Functions
3. Press the left or right arrow key to select F1 (field 1), F2 (field 2), or All.
(See Figure 42.)
NOTE.
For dual link signals in fast progressive video formats, use the arrow
keys to select Link A or Link B.
In the Datalist display, press the SEL button to toggle between Line Select and
Sample Select.
4. The line and field information will appear at the bottom of the display screen.
5. Use the General knob or the up/down arrow keys to select a video line to view.

Figure 42: Navigating line selection
