Quick Guide
1 1
Closed Loop Set-up Wizard
No & Name
0-03 Regional Settings
1-20 Motor power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
4-12 Motor Speed Low Limit [Hz]
4-14 Motor Speed High Limit [Hz]
3-41 Ramp 1 Ramp up time
3-42 Ramp 1 Ramp down time
1-73 Flying Start
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
6-19 Terminal 53 mode
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low Ref./Feedb.
Value
6-15 Terminal 53 High Ref./Feedb.
Value
6-16 Terminal 53 Filter Time
Constant
20-81 PI Normal/Inverse control
20-83 PI Start Speed
20-93 PI Proportional Gain
1-29 Automatic Motor Adaption
(AMA)
16
VLT HVAC Basic Drive FC 101 Quick Guide
Range Default Function
[0] International 0
[1] US
0.09-110kW Size related Enter motor power from nameplate data
50.0 - 1000.0V Size related Enter motor voltage from nameplate data
20.0 - 400.0Hz Size related Enter motor frequency from nameplate data
0.01 - 10000.00A Size related Enter motor current from nameplate data
100.0 - 9999.0RPM Size related Enter motor nominal speed from nameplate data
0.0 - Hz 0.0 Hz Enter the minimum limit for low speed
0-Hz 65Hz
0.05 - 3600.0 s 3 Ramp up time from 0 to rated motor frequency par. 1-23
0.05 - 3600.0 s 3 Ramp down time form rated motor frequency par. 1-23 to 0
[0] Disabled 0 Select Enable to enable the drive to catch a spinning motor
[1] Enabled
-4999-4999 0 The minimum reference is the lowest value obtainable by summing all
references
-4999-4999 50 The maximum reference is the highest value obtainable by summing all
references
-100-100% 0 Enter the set point
[0] Current 1 Select if terminal 53 is used for current- or voltage input
[1] Voltage
0-10V 0.07V Enter the voltage that corresponds to the low reference value
0-10V 10V Enter the voltage that corresponds to the low high reference value
0-20mA 4 Enter the current that corresponds to the high reference value
0-20mA 20 Enter the current that corresponds to the high reference value
-4999-4999 0 Enter the feedback value that corresponds to the voltage or current set
in par. 6-10/6-12
-4999-4999 50 Enter the feedback value that corresponds to the voltage or current set
in par. 6-11/6-13
0-10 s 0.01 Enter the filter time comstant
[0] Normal 0 Select Normal [0] to set the process control to increase the output
[1] Inverse speed when the process error is positive. Select Inverse [1] to reduce the
output speed.
0-200Hz 0 Enter the motor speed to be attained as a start signal for
commencement of PI control
0-10 0.01 Enter the process controller proportional gain. Quick control is obtained
at high amplification. However if amplification os too great, the process
may become unstable
Off Performing an AMA optimizes motor performance
®
