Furuno VR-7000 Installation Manual

Furuno VR-7000 Installation Manual

Voyage data recorder
Hide thumbs Also See for VR-7000:

Advertisement

Quick Links

See also: Operator's Manual , Instruction Manual
SAFETY INSTRUCTIONS ........................i
SYSTEM CONFIGURATION ..................iii
EQUIPMENT LIST ..................................iv
1. MOUNTING......................................1-1
1.2 Data Recording Unit (DRU) ................1-3
1.3 Junction Box VR-7022F ....................1-11
1.5 Microphone VR-7011 ........................1-14
1.8 Sensor Adapter MC-3000S/3010A/
3020D ...............................................1-23
1.9 Intelligent HUB HUB-3000 ................1-24
1.13 Junction Box IF-8540 (Option) ..........1-27
2. WIRING............................................2-1
2.2 Data Recording Unit..........................2-10
2.3 Junction Box VR-7022F ....................2-13
2.4 Remote Alarm Panel VR-7017..........2-15
2.5 Microphone VR-7011 ........................2-16
2.6 Waterproof Microphone VR-7012W ..... 2-17
2.7 Video LAN Converter IF-7100...........2-18
2.8 Sensor Adapters ...............................2-25
2.9 Intelligent HUB HUB-3000 ................2-40
2.10 Power Supply Unit PSU-011.............2-40
2.11 Junction Box IF-8530 (Option) ..........2-41
2.12 IP Addresses of the Unit ...................2-44
3.1 System Time Adjustment ....................3-1
Converter ............................................3-3
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
APPENDIX 2 CABLE
APPENDIX 4 DIGITAL
APPENDIX 5 CODING OF THE
PACKING LISTS ................................. A-1
OUTLINE DRAWINGS ........................ D-1
INTERCONNECTION DIAGRAMS ..... S-1
www.furuno.com
VR-7000
Model
(VOYAGE DATA RECORDER)
FABRICATION ...........AP-2
INTERFACE .............AP-13
FLOAT-FREE DRU ..AP-31
VDR

Advertisement

loading
Need help?

Need help?

Do you have a question about the VR-7000 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno VR-7000

Summary of Contents for Furuno VR-7000

  • Page 1 Installation Manual VR-7000 Model (VOYAGE DATA RECORDER) SAFETY INSTRUCTIONS ......i APPENDIX 1 JIS CABLE GUIDE..AP-1 SYSTEM CONFIGURATION ....iii APPENDIX 2 CABLE FABRICATION ...AP-2 EQUIPMENT LIST ........iv APPENDIX 3 ROD TERMINALS ..AP-7 APPENDIX 4 DIGITAL 1. MOUNTING........1-1 INTERFACE .....AP-13 1.1 Data Collecting Unit VR-7010 .....1-1 APPENDIX 5 CODING OF THE 1.2 Data Recording Unit (DRU) ....1-3...
  • Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : JUL 2014 Printed in Japan All rights reserved. K1 : APR . 19, 2016 Pub. No. IME-44850-K1 ( REFU ) VR-7000 0 0 0 1 7 9 3 4 6 1 9...
  • Page 3 SAFETY INSTRUCTIONS The installer of the equipment must read the safety instructions before attempting to install the equipment. DANGER Indicates a potentially hazardous situation which, if not avoided, will result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, WARNING could result in death or serious injury.
  • Page 4 SAFETY INSTRUCTIONS CAUTION Use the proper fuse. Use of an incorrect fuse may damage the equipment. Observe the following compass safe distances to prevent deviation of a magnetic compass: Standard Steering Unit compass compass Data Collecting Unit 2.30 m 1.45 m VR-7010 Remote Alarm Panel 1.15 m...
  • Page 5 SYSTEM CONFIGURATION Basic configuration is shown with solid line. Fixed Data Recording Unit (Fixed DRU) Switching HUB Radar, ECDIS, etc. VR-7020 HUB-100 100-230 VAC Float-free Data Recording Unit Junction Box (Float-free DRU) Max. 2 units VR-7022F VR-7021F VHF Audio Remote Alarm Panel VR-7017* Live Player V5 : Nominal viewing distance: 0.5 m...
  • Page 6 EQUIPMENT LIST Standard Supply Name Type Code No. Remarks Data Collecting Unit VR-7010 Remote Alarm Panel VR-7017 Fixed Data Recording Unit VR-7020 Float-free Data Recording Unit VR-7021F Junction Box VR-7022F Microphone VR-7011 Waterproof Microphone VR-7012W Video LAN Converter IF-7100 Sensor Adapter MC-3000S Power Supply Unit PSU-011...
  • Page 7 SP03-15001 001-042-330 For HUB-100 Spare Parts SP24-00801 001-235-320 For HUB-3000 SP24-01201 001-279-160 For IF-7100 Crimping Tool CRIMPFOX 10S 001-206-920 For ferrule Operator’s Manual OME-44850-* 000-179-342-1* For VR-7000 OME-44851-* 000-179-350-1* For Live Player V5 Instruction Manual OME-44852-* 000-179-352-1* For Maintenance Viewer...
  • Page 8 EQUIPMENT LIST This page is intentionally left blank.

  • Page 9: Mounting

    MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Data Collecting Unit VR-7010 Mounting consideration Select a mounting location, keeping in mind the following points: •...
  • Page 10 1. MOUNTING Mounting Install the data collecting unit (DCU) on a bulkhead. 1. Fasten the unit with four M10 bolts or 10 coach bolts (local supply). Eye bolt M10 bolt Ø10 coach bolt (4 pcs) 2. Two eye bolts are attached at the top of the unit to hoist the unit onboard. Remove them after the installation.

  • Page 11: Data Recording Unit (Dru)

    1. MOUNTING Data Recording Unit (DRU) 1.2.1 Fixed data recording unit VR-7020 The fixed DRU shall be sited in the vicinity of the bridge on the external deck area of the vessel so as to maximize the probability of its survival and recovery following an incident.
  • Page 12 1. MOUNTING "Hull Ground Technique” and “Mounting Base Template Pattern” Apply silicone sealant Hex. bolt Flat washer Lock washer Spring washer Hex. nut Hull Grounding Technique DIAMETER 0.594 inches 0.594 inches 3.451 inches 3.451 inches 15.0 mm DIAMETER 87.64 mm 87.64 mm 6.901 inches 175.29 mm...
  • Page 13 1. MOUNTING 1.2.2 Float-free data recording unit VR-7021F Mounting consideration Select a mounting location, keeping in mind the following points: • The float-free DRU should, with greatest possible probability, float-free and avoid being caught in railings, superstructure, etc., if the ship sinks. •...
  • Page 14 1. MOUNTING • Do not bend the cable base of the float-free DRU. Also, do not damage the cable. Float-free DRU Float-free DRU Do not bend the cable base. • Do not bend and/or twist the cable excessively to secure the cable. Ensure a mini- mum bend radius of 80 mm.
  • Page 15 1. MOUNTING 2. Fix the mounting bracket with the supplied installation materials. Detailed view Flat washer Fixing holes Socket head Spring washer (six places) bolt Hex. nut Bracket 3. Apply the supplied silicone grease between the docking module and storage mod- ule, then reattach the capsule.
  • Page 16 1. MOUNTING 4. Confirm the following points; • There is no space or foreign material between the storage module and docking module. • The notch on the docking module is placed in the groove of the storage module. The notch on the docking module is placed in the groove of the storage module.
  • Page 17 1. MOUNTING Example: When the expiration date is April 2019. The expiration date is indicated on this sticker. “2019” is cut out or filled with a permanent marker. “4” is cut out or filled with a permanent marker. • Hydrostatic release unit The expiration date of the hydrostatic release unit is indicated on the sticker at- tached to the side of the unit or the sticker on the side of the bracket.
  • Page 18 1. MOUNTING Attaching the SOS placard The SOS placard is supplied with the float-free DRU. The SOS placard provides the procedure for how to remove the capsule from the float-free DRU manually. Attach the SOS placard to the conspicuous bulkhead or handrail near the float-free DRU. 148.0 3 ×...

  • Page 19: Junction Box Vr-7022F

    1. MOUNTING Junction Box VR-7022F Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. • Select a location where the shock and vibration are minimal. • Make the maintenance space shown in the outline drawing for maintenance and checking purpose.

  • Page 20: Remote Alarm Panel Vr-7017

    1. MOUNTING Remote Alarm Panel VR-7017 Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. • Select a location where the shock and vibration are minimal. • Locate the unit away from places subject to water splash and rain. •...
  • Page 21 1. MOUNTING 6. Remove the front cover of the unit by hand. Front cover 7. Set the unit to the mounting hole, then fix the unit with four self-tapping screws (supplied). Bulkhead Bulkhead Self-tapping screw (4 pcs) 8. Attach the front cover to the unit. 1-13...

  • Page 22: Microphone Vr-7011

    1. MOUNTING Microphone VR-7011 A maximum of eight microphones (waterproof, non-waterproof) can be connected to the DCU. Audio coverage: Hemisphere area of 3.5 m approx. in radius Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. •...
  • Page 23 1. MOUNTING Mounting The microphone is designed to be flush-mounted. 1. Make a mounting hole in the mounting location and prepare four pilot holes, refer- ring to the outline drawing at the back of this manual. 2. Remove four binding screws to detach the back cover of the unit. Binding screw (4 pcs) Back cover...
  • Page 24 1. MOUNTING How to replace the VR-5011 with the VR-7011 The mounting holes of the Microphone VR-5011 (for previous models) can be reused when replacing the VR-5011 with the VR-7011, using the optional microphone re- placement kit OP24-44. 1. Remove four screws to remove the fixing plate from the VR-7011. Fixing plate Location of screw VR-7011...

  • Page 25: Waterproof Microphone Vr-7012W

    1. MOUNTING Waterproof Microphone VR-7012W A maximum of eight microphones (waterproof, non-waterproof) can be connected to the DCU. Audio coverage: Hemisphere area of 3.5 m approx. in radius Mounting considerations Select a mounting location, keeping in mind the following points: •...
  • Page 26 1. MOUNTING When the cable entrance is the SC lock 1. Remove four binding screws to detach the front panel from the waterproof cover. Front panel Front panel Binding screw Binding screw (4 pcs) (4 pcs) Waterproof Waterproof cover cover 2.
  • Page 27 1. MOUNTING 4. Fabricate the cable. The SC lock can clamp the cable at the sheath or cable jacket. Select where to clamp the cable, then fabricate the cable. The method of fabrication changes with the clamping location. When the sheath is fixed with the SC lock Armor: Aluminum tape Cut same length as the cable jacket.
  • Page 28 1. MOUNTING 8. After wiring, tighten the nut according to the information in the table below. Clearance Clamp location Clearance Torque Cable jacket 2.0 mm 2.0 - 2.5 Nm Sheath 1.5 mm 2.0 - 2.5 Nm 9. Fasten the front panel to the waterproof cover with the four binding screws re- moved at step 1.
  • Page 29 1. MOUNTING 4. Fabricate the cable. Armor Sheath Sheath Aluminum tape (Cut the drain wire.) Cable jacket Cable jacket 5. Pass the cable through the nut and cable entrance. 6. Wrap the vinyl tape and cable tie around the cable (see the figure below). Armor Cable jacket Cable jacket...

  • Page 30: Video Lan Converter If-7100

    1. MOUNTING Video LAN Converter IF-7100 Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. • Select a location where the shock and vibration are minimal. • Locate the unit away from places subject to water splash and rain. •...

  • Page 31: Sensor Adapter Mc-3000S/3010A 3020D

    1. MOUNTING Sensor Adapter MC-3000S/3010A/3020D Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. • Select a location where the shock and vibration are minimal. • Locate the unit away from places subject to water splash and rain. •...

  • Page 32: Intelligent Hub Hub-3000

    Use the optional Intelligent Hub HUB-3000 to connect gateway network equipment. This network cannot be connected with the LAN network on board. Also, to connect with the non-FURUNO system or multiple Live Player V5 (PCs) use this unit. Mounting considerations Select a mounting location, keeping in mind the following points: •...

  • Page 33: Power Supply Unit Psu-011

    1. MOUNTING 1.10 Power Supply Unit PSU-011 Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit away from heat sources. • Select a location where the shock and vibration are minimal. • Locate the unit away from places subject to water splash and rain. •...

  • Page 34: Switching Hub Hub-100 (Option)

    1. MOUNTING 1.11 Switching HUB HUB-100 (Option) Use the optional Switching HUB HUB-100 to connect sensor networks. This network cannot be connected to the LAN network on board. Note that a commercial PC cannot be connected in this network, other than for the maintenance. For the mounting procedures, see the operator’s manual for HUB-100 (Pub.

  • Page 35: Junction Box If-8540 (Option)

    1. MOUNTING • The unit should be 4 m or more away from the VHF/MF/HF antennas. Mounting Install the junction box on a bulkhead or desktop with four M10 bolts or 10 coach bolts (local supply). Fixing hole four locations 1.13 Junction Box IF-8540 (Option) Four sensor adapters (one MC-3000S-N and three MC-3020D-N) are pre-installed in...
  • Page 36 1. MOUNTING This page is intentionally left blank. 1-28...

  • Page 37: Wiring

    WIRING The illustration on this page shows the general connection of the VR-7000. For de- tailed information, see the interconnection diagram. Many of the cables mentioned are JIS (Japanese Industrial Standards) cables. If not available locally, use the equivalent. See the cable guide in the Appendix for how to select equivalent cables.

  • Page 38: Data Collecting Unit Vr-7010

    A maximum of seven channels of video data can be input, however six or more channels can not be recorded within the stipulated time. Note that the maximum record channel changes according to a resolution and video format. For details, see VR-7000 operator’s manual (OME-44850). 2.1.1 Location of connectors and terminals To make connections, unfasten seven binding screws, then detach the cover from the DCU.
  • Page 39 2. WIRING Cable clamp location Fasten each cables connected to the DCU to the location shown below. Clamp the ar- mor of the cable. When the armor of the cable is covered with vinyl (cable jacket), re- move it so that the armor lies in the cable clamp. Attach the cable band (supplied) to each cable to be connected to the DCU and record sensor name/equipment name on each cable band.
  • Page 40 2. WIRING Notice for the connection with the remote alarm panel When connecting the DCU to the remote alarm panel (RAP), do as follows to prevent the malfunction due to the difference of ground voltages between the DCU and RAP. 1.

  • Page 41: Power Supply

    2. WIRING 2.1.2 Power supply Connect the AC power 100-230 VAC to J1 of the DCU through the emergency switch board (ESB). For the connection, use the DPYC-1.5 cable. The DCU is compatible with 100-230 VAC input (universal power supply), so it is not necessary to change the tap setting on the switchboard.
  • Page 42 2. WIRING 2.1.4 Changing internal LAN connection (for video signal input with IEC61162-450 format) The J502 port (DATA) is connected to the J17 port internally in default. When you in- put the radar/ECDIS video signal with the IEC61162-450 (LAN) format, disconnect the LAN cable from the J17 port and connect it to the J26 port.
  • Page 43 REMOTE_ACK- BUZZER_STOP+ Input BUZZER_STOP- No connection System failure (output) The VR-7000 notifies the AMS that an alert has been generated. The system failure signal is output as normally closed (NC). J310 Contact Rating SYS_FAIL+ Voltage: Less than 32 V Current: Less than 100 mA...
  • Page 44 2. WIRING Power failure (output) The VR-7000 notifies the AMS of power failure. The power failure signal is output as normally close (NC). • Supplied by AC power: Close • Power off or supplied by the battery: Open J310 Contact Rating...
  • Page 45 2. WIRING Remote ACK (input) The AMS notifies the VR-7000 that it has acknowledged an alarm. The remote ACK signal is input as normally open (NO). Note: Input the contact signal. Voltage can not be input. J310 REMOTE_ACK+ Contact Rating...

  • Page 46: Data Recording Unit

    2. WIRING Data Recording Unit 2.2.1 Fixed Data Recording Unit VR-7020 A good grounding bond is required between the fixed DRU base plate and ship hull. Be sure that the external tooth lock washers are clamped between the bare metal of the fixed DRU base plate and the bare hull by the mounting bolts.

  • Page 47: Cable Fabrication

    2. WIRING Cable fabrication • DPYCY-1.5 cable Cable jacket Cable jacket Twist the wires. Attach the rod terminal. Fasten this part with the cable gland. Vinyl sheath Vinyl tape (width: 10) • FR-FTPC-CY cable Cable jacket Cable jacket Attach the rod terminal. Cut the unused wires.
  • Page 48 2. WIRING 3. Attach the terminal board cover to the unit with six screws (supplied). Terminal board cover DPYCY-1.5 cable To DCU (J311) To DCU (J25) FR-FTPC-CY cable Cable gland 4. Fasten two cable glands. Tightening torque: • Upper cable gland: 6.67 N•m •...
  • Page 49 2. WIRING Junction Box VR-7022F To connect the float-free data recording unit VR-7021F to the DCU, use the junction box VR-7022F. FR-FTPC-CY cable To the DCU (J21) Float-free DRU cable To the float-free DRU To the DCU (J312) DPYCY-1.5 cable 1.
  • Page 50 2. WIRING 4. Referring to the interconnection diagram at the back of this manual, connect the lines to the terminal board of the junction box. 5. Fasten the cable glands to fix the cable. The cables must project 10 mm inside of the junction box. Note: Fasten the cable glands by hand.
  • Page 51 2. WIRING Remote Alarm Panel VR-7017 Connect wiring to the terminal board of the unit, referring to the interconnection dia- gram at the back of this manual. See appendix 2 for how to fabricate the cable. After wiring the cable, fix the cable with the cable clamp. Remote alarm panel (back cover removed) Connector J101 After fabricating the cable, connect it the connector J101.
  • Page 52 2. WIRING Microphone VR-7011 Connect wiring to the terminal board of the unit, referring to the interconnection dia- gram at the back of this manual. See appendix 2 for how to fabricate the cable. Microphone (back cover removed) After fabricating the cable, connect it to the connector J1. Connector J1 Pin No.
  • Page 53 2. WIRING Waterproof Microphone VR-7012W Connect wiring to the terminal board of the unit, referring to the interconnection dia- gram at the back of this manual. See section 1.6 for how to fabricate the cable. Front panel of the waterproof microphone (rear side) After fabricating the cable, connect it to the connector J1.
  • Page 54 2. WIRING Video LAN Converter IF-7100 The video LAN converter converts the radar/ECDIS video signal (DVI-D or RGB) to a LAN signal. Use the optional cable shown below to input the DVI-D or RGB signal. • DVI-D: DVI-D/D S-LINK 5M/10M •...
  • Page 55 2. WIRING 2.7.1 Video signal (DVI-D/RGB) available with IF-7100 The IF-7100 is compatible with separate sync signals shown below. • Video signal level: Compliant with the VESA standard. • Horizontal sync signal: Max.91.146 kHz, positive or negative • Vertical sync signal: Max. 85 Hz The table below shows receivable resolution for the IF-7100.
  • Page 56 2. WIRING 2.7.2 Fabrication of the coaxial cable When you connect the IF-7100 with a radar or ECDIS using the coaxial cable, prepare the optional cable shown below. • BNCX5-DSUB15-L400: D-SUB-BNC connector cable • CP24-01200/01210*: Coaxial cable (six core, unfabricated) with BNC connectors *: When you need either the coaxial cable or the BNC connector individually, prepare the optional ECX-3C-2V-T cable (three core) and FB-SPM1D+ connector (BNC con- nector).
  • Page 57 2. WIRING 5. Insert the center pin to the core and sol- Screw the shell into the cable. der. Center pin Shell 7. Completed. 2.7.3 Connections 1. Remove the outside cover of the video LAN converter; hold the right and left sides of the cover and pull the cover outward.
  • Page 58 10. Fix the LAN cable to the cable clamp with the supplied cable tie. 11. Reattach the outside cover. 2.7.4 Connection with a FURUNO radar Connection with the FAR-217/FAR-287 series radar For the connection between the IF-7100 and FAR-217/FAR-287 series radar, see the respective radar installation manual.
  • Page 59 2. WIRING Connection with the FR-215 series radar Prepare the items shown below and modify the FR-215 series radar to connect it to the IF-7100. Name Type Part No. RGB Buffer Kit OP03-162 • RGB-BUFF Board • 03P9229A 008-501-130 • NH-XH Connector •...
  • Page 60 2. WIRING INT board RGB-BUFF board Analog RGB cable, 2 m 03-2058 XH13P J449 NH10P BNC × 5 DB15 DB15 J449 To video LAN converter XH3P J463 NH4P 03-2057 Connector converter FAR-28×5/FR-28×5 display unit The figure below shows how to mount CPA/TCPA board together with RGB-BUFF board in the FAR-285/FR-285 series radar.

  • Page 61: Sensor Adapters

    2. WIRING Sensor Adapters A maximum of eight MC-3000S can be connected to the DCU through the HUB-100. The MC-3000S can connect a maximum of ten additional units in combination with MC-3010A and MC-3020D, using the MC1.5-W cables. However, note that five MC- 3010A can be connected.
  • Page 62 2. WIRING How to set NC/NO output (J2) The POWER FAIL signal on the connector J2 can be set to NC (normally closed) out- put or NO (normally open) output as shown in the table below. Connector J2 Pin # Signal name In/Out Description...
  • Page 63 2. WIRING Connector J5 Signal Pin # In/Out Description IEC61162-2 IEC61162-1 Modbus* name TD2-A Serial CH2, out- TTYCS(LA)-4 TTYCS(LA)-4 TTYCS(LA)-4 put IEC61162-1/ 2/modbus TD2-B Serial CH2, out- put IEC61162-1/ 2/modbus RD2-A Serial CH2, input No connection No connection IEC61162-2/ modbus RD2-B Serial CH2, input IEC61162-2/...
  • Page 64 2. WIRING Connector J8 Signal Pin # In/Out Description Used cable name TD5-A Serial CH5, output IEC61162-1 TTYCS-1Q or TTYCSLA-1Q TD5-B Serial CH5, output IEC61162-1 RD5-H Serial CH5, input IEC61162-1 RD5-C Serial CH5, input IEC61162-1 TD6-A Serial CH6, output IEC61162-1 TD6-B Serial CH6, output IEC61162-1 RD6-H...
  • Page 65 2. WIRING 2.8.2 MC-3000S jumper and MODBUS settings See the jumper blocks in the MC-CS Board (24P0114) referring to the tables that fol- low. No use MC-CS Board (24P0114) Setting termination resistors Use the jumper block J19 to set the termination resistor on/off for the MODBUS com- munication on the connector J1.
  • Page 66 Set the jumper blocks J20 and J21 to select the communication type (IEC-61162-1/2 or MODBUS) of the connector J4 (CH1). For VR-7000, the MODBUS type is not used/ The setting of the jumper block JP20 and JP21 must be identical.
  • Page 67 2. WIRING 2.8.3 Case packing for MC-3000S OP24-28 (optional) The optional kit OP24-28 protects the connectors on the MC-3000S to waterproofing standard IPX2. Case packing (type: OP24-28, code no.: 001-169-970) Name Type Code No. Case packing (serial) 21-014-2051 100-367-880-10 1. Unfasten four binding screws to remove the cover from the adapter. Binding screw Cover 2.
  • Page 68 2. WIRING 2.8.4 MC-3010A/3020D connections Unfasten four screws to remove the cover, pass the cables through the clamps and attach the cables to respective connectors. The shield part of the cable (or drain wire) must be fastened by (connected to) the clamp. For fabrication of the cables connected to the unit, see appendix 2.
  • Page 69 2. WIRING Input type (MC-3010A) Select the type of the analog data input, power voltage or power current. When chang- ing the input type, turn off the MC-3010A and on again to put change in effect. Note 1: For current input, use the AWG wire for jumper. Note 2: The input must not exceed the range of the input voltage, to prevent malfunc- tion.
  • Page 70 2. WIRING Connector J3 Power Power Signal name In/Out Description voltage current AN1_IN Analog 1 input TTYCS(LA)-1 AN1_GND Analog 1 GND CURR1_JP1 Analog 1 input, power current/ Pin #3-#4: Pin #3-#4: voltage setting jumper 1 open short CURR1_JP2 Analog 1 input, power current/ voltage setting jumper 1 Connector J4 Power...
  • Page 71 2. WIRING How to set contact input (MC-3020D) Use the connectors J3 to J6 on the MC-DIN Board (24P0116) to set the contact input. See the tables on the next page. Note 1: For contact input, use the AWG24 wire for jumper. Note: The input must not exceed the range of the input voltage, to prevent malfunc- tion.
  • Page 72 2. WIRING Connector J3 ACK1 ACK1 ACK2 ACK2 Signal name In/Out Remarks contact voltage contact voltage DC12V_OUT ACK1 In Pin #1-#2: No connec- short tion DIGI_IN1 MPYC-12 DIGI_RTN1 MPYC-12 GND (DC12V) No connec- tion DC12V_OUT ACK2 In Pin #1-#2: No con- short nection DIGI_IN2...
  • Page 73 2. WIRING Connector J6 ACK7 ACK7 ACK8 ACK8 Pin # Signal name In/Out Remarks contact voltage contact voltage DC12V_OUT ACK7 In Pin #1-#2: No connec- short tion DIGI_IN7 MPYC-12 DIGI_RTN7 MPYC-12 GND (DC12V) No connec- tion DC12V_OUT ACK8 In Pin #1-#2: No con- short nection...
  • Page 74 2. WIRING 2.8.5 MC-3010A/3020D jumper setting This section shows how to set the MC-ANLG Board (24P0115, for MC-3010A) and MC-DIN Board (24P0116, for MC-3020D). MC-ANLG Board (24P0115) MC-DIN Board (24P0116) Setting MODBUS addresses Use the rotary switch U18 to set the MODBUS address with a digit of number from “0”. When multiple sensor adapters are connected to the MC-3000S, the same number cannot be used among them.
  • Page 75 2. WIRING 2.8.6 MC-3010A/3020D case packing OP24-29 (optional) The optional kit OP24-29 protects the connectors on the MC-3010A/3020D to water- proofing standard IPX2. Case packing (type: OP24-29, code no.: 001-169-970) Name Type Code No. Case packing 21-014-2052-2 100-367-961-10 1. Unfasten four binding screws to remove the cover from the adapter. Cover Binding screw 2.
  • Page 76 2. WIRING Intelligent HUB HUB-3000 Fix the LAN cable connected to the cable clamp using the cable ties (supplied). Power port Power Fail DPYC-1.5 cable DPYC-1.5 cable Ground wire (IV-1.25sq., supplied) LAN cable No use. LAN port to network equipment Attach the LAN port cap (supplied) to the unused connector holes to provide waterproofing standard IPX2.

  • Page 77: Junction Box If-8530 (Option)

    2450113-01.01 or later. To update the program, prepare the items shown in the table below. Item Description Update program Download it from Furuno Technet. Cable between a PC and Type: JEC9-XH4-#26-L2500, Code No.: 000-170-945-10 junction box Manual for how to update Type: C42-01406-*, Code No.: 000-190-046-1*...
  • Page 78 2. WIRING Cable entrance: Clamp locations Serial Serial Serial Analog Power supply Ground terminal Spare Digital Digital Analog (IV-8sq.) 2.11.2 DIP switch setting Change the DIP switch settings according to serial and analog signal specifications. Turn off the DCU to change the DIP switch settings. Analog signal (DIP switch S1 and S2) Analog Signal Range Setting Channel...
  • Page 79 2. WIRING Serial data baud rate (DIP switch S3 and S4) Serial Baud Rate Setting Channel SW No. SW Label 4800 bps 9600 bps 19200 bps 38400 bps S4-1 CH1* S4-2 S4-3 CH2* S4-4 S4-5 CH3* S4-6 S4-7 CH4* S4-8 S3-1 CH5* S3-2...

  • Page 80: Ip Addresses Of The Unit

    2. WIRING 2.12 IP Addresses of the Unit The IP addresses of each unit are shown below. Float-Free DRU VR-7021F IP address: 10.0.0.150 Video LAN Converter VR-7100 Radar/ECDIS (VLC1) IP address: 10.0.0.120 AUDIO Board 24P0134 Video LAN Converter VR-7100 Radar/ECDIS IP address: 10.0.0.110 (VLC2) For internal network...

  • Page 81: Setting Up The Equipment

    SETTING UP THE EQUIPMENT After installing the VR-7000, configure the system. For details, see the manual for VDR Maintenance Viewer and Live Player V5. The outline of the setup is as below. Step 1. Network setting on PC and VDR Step 2.

  • Page 82: Recording Expiration Date Of Parts

    3. SETTING UP THE EQUIPMENT Recording Expiration Date of Parts After installing and setting up the system, cut out (or copy and cut) the expiration data sheet provided below. Then record the date of expiration date of each item on the sheet.

  • Page 83: Dip Switch Setting In Video Lan Converter

    3. SETTING UP THE EQUIPMENT DIP Switch Setting in Video LAN Converter Set the DIP switch (S1) in the cases shown below. • When two video LAN converters are installed: Turn on the S1-1 in the No.2 video LAN converter (No.2 VLC). •...
  • Page 84 3. SETTING UP THE EQUIPMENT This page is intentionally left blank.

  • Page 85: Appendix 1 Jis Cable Guide

    EX: TTYCYSLA - 4 MPYC - 4 TTYCSLA-4 Core Area (mm # of cores Designation type Designation type The following reference table lists gives the measurements of JIS cables commonly used with Furuno products: Cable Core Core Cable Diameter Type...

  • Page 86: Appendix 2 Cable Fabrication

    APPENDIX 2 CABLE FABRICATION Fabrication of DPYC cable Armor Sheath Sheath Vinyl tape (Width: 20) Fabrication of DPYCY cable Armor Sheath Sheath Cable jacket Cable jacket Vinyl tape (Width: 20) Cable jacket Cable jacket AP-2...
  • Page 87 APPENDIX 2 CABLE FABRICATION Fabrication of TTYCSLA cable Aluminum tape Armor Sheath Drain wire* Vinyl tape (Width: 20) Crimp-on lug Pass the heat shrinkable (local supply) onto the drain wire*, then attach the crimp-on lug to it. *: The drain wire is not required for the access points shown below. Access point Unit Connector No.
  • Page 88 APPENDIX 2 CABLE FABRICATION Fabrication of MC1.5-W-L cable Core: 6 Core: 6 Core: 6 Shield Shield Shield Vinyl tape Vinyl tape Vinyl tape (fold back) (fold back) (fold back) Fabrication of MPYC-12 cable (MC-3020D) 80 or more 80 or more 80 or more No use: 50 No use: 50...
  • Page 89 APPENDIX 2 CABLE FABRICATION Fabrication of the LAN cable For VR-7010 For other units Armor Armor Cable jacket Cable jacket Cable jacket Cable jacket Inner vinyl sheath Inner vinyl sheath Outer vinyl sheath Outer vinyl sheath Vinyl tape (Width: 20) Vinyl tape (Width: 20) 25 mm approx.
  • Page 90 APPENDIX 2 CABLE FABRICATION The length of “L“ The length of “L1“ and “L2“ in the figure on AP-2 to AP-5 page is shown below. Access point The length of “L“ Cable Unit Connector No. 0 mm More than 200 mm VR-7010 J313 0 mm...

  • Page 91: Appendix 3 Rod Terminals

    APPENDIX 3 ROD TERMINALS How to attach the rod terminal (ferrule type) Vinyl sheath Rod terminal The length of “L” AI 1.5-6 BK (black) AI 0.34-6 TQ (blue) 6 mm Core AI 0.75-6 GY (gray) AI 1-6 RD (red) 0.5 to 1 mm AI 0.14-8 GY (gray) 8 mm A 1.5-10...
  • Page 92 APPENDIX 3 ROD TERMINALS VR-7020 Connector # Pin # Signal name Rod terminal to use Connected cable 24 V AI 1.5-6 BK (black) DPYCY-1.5 24 V AI 1.5-6 BK (black) DPYCY-1.5 TD_P TD_N AI 0.14-8 GY (gray) FR-FTPC-CY RD_P RD_N MC-3000S, MC-CS Board (24P0114) Connector # Pin #...
  • Page 93 APPENDIX 3 ROD TERMINALS Connector # Pin # Signal name Rod terminal to use Connected cable TD3-A TD3-B RD3-A TTYCS-4 RD3-B AI 0.75-6 GY (gray) TTYCSLA-4 ISOGND3 RD3-H RD3-C Connector # Pin # Signal name Rod terminal to use Connected cable TD4-A TD4-B RD4-A...
  • Page 94 APPENDIX 3 ROD TERMINALS MC-3010A MC-ANALG Board (24P0115) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_IN AI 0.34-6 TQ (blue) 24V_GND MODBUS-A MC1.5-W-Lxxx MODBUS-B AI 0.14-8 GY (gray) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_OUT AI 0.34-6 TQ (blue)
  • Page 95 APPENDIX 3 ROD TERMINALS MC-3020D, MC-DIN Board (24P0116) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_IN AI 0.34-6 TQ (blue) 24V_GND MODBUS-A MC1.5-W-Lxxx MODBUS-B AI 0.14-8 GY (gray) Connector # Pin # Signal name Rod terminal to use Connected cable 24V_OUT AI 0.34-6 TQ (blue)
  • Page 96 APPENDIX 3 ROD TERMINALS Connector # Pin # Signal name Rod terminal to use Connected cable DV12V_OUT7 DIGI_IN7 DIGI_RTN7 AI 1-6 RD (red) MPYC-12 DC12V_OUT8 DIGI_IN8 DIGI_RTN8 *: Pin #1 and 5: no cable connection. However the jumper connection is necessary between #1 and 2 and #5 and 6 depending on the input specification.

  • Page 97: Appendix 4 Digital Interface

    APPENDIX 4 DIGITAL INTERFACE Digital Interface ACN - Alert command $--ACN,hhmmss.ss,aaa,x.x,x.x,c,a*hh<CR><LF> 4 5 6 1. Time (UTC) 2. Manufacturer mnemonic code (3 digits) 3. Alert Identifier (0 - 9999999) 4. Alert Instance (1 - 999999,nul) 5. Alert command (A,Q,O,S) A=acknowledge Q=request/repeat information O*=responsibility transfer S=silence...
  • Page 98 APPENDIX 4 DIGITAL INTERFACE ALC - Cyclic alert list $--ALC,xx,xx,xx,x.x, aaa,x.x,x.x,x.x,’’’’’’ *hh<CR><LF> 1 2 3 4 1. Total number of sentences this message (01 to 99) 2. Sentence number (01 to 99) 3. Sequential message identifier (00 to 99) 4. Number of alert entries (0 to 3) 5.
  • Page 99 APPENDIX 4 DIGITAL INTERFACE DOR - Door status indication $--DOR,a,hhmmss.ss,aa,cc,xxx,xxx,a,a,c--c*hh<CR><LF> 5 6 7 8 9 1. Message type S=Status for section: the number of faulty and/or open doors reported in the division specified in field 4 and 5. The section may be a whole section (one or both of the division indicator fields are null) or a sub-section.
  • Page 100 APPENDIX 4 DIGITAL INTERFACE DTM - Datum reference $--DTM,ccc,a,x.x,a,x.x,a,x.x,ccc*hh<CR><LF> 1 2 3 4 5 6 7 1. Local datum (W84=WGS84 W72=WGS72 S85=SGS85, P90=PE90 User defined=999, IHO datum code 2. Local datum subdivision code (null or one character) 3. Lat offset, min (-59.99999 to 59.59999) 4.
  • Page 101 APPENDIX 4 DIGITAL INTERFACE FIR - Fire detection $--FIR , A, hhmmss.ss, aa, cc, xxx, xxx, a, a, c--c *hh<CR><LF> 1. Message type S: Status for section: the number of faulty and activated condition reported as number in field 6.The section may be a whole section (one or both of the division indicator fields are null) or a sub-section.
  • Page 102 APPENDIX 4 DIGITAL INTERFACE GEN - Generic status information $--GEN,hhhh,hhmmss.ss,hhhh,..,hhhh *hh<CR><LF> 1. Index of first packed binary field in sentence Index of first group in GEN sentence. Address is represented in hexadecimal format in the HEX range 0000 trough FFFF. The 16-bit address is formatted as fixed 4-character HEX field. 2.
  • Page 103 APPENDIX 4 DIGITAL INTERFACE GNS - GNSS fix data $--GNS,hhmmss.ss,llll.lll,a,IIIII.III,a,c--c,xx,x.x,x.x,x.x,x.x,x.x,a*hh<CR><LF> 7 8 9 10 11 12 13 1. UTC of position (no use) 2. Latitude (0.00000 to 9000.00000) 3. N/S 4. Longitude (0.00000 to 18000.00000) 5. E/W 6. Mode indicator N=No fix A=Autonomous D=Differential P=Precise R=Real Time Kinematic F=Float RTK E=Estimated Mode M=Manual Input Mode S=Simulator Mode 7.
  • Page 104 APPENDIX 4 DIGITAL INTERFACE HRM - Heel angle, roll period and roll amplitude measurement device $--HRM,x.x,x.x,x.x,x.x,A,x.x,x.x,hhmmss.ss,xx,xx,*hh<CR><LF> 3 4 5 6 7 9 10 1. Actual heel angle, degrees (see Note 1) 2. Roll period, seconds (see Note 2) 3. Roll amplitude, port side, degrees (see Note 3) 4.
  • Page 105 APPENDIX 4 DIGITAL INTERFACE HTC - Heading/Track control command $--HTC,A,x.x,a,a,a,x.x,x.x,x.x,x.x,x.x,x.x,x.x,a,a*hh<CR><LF> 2 3 4 5 6 8 9 10 11 12 13 14 1. Override, A = in use, V = not in use 2. Commanded rudder angle, degrees 3. Commanded rudder direction, L/R=Port/starboard 4.
  • Page 106 APPENDIX 4 DIGITAL INTERFACE NSR - Navigation status report $--NSR, a, A, a, A, a, A, a, A, a, A, a, a, A *hh<CR><LF> 1 2 3 4 5 6 7 8 9 10 11 12 13 1. Integrity of heading (see NOTE 1) 2.
  • Page 107 APPENDIX 4 DIGITAL INTERFACE RMC - Recommended minimum specific GPS/TRANSMIT data $--RMC,hhmmss.ss,A,llll.ll,a,yyyyy.yy,a,x.x,x.x,ddmmyy,x.x,a,a,a*hh<CR><LF> 2 3 4 6 7 8 10 11 1213 1. UTC of position fix (000000 to 235959) 2. Status (A=Data valid, V=Navigation receiver warning) 3. Latitude (0.0000 to 9000.0000) 4.
  • Page 108 APPENDIX 4 DIGITAL INTERFACE RTE - Routes $--RTE,x.x,x.x,a,c--c,c--c,..,c--c*hh <CR><LF> 2 3 4 1. Total number of messages being transmitted (1 to n, or null) 2. Sentence number (1 to n, or null) 3. Message mode (C=Complete route W=Working route, first listed) 4.
  • Page 109 APPENDIX 4 DIGITAL INTERFACE TRD - Thruster response data $--TRD, x, x.x, A, x.x, A, x.x*hh<CR><LF> 1 2 3 1. Number of thrusters Odd=Bow thruster Even=Stern thrusters 2. RPM response 3. RPM mode indicator P = P = Per cent (%): 0 - 100 % from zero to maximum rpm R = Revolutions per minute (RPM) V = data invalid This should not be a null field.
  • Page 110 APPENDIX 4 DIGITAL INTERFACE VDM - UAIS VHF data-link message !--VDM,x,x,x,x,s--s,x*hh<CR><LF> 1 2 3 4 5 6 1. Total number of sentences needed to transfer the message (1 to 9) 2. Sentence number (1 to 9) 3. Sequential message identifier (0 to 9, null) 4.
  • Page 111 APPENDIX 4 DIGITAL INTERFACE VTG - Course over ground and ground speed $--VTG,x.x,T,x.x,M,x.x,N,x.x,K,a*hh <CR><LF> 1 2 3 4 5 6 7 8 9 1. Course over ground, degrees (0.0 to 359.9) 2. T=True (fixed) 3. Course over ground, degrees (0.0 to 359.9) 4.
  • Page 112 APPENDIX 4 DIGITAL INTERFACE WPL - Waypoint location $--WPL,llll.ll,a,yyyyy.yy,a,c--c*hh<CR><LF> 1. Waypoint latitude (0.000000 to 9000.00000) 2. N/S 3. Waypoint longitude (0.00000 to 18000.00000 4. E/W 5. Waypoint identifier (No use) XDR - Transducer measurements $--XDR, a, x.x, a, c--c,…………………a, x.x, a, c--c*hh<CR><LF> 1.
  • Page 113 APPENDIX 4 DIGITAL INTERFACE Serial Interface: IEC61162-1 • Data Collecting Unit, input 5V_VCC 5V_VCC J303 0.1u FL25 ERJ_2GEJ102X 734_232 NFM41CC102R2A3L RD_3H CR13 LED:GREEN SML_H12M8TT86 ERJ_3GEYJ471V CR19 RD_3C FL26 ERJ_2GEJ102X NFM41CC102R2A3L 1SS226_TE85L_F PC400J00000F • Data Collecting Unit, output AP-29...
  • Page 114 APPENDIX 4 DIGITAL INTERFACE Serial Interface: IEC61162-2 • Data Collecting Unit, input J301 LTC1535ISW_TRPBF 734_233 NFM41CC102R2A3L 2 ST1 RD_1H 3 ST2 RD_1C 5V_VCC 25 DI 26 DE RD_1G NFM41CC102R2A3L 28 R0 SLO_N 27 RE_N J320 1 VCC VCC2 FFC_3AMEP1B NFM41CC102R2A3L 4 GND 0.1u SHORT PIN...

  • Page 115: Appendix 5 Coding Of The Float-Free Dru

    APPENDIX 5 CODING OF THE FLOAT- FREE DRU Similarly to a satellite EPIRB (Emergency Position Indicate Radio Beacon), the capsule of the float-free DRU is coded before installation. The ship’s MMSI, name, call sign, etc. are recorded to the capsule during coding, and this information is indicated on the capsule. The expiration date of both the capsule in the battery and the hydrostatic release unit is coded into the capsule of the float-free DRU as shown below.
  • Page 116 APPENDIX 5 CODING OF THE FLOAT-FREE DRU Hydrostatic release unit The expiration date of the hydrostatic release unit is 2 years after the year and month of coding. The expiration date is indicated on the sticker attached on the side of the unit and sticker on the side of the bracket.
  • Page 128 2/Jul/2014 H.MAKI...
  • Page 129 27/Jun/2014 H.MAKI...
  • Page 131 4/Aug/2014 H.MAKI...
  • Page 132 13/Mar/2014 H.MAKI...
  • Page 136 4/Sep/2014 H.MAKI...
  • Page 137 D-10 19/Jun/2014 H.MAKI...
  • Page 138 D-11...
  • Page 139 D-12 Y.NISHIYAMA 13/Jan/2012...
  • Page 140 D-13 Y.NISHIYAMA 13/Jan/2012...
  • Page 141 D-14 13/Jan/2012 Y.NISHIYAMA...
  • Page 142 D-15...
  • Page 143 D-16 Y. Hatai...
  • Page 144 D-17...
  • Page 145 12/Mar/2015 H.MAKI 17/Jul/2015 H.MAKI...
  • Page 146 OPEN: VOLTAGE INPUT, CLOSE: CURRENT INPUT IV-1.25sq. IV-1.25sq. 注記 ＊１）造船所手配。 ＊２）オプション。 NOTE *1: SHIPYARD SUPPLY. *2: OPTION. DRAWN TITLE MC-3000S/3010A/3020D T.YAMASAKI 9/Apr/2014 CHECKED 名称 センサーアダプター H.MAKI 14/Apr/2014 APPROVED 相互結線図 21/Apr/2014 H.MAKI VR-7000 SCALE MASS NAME SENSOR ADAPTER DWG.No. REF.No. C4485-C02- B 24-014-6003-2 INTERCONNECTION DIAGRAM...
  • Page 147 G:GND DRAWN TITLE IF-8530 T.YAMASAKI 18/Jun/2014 CHECKED 名称 接続箱 H.MAKI 18/Jun/2014 各信号の接続に関しては造船所/船主との事前打合せが必要です。 CONSULT WITH SHIPOWNER AND/OR SHIPYARD ABOUT CONNECTION OF DEVICES. VR-7000 APPROVED 注記 NOTE 相互結線図 19/Jun/2014 H.MAKI VR-3000/3000S ＊１）造船所手配。 *1: SHIPYARD SUPPLY. SCALE MASS NAME ＊２）入力信号が4-20mAの場合はV-I間をショートすること。 *2: SET JUMPER BETWEEN I AND V FOR 4-20mA SIGNAL.
