- Page 1 LMX2430/33/34 Evaluation Board User's Guide November 2013 SNAU049A...
- Page 2 LMX2430/33/34 Evaluation Board Instructions SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 3: Table Of Contents
C: F ......................20 PPENDIX ABRICATION AND SSEMBLY D: B ..........................20 PPENDIX ILL OF ATERIALS E: Q EVM C ..................22 PPENDIX UICK TART FOR OMMUNICATIONS November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 4: Equipment
The oscilloscope and probes should be capable of measuring the output frequencies of interest when evaluating this board. The Agilent Infiniium DSO81204A was used in creating these evaluation board instructions. SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 5: Basic Operation
OSCin SMA SMA 10 MHz Cable Cable Power Signal Supply Generator 5.0 V 4. Run CodeLoader4.exe 5. Select the Device on board by “Select Device” “PLL-Dual integer” LMX24xx November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 6 VCO on the board. Press “Enter” after making a change. 7. To program the settings into the device, Click “Keyboard Controls” “Load Device”, or Press CTRL + L SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 7: Lmx243X Board Information
T3/T1 Ratio (%) 220.8 177.1 213.9 C1_LF (nF) 0.18 0.27 C2_LF (nF) C3_LF (nF) C4_LF (nF) Open Open Open R2_LF (Kohm) R3_LF (Kohm) 0.82 0.82 0.68 R4_LF (Kohm) November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 8: Lmx2430 Measurements
LMX2430 Measurements SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 9 Spur at 1600 MHz VCO frequency is -79.9 dBc. Spur at 1650 MHz VCO frequency is -79.5 dBc. Note that this spur symmetrical. Spur at 1675 MHz VCO frequency is -77.6 dBc. November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 10: Lmx2433 Measurements
LMX2433 Measurements SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 11 Spur at 3300 MHz VCO frequency is - 83.4 dBc. Spur at 3400 MHz VCO frequency is - 83.6 dBc. Note that this spur symmetrical. November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 12: Lmx2434 Measurements
LMX2434 Measurements SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 13 Spur at 4690 MHz VCO is - 77.1 dBc. Spur at 4790 MHz VCO frequency is -79.1 dBc. Spur at 4890 MHz VCO frequency is -76.5 dBc. November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 14: Appendix A: Schematic
C2pRF T BD T BD T BD OSCin R2pRF C2_RF 51 ohm Open T BD 51 ohm =organization Vcc_PLL =title Open Open Ftest/LD =documentnumber =revision Open Red LED SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 15: Appendix B: Build Diagram
Appendix B: Build Diagram November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 16: Top Layer
Top Layer SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 17 GND Layer November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
- Page 18 POWER Layer SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com...
- Page 19 Bottom Copper November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
-
Page 20: Appendix C: Fabrication Anda
16 mils thick GND Layer [LMX2434.G1] FR4 ( = ~4.6) ?? mils thick, but thinner is preferable POWER Layer [LMX2434.G2] ?? mils thick Bottom Copper – Thermal relief [LMX2434.GBL] SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com... -
Page 21: Appendix D: Bill Of Materials
RF Microdevices/VARIL VCO690-4790T 100 pF Kemet C0603C101J5GAC C1_RF 3.9 nF Kemet C0603C392J5GAC C2_RF 1 nF Kemet C0603C102J5GAC C3_RF 3.3 k Vishay/Dale CRCW06033K30JNEA R2_RF 680 ohm Vishay/Dale CRCW0603680RJNEA R3_RF November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com... - Page 22 OPTION 1 Open Codeloader.exe Click “Select Device” Click “Port Setup” tab Click “LPT” (in Communication Mode) OPTION 2 SNAU049A LMK2430/33/34 Family November 2013 Copyright © 2013, Texas Instruments Incorporated www.ti.com...
- Page 23 Open Codeloader.exe Click “Select Device” Click “Port Setup” Tab Click “USB” (in Communication Mode) *Remember to also make modifications in “Pin Configuration” Section according to Table above. November 2013 LMK2430/33/34 Family SNAU049A Copyright © 2013, Texas Instruments Incorporated www.ti.com...
