Quick Guide
1 1
Alarm/
Warning
Fault
number Number
47
48
50
51
52
53
54
55
56
57
58
59
60
66
69
79
80
87
95
200
202
250
251
24
Bit
Fault text Warning Alarm
Control
23 Voltage Fault X
VDD1 Supply
25 Low
AMA
Calibration
failed
AMA
15 Unom,Inom
AMA low Inom
AMA big
motor
AMA small mot
AMA par.
range
AMA user
interrupt
AMA timeout
AMA internal X
25 Current limit X
External
44 Interlock
Heat sink
Temperature
26 Low X
Pwr. Card
1 Temp X
Illegal power
section config-
uration X
Drive
29 initialised
Auto DC
47 Braking X
40 Broken Belt X
Fire Mode X
Fire Mode
Limits
Exceeded X
New sparepart
New Typecode
MG.18.A1.02 - VLT
VLT HVAC Basic Drive FC 101 Quick Guide
Trip
locked Cause of problem
X X 24 V DC may be overloaded.
X X Control voltage low. Please contact your local Danfoss supplier
X Contact your local Danfoss supplier.
The setting of motor voltage, motor current and motor power is
X presumably wrong. Check the settings.
X The motor current is too low. Check the settings.
X The motor is too big for the AMA to be carried out
X The motor is too small for the AMA to be carried out
The parameter values found from the motor are outside acceptable
X range
X The AMA has been interrupted by the user
Try to start the AMA again a number of times, until the AMA is
carried out. Please note that repeated runs may heat the motor to a
level where the resistance Rs and Rr are increased. In most cases,
X however, this is not critical
X Contact your local Danfoss supplier.
The current is higher than the value in par. 4-18 Current Limit
External interlock has been activated. To resume normal operation,
apply 24V DC to the terminal programmed for external interlock and
reset the frequency converter (via serial communication, digital I/O,
X or by pressing reset button on keypad).
This warning is based on the temperature sensor in the IGBT module
(Only on 400V 30-90 kW units).
The temperature sensor on the power card is either too hot or too
X X cold.
X Internal fault. Contact your local Danfoss supplier.
X All parameter settings are initialized to default settings.
The drive is auto DC braking
Torque is below the torque level set for no load, indicating a broken
X belt. See parameter group 22-6.
Fire mode has been activated
Fire Mode has suppressed one or more warranty voiding alarms
The power or switch mode power supply has been exchanged. (Only
X X on 400V 30-90 kW units). Contact your local Danfoss supplier
The frequency converter has a new type code (Only on 400V 30-90
X X kW units). Contact your local Danfoss supplier.
®
