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 4 Do you have a valid internet connection? Check by plugging in another device. • Unplug both the Router and the Gateway. Wait 30 seconds, then plug the router back in. Wait 2 minutes, then plug our Gateway back in. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 5 All diagrams are in schematic form and earths have been omitted on the drawings for clarity. The NS1002 is a class 2 device and does not require an earth. Ensure that you do not break earth continuity to the rest of the circuit.
  • Page 6: Wiring Diagrams

    Wiring Diagrams S Plan Y Plan fig. 2 fig. 1 Programmer Programmer Combi Boiler Single Zone Two Zone fig. 3 fig. 4 Programmer Programmer Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 7 ° Wall mount screws are the correct size Hold the room thermostat in place and lightly tighten the screws underneath to secure the unit – these screws only need the lightest of pressure and must not be over tightened Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk...
  • Page 8: Testing The System

    Once you have ascertained that the unit is functioning correctly, push the front cover over the Relay Module until it clips into place. Finally remove the protective film from the cover. Please leave this installation manual with the user. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk...
  • Page 9 (CH) to pair the central heating channel to a thermostat, this will start the light flashing, • Press and hold the ‘S’ and ‘-’ keys on the Room Thermostat until the RF indicator in the lower left hand corner starts to flash. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
  • Page 10: Wiring Conversions

    SMITHS IND. CENTROLLER 1000 N SWITCHMASTER 800, 805, 900, 9000, 9001 Table 1 Please note: if there is no cable in the above position, then leave this position blank on the relay module. Inspire Home Automation www.inspirehomeautomation.co.uk contact@inspirehomeautomation.co.uk 01202 798390...
