Furuno VR-7000 Operator's Manual

Voyage data recorder (vdr) simplified voyage data recorder (s-vdr)
Hide thumbs Also See for VR-7000:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Installation Manual
OPERATOR'S MANUAL
VOYAGE DATA RECORDER (VDR)
SIMPLIFIED VOYAGE DATA
RECORDER (S-VDR)
VR-7000/VR-7000S
Model
www.furuno.com

Advertisement

Table of Contents
loading

Related Manuals for Furuno VR-7000

Summary of Contents for Furuno VR-7000

  • Page 1 OPERATOR'S MANUAL VOYAGE DATA RECORDER (VDR) SIMPLIFIED VOYAGE DATA RECORDER (S-VDR) VR-7000/VR-7000S Model www.furuno.com...
  • Page 3 How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chap- ter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of battery before disposal to prevent fire, heat generation caused by short circuit.
  • Page 4 SAFETY INSTRUCTIONS Indicates a condition that can cause death or serious WARNING injury if not avoided. Indicates a condition that can cause minor or moderate CAUTION injury if not avoided. Warning, Caution Prohibitive Action Mandatory Action WARNING WARNING ELECTRICAL SHOCK HAZARD Do not disassemble the battery in Do not open the equipment.
  • Page 5 WARNING LABELS Warning labels are attached to the DCU. Do not remove the labels. If the label is missing or damaged, contact a FURUNO agent or dealer about replacement. WARNING To avoid electrical shock, do not remove cover.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS FOREWORD ........................v SYSTEM CONFIGURATION ..................vii OPERATION ......................1 1.1 Overview ........................1 1.2 Operating Procedure..................... 5 1.2.1 How to turn the power on then record the data ............. 5 1.2.2 How to stop recording.................... 6 1.3 Operation on Remote Alarm Panel ................6 1.3.1 Start screen and base screen................

  • Page 7: Foreword

    A Word to the Owner of the VR-7000/7000S Congratulations on your choice of the FURUNO Voyage Data Recorder (VDR) VR-7000/Simpli- fied Voyage Data Recorder (S-VDR) VR-7000S. We are confident you will see why the FURUNO name has become synonymous with quality and reliability.
  • Page 8 • Compatible with remote maintenance. • Recorded data can be analyzed and monitored on shore. • Software updating from a PC connected to Ethernet. • Long term device for storage (VR-7000: 720 hours recording, VR-7000S: 48 hours recording) and retrieval of data. Program No.

  • Page 9: System Configuration

    SYSTEM CONFIGURATION Basic configuration is shown with solid line. Fixed Data Recording Unit (Fixed DRU) Switching HUB Radar, ECDIS, etc. VR-7020* HUB-100 100-230 VAC Float-free Data Recording Unit Junction Box (Float-free DRU) Max. 2 units VR-7022F VR-7021F* VHF Audio : Select one for VR-7000S. Remote Alarm Panel VR-7017* Live Player V5...

  • Page 10: Operation

    OPERATION Overview The VR-7000/7000S consists of a Data Collecting Unit (DCU), Data Recording Units (Fixed DRU and Float-free DRU), Remote Alarm Panel (RAP), Video LAN Converter, Sensor Adapter and bridge microphone units. The VDR system continuously stores data for 48 hours onto the Flash Memory in the capsule, erasing the oldest data stored as new data is recorded.
  • Page 11 • IEC sentences: when received • Analog and digital data: every second For VR-7000, you can select one or two 512-GB SSD(s) as internal long term device(s). When selecting one SSD, you can add another one using an optional SSD kit later.
  • Page 12 1. OPERATION Date and time: Date and time are obtained from an external GPS navigator referenced to UTC. When an external GPS navigator is not available, a signal is recorded with a built-in clock in the DCU. Ship’s position and datum used: Latitude, longitude and datum are obtained from a GPS navi- gator, Loran-C receiver or other EPFS or INS available on standard serial interface.
  • Page 13 1. OPERATION The channel number and resolution can be recorded is shown in the table below. Input method No. of pcs Resolution/Max. channel number Inputs through 1 SSD (512 GB) UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch the video LAN 2 SSDs (1 TB) UXGA (1600×1200): 2 ch + Full HD (1920×1080): 1 ch +...

  • Page 14: Operating Procedure

    VR-7017, however, this is not abnormal. Note 2: If the VR-7000/7000S system fails to start, it may be restarted. Note 3: Do not turn off the DCU power for 30 seconds after the power is turned on. Recorded data can be corrupted.

  • Page 15: How To Stop Recording

    VR-7017 VDR REMOTE ALARM PANEL ▲ ▼ ◄ ► [MENU/ESC] : List [ENT] : - - - : Brill Base screen for VR-7000 VR-7017 REMOTE ALARM PANEL Start screen “Press MENU, then ENT to save recorded data.” VR-7000S VR-7017 SVDR REMOTE ALARM PANEL ▲...

  • Page 16: Controls

    1. OPERATION 1.3.2 Controls MENU BRILL TEST Extract Control Function Short press: Displays the [BRILL] setting window. BRILL BRILL Long press: Restores the brilliance of the LCD and keys to default. Acknowledge an alert to stop the flashing of the alert list and silence the alert buzzer.

  • Page 17: Alert List

    1. OPERATION 1.3.4 Alert list The alert list provides information about active alerts. ◄ ► Alert List 1/ 2 Alert ID Alert Name Time of last chan No.08 Sensor ( LAN 412324 15:24:37 No.07 Sensor ( LAN 412323 15:24:37 No.06 Sensor ( LAN 412322 15:24:37 No.05 Sensor ( LAN...
  • Page 18 1. OPERATION [Serial Monitor] You can monitor the sensor information input to the serial channels. ◄ ► 1 ( SI01 - SI30 ) Serial Channel Select SI01:GPS SI11:XXXXX SI21:XXXXX SI02:XXXXX SI12:XXXXX SI22:XXXXX To shift the page, SI03:XXXXX SI13:XXXXX SI23:XXXXX use the cursorpad SI04:XXXXX SI14:XXXXX SI24:XXXXX...
  • Page 19 1. OPERATION To see the information for a sensor(LAN) channel, use the cursorpad to select a sensor(LAN) channel (LN01 to LN64) then press the ENT key to show the sensor (LAN) monitor screen. The latest received data is displayed on the top of the screen. ◄...
  • Page 20 1. OPERATION [Image Capture Status] You can monitor the information of the images recorded in the DCU. The information for the image captures (the time and date when the image is captured to the VDR, captured image size, etc.) are updated. ◄...

  • Page 21: How To Extract The Recorded Data To An External Media

    1. OPERATION [Status Monitor] You can see the status of the system. Page 2 is only for VR-7000S. ◄ ► ◄ ► Status Monitor 2 / 2 Status Monitor 1 / 2 VDR Version : 2450102-01.XX AreaNumber Start-End TrackNumber SYS Time : 10/05/2014 17:45:20 RAP Version : 2450103-01.XX Area1 01/06/2016 17:20:30-01/06/2016 05:20:30 01...
  • Page 22 Long Term Device Long Term Device Float DRU Float DRU Area1 01/06/2016 17:20:30-01/06/2016 05:20:30 01 VR-7000 Area2 03/06/2016 23:10:15-03/06/2016 11:10:15 01 Area3 07/06/2016 19:30:50-07/06/2016 07:30:50 01 Area4 10/06/2016 10:40:20-09/06/2016 22:40:20 01 VR-7000S 4. Use the cursorpad ( or ) to select the data source from [Long Term Device], [Float DRU] or [Area1 (2, 3, 4)] (only for VR-7000S) then press the ENT key.

  • Page 23: How To Record The Data To A Usb Flash Memory

    1. OPERATION 6. Press the ENT key. The confirmation window appears. User Disk Format? 7. Use the cursorpad ( or ) to select [Yes] then press the ENT key. The window changes as follow. Now Extractin Remainin time: hh/mm/ss Now Formattin Extract Com lete Cancel...

  • Page 24: How To Execute Save Function For Recorded Data (Only For Vr-7000S)

    1. OPERATION 1.3.8 How to execute SAVE function for recorded data (only for VR- 7000S) If marine incidents occur, record the data, which are recorded to the capsule, to area1 (or 2, 3, 4) in the long term device(s). When all areas are used, the memory for the oldest area is automati- cally overwritten with the new memory in order from the oldest area.

  • Page 25: How To Release The Capsule From The Bracket Of The Float-Free Dru In Emergency Situation

    1. OPERATION How to Release the Capsule from the Bracket of the Float-free DRU in Emergency Situation In an emergency situation, release the capsule from the bracket of the Float-free DRU to remove the capsule if possible. Note 1: Do not drop the capsule from a high place. Note 2: Do not release the capsule other than in an emergency situation or maintenance.
  • Page 26 1. OPERATION After picking up the capsule After picking up the capsule from the sea, dry it with a towel. When the capsule is dried, its lamp stops flashing. Pass the capsule to the investigating authorities through the search and rescue team.

  • Page 27: Maintenance

    MAINTENANCE Regular maintenance is important to maintain performance. This chapter contains maintenance instructions to be followed to obtain optimum performance and the longest possible life of the equipment. WARNING NOTICE ELECTRICAL SHOCK HAZARD Do not apply paint, anti-corrosive Do not open the DCU cover. sealant or contact spray to coating or plastic parts of the equipment.

  • Page 28: Maintenance Of The Float-Free Dru

    2. MAINTENANCE Maintenance of the Float-free DRU The capsule of the Float-free DRU transmits the signal similar to the distress signal of a satellite EPIRB. Therefore, trouble to the search and rescue authorities may occur if the capsule acciden- tally transmits the signal. If accidental transmission occurs, stop the transmission and inform the search and rescue authorities of the accidental transmission.
  • Page 29 2. MAINTENANCE the VDR can retain the data of the latest 10 minutes. If more than 10 minutes passes after re- leasing the capsule, the data of 10 minutes before the capsule is returned to the bracket is lost. At this time, the communication error with the Float-free DRU appears on the remote alarm pan- el.
  • Page 30 2. MAINTENANCE • Do not use force to reattach the capsule and bracket cover. Also, confirm that there is no space or foreign material between the storage module and docking module (see figure below). If the capsule is not seated in the bracket correctly, the communication error occurs on the remote alarm panel after 10 minutes and the capsule may transmit the signal because that the elec- trodes are shorted by water.
  • Page 31 2. MAINTENANCE Maintenance point Result Normal self Do the self test as follows: test Note: Hold the capsule by its handle during the test. This keeps foreign material away from the silicone grease on the capsule, and keeps the an- tenna of the capsule away from metallic objects or human body.

  • Page 32: Annual Performance Test For The Float-Free Dru

    2. MAINTENANCE Maintenance point Result Extended self The extended self test involves both the normal self test and GPS test. Do test (normal the extended self test as follows: self test and Note: The extended self test reduces the lifetime of the battery. Do this test GPS test) once every three months.

  • Page 33: Shore-Based Maintenance (Sbm)

    2. MAINTENANCE test is conducted by a engineer authorized by the Ship’s Electric Installation Contractors’ Associ- ation of Japan. 2.2.3 Shore-Based Maintenance (SBM) The capsule of the Float-free DRU has the same functionality of an satellite EPIRB (Emergency Position-Indicating Radio Beacon). So, it is required to conduct the Shore-Based Maintenance (SBM) within five years from installation or previous SBM.

  • Page 34: Fuse Replacement

    If the fuses for the DCU have blown, replace them with the specified fuses (see page AP-3 for the fuse location). If the fuses blow again after replace- ment, contact a FURUNO agent or dealer. Have a qualified technician replace the fuse for Video LAN Converter and Sensor Adapter.

  • Page 35: Consumable Parts

    2. MAINTENANCE Consumable Parts You can check the lifetimes of the consumable parts on the RAP screen (see "[Life Parts List]" on page 11). Contact your dealer to replace the consumable parts. Unit Name Type Interval Indication on the RAP VR-7010 Battery CY1-1487-01...

  • Page 36: Self Test

    2. MAINTENANCE Self Test The self test checks the ROM, RAM, connection, program no., keyboard, LCD performance and buzzer. The user can do the tests to help the service technician in troubleshooting. How to open the test menu Press the TEST key on the RAP to show the test menu. Self Test LCD Test Buzzer Test...
  • Page 37 2. MAINTENANCE LCD test 1. Open the test menu. 2. Use the cursorpad ( or ) to select [LCD Test] then press the ENT key. Each press of the ENT key changes the LCD pattern in the sequence shown below. Green Blue 16 tones of red...

  • Page 38: Verification Of Recording Function Of The Long Term Device

    2. MAINTENANCE Verification of Recording Function of the Long Term Device Verify the long term device recording function at the annual inspection and when repairing or maintaining the VDR or sensors connected to the VDR. The verification requires the Live Player V5.

  • Page 39: Troubleshooting

    TROUBLESHOOTING This chapter provides information on possible causes of problems you may experience with your VDR. If you still have a problem after referring to the table, contact your dealer for further advice. Always provide the product serial number. General Troubleshooting Use the table below to identify the problem, cause and remedy.
  • Page 40 3. TROUBLESHOOTING Alert no. Alert name Description Action 412171 Recording Buffer A image exceeding a recording Contact your dealer. Overflow buffer is input. 412173 Fatal System Failure Fatal system error. Reboot au- If the error re-occurs, contact tomatically after an error oc- your dealer.
  • Page 41 3. TROUBLESHOOTING Alert no. Alert name Description Action 4123xx No No.xx Sensor No. xx sensor (LAN) channel Check the sentences input (xx: (LAN) Connection has not received correct format from the LAN channel on the 17 - 80) (xx: 01 - 64) data from a connected sensor RAP and confirm that the ap- (LAN) device (xx: 01 - 64).
  • Page 42 FloatDRU Memory Data cannot be recorded more Shortage than 48 hours. 412523 LongTermDevice • VR-7000: Data cannot be re- Memory Shortage corded more than “720 hours + used hours in SAVE ar- eas”. • VR-7000S: Data cannot be recorded more than “48 hours + used hours in SAVE areas”.
  • Page 43 3. TROUBLESHOOTING Alert no. Alert name Description Action 412525 Sensor(LAN) Buffer Serial, analog and digital data If the error re-occurs, contact Overflow from Sensor Adapter are not re- your dealer. corded to Fixed DRU, Float-free DRU and Long Term Device. 412527 Image(LAN) Buffer Image data from RADAR/EC-...

  • Page 44: Menu Items

    APPENDIX 1 MENU ITEMS Below are the menu items for the Remote Alarm Panel (RAP). To open this menu, press the MENU/ESC key. Menu item Function Execute SAVE Function Records the data, which are recorded to the capsule, to area1 (or 2, 3, (only for VR-7000S) 4) in the long term device(s) Serial Monitor...

  • Page 45: Parts List/Location

    This equipment contains complex modules in which fault diagnosis and repair down to component level are not practical (IMO A.694(17)/8.3.1). Only some discrete components are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value for shipboard maintenance;...
  • Page 46 APPENDIX 2 PARTS LIST/LOCATION Parts location Data Collecting Unit (VR-7010) ADP-586-31 24P0135 24P0141 24P0137 24P0138 24P0137A Baterry switch 24P0133 AC switch AC power connector 24P0134 AUDIO One set (12 pcs.) of batteries Battery fuse AC fuse Video LAN Converter (IF-7100) 24P0132 Fuse Remote Alarm Panel (VR-7017)
  • Page 47 APPENDIX 2 PARTS LIST/LOCATION Microphone (VR-7011), Waterproof Microphone (VR-7012W) 24P0136 VR-7011 VR-7012W Sensor Adapter (MC-3000S) 24P0114 MC-CS Fuse MC-3000S AP-4...

  • Page 48: List Of Terms And Abbreviations/Symbols

    APPENDIX 3 LIST OF TERMS AND AB- BREVIATIONS/SYMBOLS The following table shows the terms, abbreviations and symbols used in the VR-7000/7000S. Terms and abbreviations Term Abbreviation Term Abbreviation Alternate current Local Area Network Additional Liquid Crystal Display Alert ALERT Light Emitting Diode...

  • Page 49: Playing Back Recorded Data

    APPENDIX 4 PLAYING BACK RECORDED DATA IMO Circular MSC.214(81) recommends that all VDR systems installed on or after 1 June 2008 carry software to playback data on a PC, the manual for data extraction, and the cable necessary to connect the PC to the Data Collecting Unit (DCU). Attach the supplied card holder to the front door of the DCU to store the items listed in the table below.

  • Page 50: Specifications

    SIMPLIFIED VOYAGE DATA RECORDER VR-7000S The Voyage Data Recorder (VDR) is a recording system required on certain categories of ships from 1st July 2002 by the revised SOLAS Chapter V. VR-7000/7000S fully complies with the IMO Resolution MSC.333 (90) and IEC 61996-1/2 testing standard.
  • Page 51 FURUNO VR-7000/7000S Operating life Minimum 168 hrs at -20°C Release mechanism Hydrostatic release unit (released at water depth 4 m) Navigation device 22 channel GPS receiver COSPAS-SARSAT Transmitter Antenna type Built-in, omnidirectional Frequency 406.037 MHz ± 2 ppm Output power 5 W ±...
  • Page 52 MISC, SATD, NAVD, VDRD, RCOM, TIME, PROP, USR1 to USR8 Output MISC Other Network Function (except IEC61162-450) HTTP; *.*.*.*:80 VR-7000 replies on PC’s ARP command and ping command Live player, Maintenance viewer - UDP multicast: 239.255.0.1 Port: 20001-20004, 21001-21004, 22001-22007, 23001-23007 27001-27010, 28001-28010 - TCP: *.*.*.*, Port: 20, 21, 10106, 24001, 24004...
  • Page 53 FURUNO VR-7000/7000S POWER SUPPLY Data collecting unit 100-230 VAC: 1.6-0.7 A, 1 phase, 50/60 Hz Sensor adapters 24 VDC: 1.4 A max.(11 units), fed from DCU Junction box (IF-8530) 24 VDC: 0.9 A, fed from DCU Video LAN converter (IF-7100, option) 24 VDC: 0.3 A (SER.NO. 100000 to 199999: 0.7 A)
  • Page 56 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : JUL 2014 Printed in Japan All rights reserved. G : NOV . 15, 2016 Pub. No. OME-44850-G ( YOTA ) VR-7000/7000S 0 0 0 1 7 9 3 4 2 1 6...
