Edid Control - BluStream HDCP11AB User Manual

Rear Panel
HDMI LED indicator - Lit when detecting a HDMI
1
connection to a display/end point.
Digital Coaxial Out—Extracted audio from the HDMI input.
2

EDID Control

EDID (Extended Display Identification Data) is a data structure that
is used between a display and a source. This data is used by the
source to find out what audio and video resolutions are supported
by the display then from this information the source will determine
what the best resolution is to output.
While the objective of EDID is to make connecting a digital display
to a source a simple plug and play procedure issues do arise when
multiple displays or video matrix switching is introduced because
of the increased number of variables.
By pre-determining the video resolution and audio format of
the source and display device you can potentially work around
compatibility issues associated with some display and source
combinations.
To change the EDID settings move the EDID dip-switches as
required on the front panel of the unit. Please see adjacent
table for settings.
Note: You must power-cycle the HDCP11AB after changes
have been made in order for the EDID settings to update.
04
1
Analog Out HDMI Output
3 4
3
4
3
Combination of DIP positions
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
HDCP11AB
2
Coaxial Out
L/R Out Analogue Audio Out - Extracted audio from HDMI
input (Compatible with 2ch PCM only).
HDMI Output - Connect to the HDMI display.
2 1 0
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
1 1 1
USER MANUAL
EDID Type
Copy EDID from output
1080P 2.0CH
1080P 5.1CH
1080P 7.1CH
1080i 2.0CH
1080i 5.1CH
1080i 7.1CH
3D 2.0CH
3D 5.1CH
3D 7.1CH
4K 2.0CH
4K 5.1CH
4K 7.1CH
DVI 1280x1024
DVI 1920x1080
DVI 1920x1200
www.blustream.co.uk
